4. INSTALL STARTER ARMATURE PLATE
(a) Insert the armature plate to the starter yoke.
(b) Align the keyway of the starter plate with the key
inside the starter yoke, and install the starter plate.
5. INSTALL STARTER COMMUTATOR END FRAME
ASSEMBLY
(a) Align the rubber of the end frame with the cutout of
the starter yoke.
(b) Install the end frame to the starter yoke.
6. INSTALL STARTER YOKE ASSEMBLY
(a) Align the protrusion of the starter yoke with the
cutout of the starter drive housing.
(b) Install the starter yoke with the 2 through-bolts.
Torque: 5.9 N*m (60 kgf*cm, 52 in.*lbf)
7. INSTALL MAGNETIC SWITCH ASSEMBLY
(a) Apply grease to the plunger and the hook.
(b) Hang the plunger hook of the magnetic switch to the
drive lever.
(c) Install the plunger and return spring.
A073991E04
A079727E01
A079728E01
A079720
A079729
Page 906 of 2000
ST–142AZ-FE STARTING – STARTER
ST
(d) Install the magnetic switch with the 2 screws.
Torque: 7.5 N*m (76 kgf*cm, 66 in.*lbf)
(e) Connect the lead wire to the magnetic switch with
the nut.
Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
INSTALLATION
1. INSTALL STARTER ASSEMBLY
(a) Install the starter with the 2 bolts.
Torque: 37 N*m (377 kgf*cm, 27 ft.*lbf)
(b) Connect the starter connector.
(c) Install the terminal nut and cover the nut with the
cap.
Torque: 9.8 N*m (100 kgf*cm, 7 ft.*lbf)
2. INSTALL BATTERY BRACKET REINFORCEMENT
(a) Install the bracket reinforcement.
Torque: 19 N*m (194 kgf*cm, 14 ft.*lbf)
A079719
A079718
A124921
A124920
A124919
Page 907 of 2000
2AZ-FE STARTING – STARTERST–15
ST
3. INSTALL FRONT BATTERY BRACKET
(a) Install the bracket front with the 4 bolts.
Torque: 19 N*m (194 kgf*cm, 14 ft.*lbf)
(b) Attach the 2 wire harness clamps.
4. INSTALL BATTERY
5. INSTALL BATTERY INSULATOR
6. INSTALL BATTERY CLAMP
(a) Attach the hook of the battery clamp to the battery
bracket front.
(b) Temporarily tighten the nut and install the bolt.
(c) Adjust the battery clamp's position.
(d) Fully tighten the nut and bolt.
Torque: 5.0 N*m (51 kgf*cm, 44 in.*lbf)
(e) Attach the 2 wire harness clamps.
7. CONNECT CABLE TO POSITIVE BATTERY
TERMINAL
8. CONNECT CABLE TO NEGATIVE BATTERY
TERMINAL
A124918
A124917E01
Page 908 of 2000
2AZ-FE STARTING – IGNITION SWITCHST–19
ST
If the result is not as specified, replace the switch
assembly.
INSTALLATION
1. INSTALL IGNITION SWITCH ASSEMBLY
(a) Install the ignition switch with the 2 screws.
(b) Install the ignition key cylinder light connector.
(c) Install the ignition switch connector.
2. INSTALL STEERING COLUMN COVER LOWER
(a) Attach the 4 claws to install the steering column
lower cover.
3. CONNECT CABLE TO NEGATIVE BATTERY
TERMINAL
A124915
A124916
A134309
Page 909 of 2000
ST–62GR-FE STARTING – STARTER
ST
REMOVAL
1. DISCONNECT CABLE FROM NEGATIVE BATTERY
TERMINAL
CAUTION:
Wait at least 90 seconds after disconnecting the
cable from the negative (-) battery terminal to
prevent airbag and seat belt pretensioner activation.
2. REMOVE BATTERY CLAMP SUB-ASSEMBLY
(a) Loosen the bolt and nut, and remove the battery
clamp.
3. REMOVE BATTERY INSULATOR
4. REMOVE BATTERY
5. REMOVE BATTERY TRAY
6. REMOVE FRONT BATTERY CARRIER
(a) Disconnect the 2 clamps of the engine wire.
(b) Remove the 4 bolts and front battery carrier.
7. REMOVE BATTERY BRACKET REINFORCEMENT
(a) Remove the 2 bolts and battery bracket
reinforcement.
8. REMOVE STARTER ASSEMBLY
(a) Disconnect the starter connector.
(b) Open the terminal cap, remove the nut and
disconnect the starter wire.
A124827
A124828
A126954
Page 910 of 2000
2GR-FE STARTING – STARTERST–7
ST
(c) Remove the 2 bolts and starter.
DISASSEMBLY
1. REMOVE MAGNETIC SWITCH ASSEMBLY
(a) Remove the nut and disconnect the lead wire from
the magnetic switch assembly.
(b) Remove the 2 screws holding the magnetic switch
assembly to the starter drive housing assembly.
(c) Remove the magnetic switch assembly.
(d) Remove the return spring and plunger from the
starter drive housing assembly.
2. REMOVE STARTER YOKE ASSEMBLY
(a) Remove the 2 through-bolts, and pull out the starter
yoke assembly together with the starter commutator
end frame assembly.
3. REMOVE STARTER COMMUTATOR END FRAME
ASSEMBLY
(a) Remove the starter commutator end frame
assembly from the starter yoke assembly.
A126955
A079718E01
A079719E01
A079720E01
A079721E01
Page 911 of 2000
ST–82GR-FE STARTING – STARTER
ST
4. REMOVE STARTER ARMATURE PLATE
(a) Remove the starter armature plate from the starter
yoke assembly.
5. REMOVE STARTER COMMUTATOR END FRAME
COVER
(a) Using a screwdriver, pry out the starter commutator
end frame cover.
6. REMOVE STARTER ARMATURE ASSEMBLY
(a) Using snap ring pliers, remove the snap ring and
plate washer.
(b) Remove the starter armature assembly from the
starter commutator end frame assembly.
7. REMOVE PLANETARY GEAR
(a) Remove the 3 planetary gears from the starter drive
housing assembly.
A079722E01
A079723E01
A082440E03
A081167E01
Page 912 of 2000

2GR-FE STARTING – STARTERST–9
ST
INSPECTION
1. INSPECT STARTER ASSEMBLY
CAUTION:
These tests must be performed within 3 to 5 seconds
to avoid burning out the coil.
(a) Perform the pull-in test.
(1) Disconnect the lead wire from terminal C.
(2) Connect the battery to the magnetic switch
assembly as shown in the illustration. Check
that the clutch pinion gear extends.
If the clutch pinion gear does not move, replace
the magnetic switch assembly.
(b) Perform the hold-in test.
(1) Maintain the battery connections of the pull-in
test above, but disconnect the negative (-) lead
from terminal C. Check that the pinion gear
remains extended.
If the clutch pinion gear returns inward, replace
the magnetic switch assembly.
(c) Check the clutch pinion gear return.
(1) Disconnect the negative (-) lead from the
switch body. Check that the clutch pinion gear
returns.
If the clutch pinion gear does not return,
replace the magnetic switch assembly.
(d) Perform the no-load performance test.
(1) Connect the lead wire to terminal C. Make sure
that the lead is not grounded.
Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
(2) Clamp the starter in a vise.
(3) Connect the battery and an ammeter to the
starter as shown in the illustration.
(4) Check that the starter rotates smoothly and
steadily while the pinion gear is moving out.
Then measure the current.
Standard current:
90 A or less at 11.5 V
If the test result is not as specified,
overhaul the starter assembly.
A060459E07
A081044E06
A081045E01
A060462E06
