Page 593 of 2000

TOYOTA RAV4 2006 Service Repair Manual EM–362AZ-FE ENGINE MECHANICAL – TIMING CHAIN EM • Do not add engine oil for at least 2 hours after installing the chain cover. A132566E02

Page 594 of 2000

TOYOTA RAV4 2006 Service Repair Manual 2AZ-FE ENGINE MECHANICAL – TIMING CHAINEM–37 EM (d) Install the timing chain cover with the 12 bolts and 2 nuts. Torque: 9.0 N*m (92 kgf*cm, 80 in.*lbf) for bolt A 25 N*m (255 kgf*cm, 18 ft.*l

Page 595 of 2000

TOYOTA RAV4 2006 Service Repair Manual EM–382AZ-FE ENGINE MECHANICAL – TIMING CHAIN EM (b) Install a new gasket and the chain tensioner with the 2 nuts. Torque: 9.0 N*m (92 kgf*cm, 80 in.*lbf) NOTICE: When installing the chain tensi

Page 596 of 2000

TOYOTA RAV4 2006 Service Repair Manual 2AZ-FE ENGINE MECHANICAL – TIMING CHAINEM–39 EM (b) Turn the crankshaft counterclockwise, then disconnect the plunger knock pin from the hook. (c) Turn the crankshaft clockwise, then check that

Page 597 of 2000

TOYOTA RAV4 2006 Service Repair Manual EM–402AZ-FE ENGINE MECHANICAL – TIMING CHAIN EM (d) Uniformly tighten the 12 bolts and 2 nuts in the sequence shown in the illustration. Torque: 9.0 N*m (92 kgf*cm, 80 in.*lbf) (e) Place a tran

Page 598 of 2000

TOYOTA RAV4 2006 Service Repair Manual 2AZ-FE ENGINE MECHANICAL – TIMING CHAINEM–41 EM (d) Install the 2 engine wires with the 2 bolts. Torque: 8.4 N*m (86 kgf*cm, 74 in.*lbf) (e) Connect the 2 ventilation hoses to the cylinder head

Page 599 of 2000

TOYOTA RAV4 2006 Service Repair Manual EM–422AZ-FE ENGINE MECHANICAL – TIMING CHAIN EM (b) Connect the 2 clamps of the engine wire. (c) Install the wire harness protector with the bolt. 20. INSTALL ENGINE MOUNTING INSULATOR FR (a) In

Page 600 of 2000

TOYOTA RAV4 2006 Service Repair Manual 2AZ-FE ENGINE MECHANICAL – TIMING CHAINEM–43 EM 30. INSTALL NO. 1 ENGINE COVER (a) Install the engine cover with the 2 nuts. Torque: 7.0 N*m (71 kgf*cm, 62 in.*lbf) 31. INSTALL FRONT FENDER APRO
