Page 993 of 2000

TOYOTA RAV4 2006 Service Repair Manual U140F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–199 AX 23. INSTALL NO. 1 GOVERNOR APPLY GASKET (a) Install 2 new governor apply gaskets. 24. INSTALL FRONT CLUTCH APPLY TUBE (a) Install th

Page 994 of 2000

TOYOTA RAV4 2006 Service Repair Manual AX–200U140F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX 27. INSTALL TRANSAXLE REAR COVER SUB- ASSEMBLY (a) Using SST and a press, press in the bearing. SST 09950-60010 (09951-00230, 09952-

Page 995 of 2000

TOYOTA RAV4 2006 Service Repair Manual U140F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–201 AX (h) Apply adhesive to the threads of the bolts labeled A. Adhesive: Toyota Genuine Adhesive 1344, Three Bond 1344 or Equivalent (i)

Page 996 of 2000

TOYOTA RAV4 2006 Service Repair Manual AX–202U140F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX (b) Install the 1-way clutch to the transaxle. NOTICE: Make sure that the mark on the 1-way clutch outer race is visible. (c) Using

Page 997 of 2000

TOYOTA RAV4 2006 Service Repair Manual U140F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–203 AX (c) Install the underdrive planetary gear to the transaxle. NOTICE: Engage all the discs of underdrive clutch and the hub splines

Page 998 of 2000

TOYOTA RAV4 2006 Service Repair Manual AX–204U140F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX 33. INSTALL MULTIPLE DISC CLUTCH HUB (a) Install the bearing race to the transaxle while checking its direction. Standard bearing r

Page 999 of 2000

TOYOTA RAV4 2006 Service Repair Manual U140F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–205 AX 35. INSTALL OVERDRIVE BRAKE GASKET (a) Install 2 new overdrive brake gaskets. 36. INSTALL DIFFERENTIAL GEAR ASSEMBLY (a) Install the

Page 1000 of 2000

TOYOTA RAV4 2006 Service Repair Manual AX–206U140F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX Standard bearing and bearing race diameter 39. INSTALL OIL PUMP ASSEMBLY (a) Install the oil pump to the transaxle with the 7 bolts.
