Page 1881 of 2000

TOYOTA RAV4 2006 Service Repair Manual LI–50LIGHTING – LIGHTING SYSTEM LI (a) Remove the front fog light relay from the No. 6 relay block. (b) Disconnect the A11 and A28 front fog light connectors. (c) Measure the resistance of the

Page 1882 of 2000

TOYOTA RAV4 2006 Service Repair Manual LIGHTING – LIGHTING SYSTEMLI–51 LI (c) Measure the resistance of the wire harness side connectors. Standard resistance NG OK (a) Remove the headlight dimmer switch. (b) Measure the resistance o

Page 1883 of 2000

TOYOTA RAV4 2006 Service Repair Manual LIGHTING – VANITY LIGHTLI–129 LI (b) Inspect vanity light switch. Standard resistance If the result is not as specified, replace the visor assembly. INSTALLATION 1. INSTALL VANITY LIGHT BULB (a

Page 1884 of 2000

TOYOTA RAV4 2006 Service Repair Manual LI–134LIGHTING – HEADLIGHT DIMMER SWITCH LI REMOVAL 1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) bat

Page 1885 of 2000

TOYOTA RAV4 2006 Service Repair Manual LIGHTING – HEADLIGHT DIMMER SWITCHLI–135 LI INSPECTION 1. INSPECT HEADLIGHT DIMMER SWITCH ASSEMBLY (a) Measure the resistance of the switch. Standard resistance: Light control switch Headlight d

Page 1886 of 2000

TOYOTA RAV4 2006 Service Repair Manual LI–136LIGHTING – HEADLIGHT DIMMER SWITCH LI (b) Install the headlight dimmer switch with the clamp. (c) Connect the connector. 2. INSTALL WIPER AND WASHER SWITCH ASSEMBLY (See page WW-29) 3. IN

Page 1887 of 2000

TOYOTA RAV4 2006 Service Repair Manual LIGHTING – FRONT DOOR COURTESY SWITCHLI–141 LI INSTALLATION HINT: • Use the same procedures for the RH and LH sides. • The procedures listed below are for the LH side. • A bolt without a t

Page 1888 of 2000

TOYOTA RAV4 2006 Service Repair Manual LIGHTING – REAR DOOR COURTESY SWITCHLI–143 LI INSTALLATION HINT: • Use the same procedures for the RH and LH sides. • The procedures listed below are for the LH side. • A bolt without a to
