Page 985 of 2000
U140F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–191
AX
(c) Using SST and a press, install the counter drive
gear and bearing to the transaxle.
SST 09950-70010 (09951-07150), 09950-60020
(09951-00750)
NOTICE:
Do not apply excessive pressure.
10. INSTALL 1ST AND REVERSE BRAKE PISTON
(a) Coat 2 new O-rings with ATF.
(b) Install the 2 O-ring to the 1st and reverse brake
piston.
(c) Coat the 1st and reverse brake piston with ATF, and
install it to the transaxle.
11. INSTALL 1ST AND REVERSE BRAKE RETURN
SPRING SUB-ASSEMBLY
(a) Using SST, a press and snap ring expander, press
the piston return spring and snap ring to the
transaxle.
SST 09387-00070
NOTICE:
• Stop the press when the spring sheet is
lowered to the place 1 to 2 mm (0.039 to 0.078
in.) from the snap ring groove, preventing the
spring sheet from being deform.
• Do not expand the snap ring excessively.
D003614E01
D003913E01
D003813E01
D003600E01
Page 986 of 2000
AX–192U140F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT
AX
12. INSTALL FRONT PLANETARY RING GEAR
(a) Using a screwdriver, install the front planetary ring
gear and snap ring to the brake hub.
13. INSTALL FRONT PLANETARY GEAR ASSEMBLY
(a) Install the front planetary gear assembly to the
brake hub.
(b) Using SST and a press, press-fit the front planetary
gear.
SST 09950-60010 (09951-00500), 09950-70010
(09951-07100)
NOTICE:
Do not apply excessive pressure.
(c) Install the washer, as shown in the illustration.
D003615E03
D008063E01
D003916E04
D003917E01
Page 987 of 2000

U140F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–193
AX
(d) Using SST, install the nut.
SST 09387-00030, 09387-00080
Torque: 280 N*m (2,855 kgf*cm, 206 ft.*lbf)
(e) Using SST and a torque wrench, measure the
turning torque of the bearing while rotating SST at
60 rpm. When the measured value is not within the
specified value, gradually tighten the nut until it
reaches the specified value.
SST 09387-00080
Torque: Turning torque at 60 rpm
0.51 to 1.02 N*m (5.1 to 10.0 kgf*cm, 4.4
to 8.7 in.*lbf) for new
0.3 to 0.5 N*m (3.1 to 5.1 kgf*cm, 27 to
4.4 in.*lbf) for used
HINT:
Use a torque wrench with a fulcrum length of 160
mm (6.3 in.).
(f) Using a chisel and hammer, stake the front
planetary gear washer.
14. INSTALL INPUT SUN GEAR
(a) Install the 2 thrust bearings, bearing race and front
planetary sun gear to the front planetary gear.
Standard bearing and race diameter
D003596E01
D003918E01
D008074E02
D003873E03
Item Inside Outside
Bearing 34.6 mm (1.362 in.) 52.2 mm (2.055 in.)
Race 40.3 mm (1.587 in.) 58.0 mm (2.283 in.)
Bearing 38.6 mm (1.52 in.) 60.0 mm (2.362 in.)
Page 988 of 2000
AX–194U140F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT
AX
15. INSTALL REAR PLANETARY GEAR ASSEMBLY
(a) Coat the bearing race with ATF, and install it to the
rear planetary gear assembly.
Standard bearing race diameter
(b) Install the No. 2 thrust washer.
(c) Install the rear planetary gear to the rear planetary
ring gear.
(d) Using a screwdriver, install the snap ring.
16. INSTALL 1ST AND REVERSE BRAKE CLUTCH DISC
(a) Install the 5 plates and 5 discs.
Install in order:
P - D - P - D - P - D - P - D - P - D
HINT:
P = Plate
D = Disc
D003593E01
Item Inside Outside
Race 38.6 mm (1.520 in.) 58.0 mm (2.83 in.)
D003910E01
D008062E01
D003616E02
C129389E01
Page 989 of 2000

U140F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–195
AX
(b) Using a vernier caliper, measure the distance
between the disc surface and the contact surface of
the 2nd brake cylinder and transaxle (Dimension A).
(c) Select an appropriate flange so that the pack
clearance will meet the specified value.
0.745 to 1.21 mm (0.0293 to 0.0476 in.)
HINT:
Piston stroke = Dimension A - Flange thickness
Standard flange thickness
(d) Install the flange.
17. INSTALL 2ND BRAKE PISTON ASSEMBLY
(a) Install the 2nd brake piston to the transaxle.
(b) Install the snap ring and measure the inside
diameter.
Standard inside diameter:
More than 167 mm (6.57 in.)
NOTICE:
• Because the taper snap ring has the
positioning direction, check it when
installing.
• When the diameter does not satisfy the
specified value, replace the snap ring with a
new one.
18. INSTALL 1-WAY CLUTCH SLEEVE OUTER
(a) Install the 1-way clutch outer sleeve to the 2nd
brake cylinder.
NOTICE:
Check the positioning direction of the outer
sleeve.
D003618E01Mark Thickness Mark Thickness
1 1.8 mm (0.071in.) 5 2.2 mm (0.087 in.)
2 1.9 mm (0.075 in.) 6 2.3 mm (0.091 in.)
3 2.0 mm (0.079 in.) 7 2.4 mm (0.094 in.)
4 2.1 mm (0.083 in.) 8 2.5 mm (0.098 in.)
D003815E01
D003619E01
D008078E01
Page 990 of 2000
AX–196U140F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT
AX
19. INSTALL 1-WAY CLUTCH ASSEMBLY
(a) Install the inner race to the 1-way clutch.
NOTICE:
Check the direction of the inner race.
(b) Check the rotating direction of the 1-way clutch for
the lock or free operation, as shown in illustration.
(c) Install the 1-way clutch and bearing to the 1-way
clutch sleeve outer.
Standard bearing diameter
NOTICE:
Install the thrust bearing properly so that no-
colored race will be visible.
20. INSTALL REAR PLANETARY SUN GEAR ASSEMBLY
(a) Coat the No. 1 thrust washer with petroleum jelly,
and install it onto the rear planetary sun gear.
(b) Coat the bearing with petroleum jelly, and install it
onto the rear planetary sun gear.
Standard bearing diameter
D003909E02
D009638E02
D003588E02
Item Inside Outside
Bearing 53.6 mm (2.110 in.) 69.6 mm (2.740 in.)
D003908E01
D003791E01
Item Inside Outside
Bearing 33.8 mm (1.331 in) 48.2 mm (1.898 in.)
Page 991 of 2000

U140F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–197
AX
(c) Install the rear planetary sun gear to the rear
planetary gear.
21. INSTALL 2ND BRAKE CLUTCH DISC
(a) Install the 3 discs and 3 plates to the transaxle.
Standard install in order:
P - D - P - D - P - D
HINT:
P = Plate
D = Disc
(b) Temporarily install the snap ring.
(c) Using a vernier caliper, measure the distance
between the disc surface and snap ring surface.
(d) Select an appropriate flange so that the pack
clearance will meet the specified value.
Standard pack clearance:
0.50 to 0.91 mm (0.0197 to 0.0358 in.)
HINT:
Piston stroke = Clearance - Flange thickness - Snap
ring thickness 1.6 mm (0.063 in.)
Standard flange thickness
(e) Temporarily remove the snap ring, attach the
selected flange and restore the snap ring.
NOTICE:
Secure the snap ring so that its gap is visible
through the groove of the transaxle case.
D003587E01
C129390E01
D009163E01
Mark Thickness Mark Thickness
1 3.0 mm (0.118 in.) 5 3.4 mm (0.134 in.)
2 3.1 mm (0.122 in.) 6 3.5 mm (0.138 in.)
3 3.2 mm (0.126 in.) 7 3.6 mm (0.142 in.)
4 3.3 mm (0.130 in) 8 -
D003623E02
Page 992 of 2000

AX–198U140F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT
AX
22. INSTALL DIRECT CLUTCH
(a) Install the bearing race to the direct clutch.
Standard bearing race diameter
(b) Install the direct clutch and thrust bearing to the rear
planetary sun gear.
NOTICE:
The disc in the direct clutch should completely
mate with the hub attached outside the rear
planetary sun gear. Otherwise, the rear cover
cannot be installed.
(c) Clean the connector part of the transaxle case and
rear cover.
(d) As shown in the illustration, place a straightedge on
the direct clutch drum and measure the distance
between the transaxle case and the straightedge
using a vernier caliper (Dimension B).
(e) Measure the 2 places of the rear cover as shown in
the illustration. Calculate a dimension C using the
following formula.
HINT:
Dimension C = Dimension (1) - Dimension (2)
(f) Calculate the end play value using the following
formula. Select a thrust bearing which satisfies the
end play value and install it.
End play:
0.198 to 0.936 mm (0.00780 to 0.03685 in.)
NOTICE:
Make sure that the colored race side is facing
the direct clutch assembly.
HINT:
End play = Dimension C - Dimension B
Standard bearing thickness and diameter
D003802E01
Item Inside Outside
Bearing race 30.3 mm (1.193 in.) 46.0 mm (1.811 in.)
D003586E01
D003624E01
D003922E01
Thickness Inside Outside
3.58 mm (0.1409 in.) 53.6 mm (2.110 in.) 69.6 mm (2.740 in.)
3.88 mm (0.1528 in.) 53.6 mm (2.110 in.) 70.18 mm (2.768 in.)
