Page 1409 of 2000

TOYOTA RAV4 2006 Service Repair Manual DRIVE SHAFT – FRONT DRIVE SHAFT ASSEMBLY (for 4WD)DS–55 DS 13. INSTALL FRONT DRIVE SHAFT DAMPER RH HINT: Install the damper clamp to outboard joint side. (a) Install a new drive shaft damper cla

Page 1410 of 2000

TOYOTA RAV4 2006 Service Repair Manual DS–56DRIVE SHAFT – FRONT DRIVE SHAFT ASSEMBLY (for 4WD) DS (f) Pack the inboard joint shaft and boot with grease from the boot kit. Standard grease capacity: 175 to 185 g (6.2 to 6.5 oz.) (g) U

Page 1411 of 2000

TOYOTA RAV4 2006 Service Repair Manual DRIVE SHAFT – FRONT DRIVE SHAFT ASSEMBLY (for 4WD)DS–57 DS 20. INSTALL FRONT AXLE INBOARD JOINT BOOT NO. 2 CLAMP LH (a) One touch type: (1) Using a screwdriver, install the No. 2 inboard joint

Page 1412 of 2000

TOYOTA RAV4 2006 Service Repair Manual DS–58DRIVE SHAFT – FRONT DRIVE SHAFT ASSEMBLY (for 4WD) DS (c) Using a snap ring expander, install a new drive shaft hole snap ring. 2. REMOVE FRONT DRIVE SHAFT DUST COVER RH (a) Using SST and

Page 1413 of 2000

TOYOTA RAV4 2006 Service Repair Manual DRIVE SHAFT – FRONT DRIVE SHAFT ASSEMBLY (for 4WD)DS–59 DS 6. INSTALL FRONT AXLE OUTBOARD JOINT BOOT HINT: Before installing the boots, wrap the spline of the drive shaft with vinyl tape to pre

Page 1414 of 2000

TOYOTA RAV4 2006 Service Repair Manual DS–60DRIVE SHAFT – FRONT DRIVE SHAFT ASSEMBLY (for 4WD) DS (c) Using a plastic-faced hammer, fix the buckle into place by tapping it. At the same time, use the plastic-faced hammer to adjust t

Page 1415 of 2000

TOYOTA RAV4 2006 Service Repair Manual DRIVE SHAFT – FRONT DRIVE SHAFT ASSEMBLY (for 4WD)DS–61 DS (b) Using water pump pliers, temporarily lock the boot clamp by clamping it down until a "click" sound is heard. (c) Using a

Page 1416 of 2000

TOYOTA RAV4 2006 Service Repair Manual DS–62DRIVE SHAFT – FRONT DRIVE SHAFT ASSEMBLY (for 4WD) DS 9. INSTALL FRONT DRIVE SHAFT DAMPER LH (a) Install a new drive shaft damper clamp and the drive shaft damper to the drive shaft. HINT:
