WW–28WIPER AND WASHER – WIPER SWITCH
WW
(c) Check the intermittent operation.
(1) Connect the voltmeter's positive (+) lead to
terminal E10-3 (+1) and the negative (-) lead to
terminal E9-2 (EW).
(2) Connect the battery's positive (+) lead to
terminal E10-2 (+B) and the negative (-) lead to
terminal E9-2 (EW) and E10-1 (+S).
(3) Turn the wiper switch to the INT position.
(4) Connect the battery's positive (+) lead to
terminal E10-1 (+S) for 5 seconds.
(5) Connect the battery's negative (-) lead to
terminal E10-1 (+S). Operate the intermittent
wiper relay and check the voltage between
terminals E10-3 (+1) and E9-2 (EW).
Standard voltage:
Refer to the illustration below.
If the result is not as specified, replace the
switch assembly.
(d) Check the front washer operation.
(1) Turn the wiper switch OFF.
(2) Connect the battery's positive (+) lead to
terminal E10-2 (+B) and the negative (-) lead to
terminals E10-4 (+S) and E9-2 (EW).
(3) Connect the voltmeter's positive (+) lead to
E10-3 (+1) and the negative (-) lead to terminal
E9-2 (EW).
(4) Turn the washer switch ON and OFF, and
check the voltage between terminals E10-3
(+1) and E9-2 (EW).
OK:
Refer to the illustration below.
If the result is not as specified, replace the
switch assembly.
E056399E25
E125344E01
Page 1898 of 2000

WIPER AND WASHER – WIPER SWITCHWW–29
WW
(e) Check the rear wiper switch.
(1) Measure the resistance of the switch.
Standard resistance
If the result is not as specified, replace the
switch assembly.
(f) Check the rear washer switch.
(1) Measure the resistance of the switch.
Standard resistance
If the result is not as specified, replace the
switch assembly.
INSTALLATION
1. INSTALL WIPER AND WASHER SWITCH ASSEMBLY
(a) Attach the claw to install the wiper switch.
(b) Connect the connectors.
NOTICE:
Do not push the claw with excessive force as
damage may occur.
2. INSTALL STEERING COLUMN COVER LOWER (See
page SR-20)
3. INSTALL STEERING COLUMN COVER UPPER (See
page SR-20)
4. INSTALL STEERING WHEEL ASSEMBLY (See page
SR-21)
5. PLACE FRONT WHEELS FACING STRAIGHT AHEAD
6. INSPECT STEERING WHEEL CENTER POINT
7. INSTALL STEERING PAD ASSEMBLY (See page RS-
336)
8. CONNECT CABLE TO NEGATIVE BATTERY
TERMINAL
9. INSPECT STEERING PAD ASSEMBLY (See page RS-
337)
10. CHECK SRS WARNING LIGHT
(a) Check the SRS warning light (see page RS-337).
E124704E05
Tester Connection Switch Condition Specified Condition
E9-2 (EW) - E9-6 (CIR) INT Below 1
E9-2 (EW) - E9-7 (+1R) ON
E9-2 (EW) - E9-6 (CIR) OFF 10 k
or higher
E9-2 (EW) - E9-7 (+1R)
Tester Connection Switch Condition Specified Condition
E9-2 (EW) - E9-7 (+1R)
E9-2 (EW) - E10-5 (WR)ON Below 1
OFF 10 k or higher
B133131
Page 1899 of 2000

WIPER AND WASHER – WASHER MOTORWW–33
WW
INSPECTION
1. INSPECT WINDSHIELD WASHER MOTOR AND
PUMP ASSEMBLY
HINT:
This check should be performed with the windshield
washer motor and pump installed to the washer jar.
(a) Fill the washer jar with washer fluid.
(b) Connect the battery's positive (+) lead to terminal 1
of the washer motor and pump, and the negative (-)
lead to terminal 2.
(c) Check that washer fluid flows from the washer jar.
OK:
Washer fluid flows from the washer jar.
If the result is not as specified, replace the washer
motor and pump assembly.
2. INSPECT REAR WASHER MOTOR AND PUMP
ASSEMBLY
(a) Fill the washer jar with washer fluid.
(b) Connect the battery's positive (+) lead to terminal 1
of the washer motor and pump, and the negative (-)
lead to terminal 2.
(c) Check that washer fluid flows from the washer jar.
OK:
Washer fluid flows from the washer jar.
If the result is not as specified, replace the washer
motor and pump assembly.
INSTALLATION
1. INSTALL REAR WASHER MOTOR AND PUMP
ASSEMBLY
(a) Install the windshield washer motor and pump to the
packing of the washer jar.
2. INSTALL WINDSHIELD WASHER MOTOR AND PUMP
ASSEMBLY
(a) Install the windshield washer motor and pump to the
packing of the washer jar.
E114464
E114465
B133126E01
B133127E01
Page 1900 of 2000
WW–34WIPER AND WASHER – WASHER MOTOR
WW
3. INSTALL WINDSHIELD WASHER JAR ASSEMBLY
(a) Install the windshield washer jar and pump with the
3 bolts.
(b) Connect the connectors.
4. FILL UP WASHER JAR AND PUMP ASSEMBLY WITH
WASHER FLUID
(a) Connect the washer hoses to the washer motor and
pump, and fill the washer jar with washer fluid.
5. INSTALL FRONT BUMPER COVER (See page ET-11)
6. INSTALL RADIATOR SUPPORT OPENING COVER
(See page ET-12)
7. INSTALL FRONT FENDER LINER LH (See page ET-
12)
8. INSTALL FRONT FENDER LINER RH (See page ET-
12)
9. INSTALL WASHER INLET SUB-ASSEMBLY
(a) Install the washer inlet of the washer jar and pump
to the windshield washer jar and pump.
(b) Install the washer inlet of the washer jar and pump
with the clip.
10. CONNECT CABLE TO NEGATIVE BATTERY
TERMINAL
B133945
B133129
B133130
Page 1901 of 2000
DOOR LOCK – POWER DOOR LOCK CONTROL SYSTEMDL–5
DL
HOW TO PROCEED WITH
TROUBLESHOOTING
HINT:
• Use the procedure to troubleshoot the power door lock
control system.
• *: Use the Intelligent tester.
NEXT
Standard voltage:
11 to 14 V
If the voltage is below 11 V, recharge or replace the battery
before proceeding.
NEXT
Result
B
A
(a) Operation Check (see page DL-6 ).
(b) Terminals of ECU (see page DL-8).
(c) DATA LIST / ACTIVE TEST (see page DL-12).
NEXT
NEXT
1VEHICLE BROUGHT TO WORKSHOP
2INSPECT BATTERY VOLTAGE
3PROBLEM SYMPTOMS TABLE
Result Proceed to
Fault is not listed in problem symptoms table A
Fault is listed on problem symptoms table B
Go to step 5
4OVERALL ANALYSIS AND TROUBLESHOOTING*
5ADJUST, REPAIR OR REPLACE
Page 1902 of 2000
DL–6DOOR LOCK – POWER DOOR LOCK CONTROL SYSTEM
DL
NEXT
6CONFIRMATION TEST
END
Page 1903 of 2000

DOOR LOCK – POWER DOOR LOCK CONTROL SYSTEMDL–7
DL
OPERATION CHECK
1. CHECK ELECTRICAL DOOR LOCK OPERATION
(a) Check the basic function.
(1) Check that all doors lock when the door control
switch (for manual operation) is turned to LOCK
and all doors unlock when turned to UNLOCK.
(2) Check that all doors lock when the driver side
door lock key cylinder is turned to LOCK using
the key.
(3) Check that only the driver side door unlocks
when the driver side door lock key cylinder is
turned to UNLOCK and all doors unlock when
turned to UNLOCK once again within 3 seconds
using the key (2-step unlocking function).
(b) Check the key lock-in prevention.
NOTICE:
In order to prevent the key from being actually
locked-in, the inspection should be made with
the driver side door window open.
(1) Have the key inserted into the ignition key
cylinder.
(2) With the driver side door open, check that all
doors unlock immediately after the door lock
knob for the driver side door is turned to LOCK.
(3) With the driver side door open, check that all
doors unlock immediately after the door control
switch (for manual operation) is turned to LOCK.
(4) With the driver side door open, turn the driver
side door lock knob to LOCK and hold it for 2
seconds or more, and then close the driver side
door. Then check that all doors unlock.
Page 1904 of 2000
DL–8DOOR LOCK – POWER DOOR LOCK CONTROL SYSTEM
DL
CUSTOMIZE PARAMETERS
1. CUSTOMIZING FUNCTION WITH INTELLIGENT
TESTER (REFERENCE)
HINT:
The following item can be customized.
NOTICE:
• When the customer requests a change in a
function, first make sure that the function can be
customized.
• Make a note of the current settings before
customizing.
• When troubleshooting a function, first make sure
that the function is set to the default setting.
Power door lock control system:
Display (Item) Default Function Setting
UNLK/KEY TWICE ON Unlocks only driver side door
when driver side door key
cylinder turned to unlock once,
and unlocks all doors when
turned to unlock twice. For OFF
setting, turning it once unlocks all
doors.ON/OFF
