Page 1113 of 2000

TOYOTA RAV4 2006 Service Repair Manual U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–239 AX 65. INSTALL NO. 1 GOVERNOR APPLY GASKET (a) Coat a new governor apply gasket with ATF, and install it to the transaxle case. NOTICE

Page 1114 of 2000

TOYOTA RAV4 2006 Service Repair Manual AX–240U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX NOTICE: • Push the valve body against the accumulator piston spring and the check ball body to install the valve body. • When

Page 1115 of 2000

TOYOTA RAV4 2006 Service Repair Manual U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–241 AX 71. INSTALL NO. 1 TRANSAXLE CASE PLUG (a) Coat 4 new O-rings with ATF, and install them to the 4 plugs. (b) Install the 4 plugs to

Page 1116 of 2000

TOYOTA RAV4 2006 Service Repair Manual AX–242U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX 77. INSTALL PARK/NEUTRAL POSITION SWITCH ASSEMBLY (a) Install the switch to the manual valve shaft. (b) Temporarily install the 2 b

Page 1117 of 2000

TOYOTA RAV4 2006 Service Repair Manual U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–243 AX (j) Install the control shaft lever with the washer and nut. Torque: 13 N*m (130 kgf*cm, 9 ft.*lbf) 78. INSTALL SPEEDOMETER DRIVEN

Page 1118 of 2000

TOYOTA RAV4 2006 Service Repair Manual AX–248U151E AUTOMATIC TRANSAXLE – OIL PUMP AX REASSEMBLY 1. INSTALL FRONT OIL PUMP OIL SEAL (a) Using SST and a hammer, tap in a new oil seal to the oil pump body. SST 09350-32014 (09351-32140)

Page 1119 of 2000

TOYOTA RAV4 2006 Service Repair Manual U151E AUTOMATIC TRANSAXLE – OIL PUMPAX–249 AX 6. INSTALL CLUTCH DRUM OIL SEAL RING (a) Coat 2 new oil seal rings with ATF. (b) Install 2 new clutch drum oil seal rings. NOTICE: Do not expand the

Page 1120 of 2000

TOYOTA RAV4 2006 Service Repair Manual AX–252U151E AUTOMATIC TRANSAXLE – SECOND BRAKE PISTON AX REASSEMBLY 1. INSTALL 2ND BRAKE PISTON O-RING (a) Coat 2 new O-rings with ATF, and install them in the 2nd brake piston. NOTICE: Make su
