Page 1193 of 2000

TOYOTA RAV4 2006 Service Repair Manual U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–215 AX Standard bearing position 2. INSTALL DIFFERENTIAL GEAR LUBE APPLY TUBE (a) Install the differential gear lube apply tube and transa

Page 1194 of 2000

TOYOTA RAV4 2006 Service Repair Manual AX–216U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX 4. INSTALL UNDERDRIVE OUTPUT SHAFT OIL SEAL RING (a) Coat a new oil seal ring with ATF and install it to the transaxle housing. 5.

Page 1195 of 2000

TOYOTA RAV4 2006 Service Repair Manual U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–217 AX 8. INSTALL UNDERDRIVE BRAKE PISTON (a) Coat 2 new O-rings with ATF, and install them to the underdrive brake piston. NOTICE: • Ma

Page 1196 of 2000

TOYOTA RAV4 2006 Service Repair Manual AX–218U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX (c) Using a snap ring expander, install the snap ring. NOTICE: The white mark side of the snap ring should face upward. 12. INSTALL

Page 1197 of 2000

TOYOTA RAV4 2006 Service Repair Manual U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–219 AX (c) Coat the 1st and reverse brake piston with ATF, and install it to the transaxle case. NOTICE: Be careful not to damage the O-ri

Page 1198 of 2000

TOYOTA RAV4 2006 Service Repair Manual AX–220U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX (b) Using SST and a press, press-fit the front planetary gear. SST 09950-60010 (09951-00500), 09950-70010 (09951-07100) NOTICE:

Page 1199 of 2000

TOYOTA RAV4 2006 Service Repair Manual U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–221 AX (f) Tighten the nut gradually until the specified turning torque of the tapered roller bearing is measured. Torque: 350 N*m (3,569

Page 1200 of 2000

TOYOTA RAV4 2006 Service Repair Manual AX–222U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX (b) Using a screwdriver, install the snap ring. NOTICE: Confirm that the snap ring is fixed in the groove of the 1st and reverse br
