TOYOTA RAV4 2006 Service Repair Manual SEAT BELT – FRONT SEAT OUTER BELT ASSEMBLYSB–33 SB (2) Press the SST activation switch and check that the LED of the SST activation switch illuminates. CAUTION: If the LED illuminates when the

Page 1770 of 2000

TOYOTA RAV4 2006 Service Repair Manual SB–34SEAT BELT – FRONT SEAT OUTER BELT ASSEMBLY SB (2) Press the SST activation switch to activate the seat belt pretensioner. HINT: The seat belt pretensioner operates at the same time the SS

Page 1771 of 2000

TOYOTA RAV4 2006 Service Repair Manual SEAT BELT – FRONT SEAT OUTER BELT ASSEMBLYSB–35 SB (b) Check if SST is functioning properly. SST 09082-00700, 09082-00770 CAUTION: When activating a seat belt pretensioner, always use the speci

Page 1772 of 2000

TOYOTA RAV4 2006 Service Repair Manual SB–36SEAT BELT – FRONT SEAT OUTER BELT ASSEMBLY SB (e) Dispose of the front seat outer belt (with the seat belt pretensioner). CAUTION: • Do not touch the front seat outer belt for at least

Page 1773 of 2000

TOYOTA RAV4 2006 Service Repair Manual SEAT BELT – REAR SEAT INNER BELT ASSEMBLYSB–39 SB REMOVAL 1. REMOVE REAR SEAT LEG COVER 2. REMOVE REAR NO. 2 SEAT LEG SIDE COVER 3. REMOVE REAR NO. 3 SEAT LEG SIDE COVER (w/ Rear No. 2 Seat) (S

Page 1774 of 2000

TOYOTA RAV4 2006 Service Repair Manual SB–40SEAT BELT – REAR SEAT INNER BELT ASSEMBLY SB 12. REMOVE REAR SEAT INNER BELT ASSEMBLY RH (for 60/40 Split Seat Type LH Side) (a) Remove the bolt and the seat belt. 13. REMOVE REAR NO. 1 SE

Page 1775 of 2000

TOYOTA RAV4 2006 Service Repair Manual SEAT BELT – REAR SEAT INNER BELT ASSEMBLYSB–41 SB 4. INSTALL NO. 2 SEAT LEG COVER (w/ Rear No. 2 Seat) (See page SE-123) 5. INSTALL NO. 2 SEAT HINGE COVER (w/ Rear No. 2 Seat) (See page SE-123

Page 1776 of 2000

TOYOTA RAV4 2006 Service Repair Manual SB–42SEAT BELT – REAR SEAT INNER BELT ASSEMBLY SB 12. INSTALL REAR SEAT LAP TYPE BELT ASSEMBLY CENTER RH (w/o Rear No. 2 Seat) (a) Install the belt with the bolt. Torque: 42 N*m (428 kgf*cm, 31
