Page 1713 of 2000

TOYOTA RAV4 2006 Service Repair Manual RS–64SUPPLEMENTAL RESTRAINT SYSTEM – AIRBAG SYSTEM RS (a) Connect the cable to the negative (-) battery terminal, and wait for at least 2 seconds. (b) Turn the ignition switch ON. (c) Measure t

Page 1714 of 2000

TOYOTA RAV4 2006 Service Repair Manual SUPPLEMENTAL RESTRAINT SYSTEM – AIRBAG SYSTEMRS–65 RS (a) Turn the ignition switch OFF. (b) Disconnect the cable from the negative (-) battery terminal, and wait for at least 90 seconds. (c) Me

Page 1715 of 2000

TOYOTA RAV4 2006 Service Repair Manual RS–66SUPPLEMENTAL RESTRAINT SYSTEM – AIRBAG SYSTEM RS (a) Connect the connectors to the center airbag sensor . (b) Interchange the front airbag sensor RH and LH, and connect the connectors to t

Page 1716 of 2000

TOYOTA RAV4 2006 Service Repair Manual SUPPLEMENTAL RESTRAINT SYSTEM – AIRBAG SYSTEMRS–67 RS (a) Disconnect the service wire from connector E. (b) Disconnect the engine room main wire connector from the instrument panel wire. (c) Us

Page 1717 of 2000

TOYOTA RAV4 2006 Service Repair Manual RS–68SUPPLEMENTAL RESTRAINT SYSTEM – AIRBAG SYSTEM RS (a) Disconnect the engine room main wire connector from the instrument panel wire. (b) Disconnect the service wire from connector E. (c) Me

Page 1718 of 2000

TOYOTA RAV4 2006 Service Repair Manual SUPPLEMENTAL RESTRAINT SYSTEM – AIRBAG SYSTEMRS–69 RS (a) Turn the ignition switch OFF. (b) Disconnect the cable from the negative (-) battery terminal, and wait for at least 90 seconds. (c) Di

Page 1719 of 2000

TOYOTA RAV4 2006 Service Repair Manual RS–70SUPPLEMENTAL RESTRAINT SYSTEM – AIRBAG SYSTEM RS (a) Disconnect the engine room main wire connector from the instrument panel wire. (b) Measure the resistance of the wire harness side con

Page 1720 of 2000

TOYOTA RAV4 2006 Service Repair Manual SUPPLEMENTAL RESTRAINT SYSTEM – AIRBAG SYSTEMRS–71 RS DESCRIPTION The front airbag sensor LH consists of the diagnostic circuit and the frontal deceleration sensor. If the center airbag sensor r
