TOYOTA RAV4 2006 Service Repair Manual RS–48SUPPLEMENTAL RESTRAINT SYSTEM – AIRBAG SYSTEM
RS
C128725E05

Page 1698 of 2000

TOYOTA RAV4 2006 Service Repair Manual SUPPLEMENTAL RESTRAINT SYSTEM – AIRBAG SYSTEMRS–49
RS
H100199E06

Page 1699 of 2000

TOYOTA RAV4 2006 Service Repair Manual RS–50SUPPLEMENTAL RESTRAINT SYSTEM – AIRBAG SYSTEM
RS
DTC CHECK / CLEAR
1. CHECK DTC (USING SST (CHECK WIRE))
(a) Check the DTCs (Present trouble code).
(1) Turn the ignition switch ON, and wait

Page 1700 of 2000

TOYOTA RAV4 2006 Service Repair Manual SUPPLEMENTAL RESTRAINT SYSTEM – AIRBAG SYSTEMRS–51
RS
(c) Read the DTCs.
(1) Read the blinking patterns of the DTCs. As
examples, the blinking patterns for the normal
system code and DTCs 11 a

Page 1701 of 2000

TOYOTA RAV4 2006 Service Repair Manual RS–52SUPPLEMENTAL RESTRAINT SYSTEM – AIRBAG SYSTEM
RS
(6) The SRS warning light comes on again within 2
to 4 seconds after disconnecting terminal
13(TC). Then, reconnect terminals 13(TC) and

Page 1702 of 2000

TOYOTA RAV4 2006 Service Repair Manual SUPPLEMENTAL RESTRAINT SYSTEM – AIRBAG SYSTEMRS–53
RS
3. CHECK DTC (USING INTELLIGENT TESTER)
(a) Connect the intelligent tester (with CAN VIM) to the
DLC3.
(b) Turn the ignition switch ON.
(c)

Page 1703 of 2000

TOYOTA RAV4 2006 Service Repair Manual RS–54SUPPLEMENTAL RESTRAINT SYSTEM – AIRBAG SYSTEM
RS
DATA LIST / ACTIVE TEST
1. READ DATA LIST
HINT:
Using the intelligent tester's Data List allows switch,
sensor, actuator and other item

Page 1704 of 2000

TOYOTA RAV4 2006 Service Repair Manual SUPPLEMENTAL RESTRAINT SYSTEM – AIRBAG SYSTEMRS–55
RS
DIAGNOSTIC TROUBLE CODE CHART
If a DTC is displayed during the DTC check, check the circuit
listed for the DTC in the table below (refer to

SUPPLEMENTAL RESTRAINT SYSTEM – AIRBAG SYSTEMRS–55
RS
DIAGNOSTIC TROUBLE CODE CHART
If a DTC is displayed during the DTC check, check the circuit
listed for the DTC in the table below (refer to the appropriate
page).
HINT:
• When the SRS warning light remains on and the normal
system code is output, a decrease in the source voltage is
likely to occur. This malfunction is not stored in the
memory of the center airbag sensor. If the power source
voltage returns to normal, the SRS warning light will
automatically go off.
• When 2 or more DTCs are indicated, the DTC with the
lowest number appears first.
• If a DTC is not listed on the DTC chart, the center airbag
sensor may have malfunctioned.
• In the case of any malfunctions concerning open circuits,
shorts to ground, or shorts to B+ due to squibs, other
DTCs may not be set. In this case, repair the malfunction
currently indicated and then perform a malfunction
diagnosis again.
• Mark in the check mode column:
-: DTC does not correspond to check mode.
: DTC corresponds to check mode.
• When DTC B1650/32 is set as a result of troubleshooting
the Supplemental Restraint System (SRS), perform
troubleshooting for the occupant classification system.
Airbag System
DTC No. Detection Item Check Mode SRS Warning Light See Page
B1000/31 Center Airbag Sensor
Assembly Malfunction-ONRS-58
B1602/83 Lost Communication with
Front Satellite Sensor Bus
RH-ONRS-59
B1603/83 Front Satellite Sensor Bus
RH Initialization
Incomplete-ONRS-59
B1607/84 Lost Communication with
Front Satellite Sensor Bus
LH-ONRS-70
B1608/84 Front Satellite Sensor Bus
LH Initialization
Incomplete-ONRS-70
B1610/13 Front Airbag Sensor RH
Circuit Malfunction-ONRS-81
B1612/83 Lost Communication with
Front Airbag Sensor RH-ONRS-59
B1613/83 Front Airbag Sensor RH
Initialization Incomplete-ONRS-59
B1615/14 Front Airbag Sensor LH
Circuit Malfunction-ONRS-83
B1617/84 Lost Communication with
Front Airbag Sensor LH-ONRS-70
B1618/84 Front Airbag Sensor LH
Initialization Incomplete-ONRS-70
B1620/21 Driver Side - Side Airbag
Sensor Circuit Malfunction-ONRS-85
