Page 769 of 2000

TOYOTA RAV4 2006 Service Repair Manual 2AZ-FE FUEL – FUEL INJECTORFU–9 FU REMOVAL 1. DISCHARGE FUEL SYSTEM PRESSURE CAUTION: • DISCHARGE FUEL SYSTEM PRESSURE procedures must be performed before disconnecting any part of the fuel

Page 770 of 2000

TOYOTA RAV4 2006 Service Repair Manual FU–102AZ-FE FUEL – FUEL INJECTOR FU 5. DISCONNECT FUEL MAIN TUBE NOTICE: Do not forcibly bend and twist the fuel main tube. (a) Remove the fuel tube from the fuel hose clamp. (b) Remove the fuel

Page 771 of 2000

TOYOTA RAV4 2006 Service Repair Manual 2AZ-FE FUEL – FUEL INJECTORFU–11 FU (c) Remove the 2 bolts, then remove the fuel delivery pipe together with the 4 fuel injectors. NOTICE: Be careful not to drop the fuel injectors when removi

Page 772 of 2000

TOYOTA RAV4 2006 Service Repair Manual FU–122AZ-FE FUEL – FUEL INJECTOR FU (3) Connect SST (adapter and hose) to the injector, and hold the injector and union with SST (clamp). SST 09268-31011 (09268-41110, 09268- 41130, 09268-4131

Page 773 of 2000

TOYOTA RAV4 2006 Service Repair Manual 2AZ-FE FUEL – FUEL INJECTORFU–13 FU (b) Apply a light coat of gasoline or spindle oil to the part of the fuel delivery pipe which comes into contact with the O-ring of the fuel injector. (c) A

Page 774 of 2000

TOYOTA RAV4 2006 Service Repair Manual FU–142AZ-FE FUEL – FUEL INJECTOR FU (f) Connect the 4 fuel injector connectors. (g) Install the 2 wire harness clamps. 3. CONNECT NO. 2 VENTILATION HOSE (a) Connect the ventilation hose to the v

Page 775 of 2000

TOYOTA RAV4 2006 Service Repair Manual 2AZ-FE FUEL – FUEL PRESSURE REGULATORFU–17 FU REMOVAL 1. REMOVE FUEL TANK ASSEMBLY (a) Remove the fuel tank (see page FU-39). 2. REMOVE FUEL TANK MAIN TUBE SUB-ASSEMBLY (a) Remove the joint clip

Page 776 of 2000

TOYOTA RAV4 2006 Service Repair Manual FU–182AZ-FE FUEL – FUEL PRESSURE REGULATOR FU (b) Remove the gasket from the fuel pump. 5. REMOVE FUEL SUB-TANK ASSEMBLY (a) Disconnect the wire harness. (b) Using needle nose pliers, remove the
