Page 1177 of 2000

TOYOTA RAV4 2006 Service Repair Manual U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–199 AX (b) Remove the parking lock pawl shaft. (c) Push the parking lock pawl. HINT: Failure to do so will cause interference when the und

Page 1178 of 2000

TOYOTA RAV4 2006 Service Repair Manual AX–200U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX 41. REMOVE UNDERDRIVE 1-WAY CLUTCH ASSEMBLY (a) Using a screwdriver, remove the snap ring from the transaxle case. NOTICE: Do not a

Page 1179 of 2000

TOYOTA RAV4 2006 Service Repair Manual U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–201 AX 44. REMOVE TRANSAXLE REAR COVER SUB- ASSEMBLY (a) Remove the 11 bolts. (b) Tap on the circumference of the rear cover with a plasti

Page 1180 of 2000

TOYOTA RAV4 2006 Service Repair Manual AX–202U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX 49. REMOVE BRAKE APPLY TUBE (a) Remove the bolt, clamp and brake apply tube. (b) Remove the clutch apply tube. (c) Remove the brake

Page 1181 of 2000

TOYOTA RAV4 2006 Service Repair Manual U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–203 AX (c) Remove the planetary carrier thrust washer from the rear planetary sun gear. 54. REMOVE 1-WAY CLUTCH ASSEMBLY (a) Remove the 1-

Page 1182 of 2000

TOYOTA RAV4 2006 Service Repair Manual AX–204U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX 57. REMOVE 2ND BRAKE CLUTCH DISC (a) Using a screwdriver, remove the snap ring. (b) Remove the flange, 4 discs and 4 plates from the

Page 1183 of 2000

TOYOTA RAV4 2006 Service Repair Manual U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–205 AX 61. REMOVE INPUT SUN GEAR (a) Remove the 2 thrust needle roller bearings, thrust bearing race and the input sun gear from the tran

Page 1184 of 2000

TOYOTA RAV4 2006 Service Repair Manual AX–206U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX (d) Remove the front planetary gear from the brake hub. 65. REMOVE FRONT PLANETARY RING GEAR (a) Using a screwdriver, remove the sn
