Page 1065 of 2000

TOYOTA RAV4 2006 Service Repair Manual U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–191 AX 10. INSPECT TRANSMISSION OIL CLEANER MAGNET (a) Remove the magnets and use them to collect any steel chips. Examine the chips and p

Page 1066 of 2000

TOYOTA RAV4 2006 Service Repair Manual AX–192U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX 13. REMOVE TRANSMISSION VALVE BODY ASSEMBLY (a) Support the valve body and remove the 17 bolts and valve body. 14. REMOVE NO. 1 GOV

Page 1067 of 2000

TOYOTA RAV4 2006 Service Repair Manual U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–193 AX 18. REMOVE C-3 ACCUMULATOR PISTON (a) Remove the spring from the C-3 accumulator piston. (b) Apply compressed air (392 kPa, 4.0 kgf

Page 1068 of 2000

TOYOTA RAV4 2006 Service Repair Manual AX–194U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX 20. REMOVE B-3 ACCUMULATOR PISTON (a) Apply compressed air (392 kPa, 4.0 kgf/cm 2, 57 psi) to the oil hole and remove the B-3 accum

Page 1069 of 2000

TOYOTA RAV4 2006 Service Repair Manual U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–195 AX 24. REMOVE MANUAL VALVE LEVER SUB-ASSEMBLY (a) Using a chisel and hammer, cut off and remove the spacer. (b) Using a pin punch ( 35

Page 1070 of 2000

TOYOTA RAV4 2006 Service Repair Manual AX–196U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX 29. REMOVE TRANSAXLE HOUSING (a) Remove the 16 bolts. (b) Tap on the circumference of the transaxle housing with a plastic-faced ha

Page 1071 of 2000

TOYOTA RAV4 2006 Service Repair Manual U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–197 AX 34. REMOVE OVERDRIVE BRAKE GASKET (a) Remove the 2 overdrive brake gaskets from the transaxle case. 35. REMOVE FORWARD CLUTCH ASSEM

Page 1072 of 2000

TOYOTA RAV4 2006 Service Repair Manual AX–198U151E AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX (b) Remove the parking lock pawl shaft. (c) Push the parking lock pawl. HINT: Failure to do so will cause interference when the und
