Page 1169 of 2000

TOYOTA RAV4 2006 Service Repair Manual U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–191 AX 5. REMOVE SPEED SENSOR (a) Remove the 2 bolts and the 2 speed sensors from the transaxle. 6. REMOVE NO. 1 TRANSAXLE CASE PLUG (a) R

Page 1170 of 2000

TOYOTA RAV4 2006 Service Repair Manual AX–192U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX 10. INSPECT TRANSMISSION OIL CLEANER MAGNET (a) Remove the magnets and use them to collect any steel chips. Examine the chips and p

Page 1171 of 2000

TOYOTA RAV4 2006 Service Repair Manual U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–193 AX 13. REMOVE TRANSMISSION VALVE BODY ASSEMBLY (a) Support the valve body and remove the 17 bolts and valve body. 14. REMOVE NO. 1 GOV

Page 1172 of 2000

TOYOTA RAV4 2006 Service Repair Manual AX–194U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX 18. REMOVE C-3 ACCUMULATOR PISTON (a) Remove the spring from the C-3 accumulator piston. (b) Apply compressed air (392 kPa, 4.0 kgf

Page 1173 of 2000

TOYOTA RAV4 2006 Service Repair Manual U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–195 AX 20. REMOVE B-3 ACCUMULATOR PISTON (a) Apply compressed air (392 kPa, 4.0 kgf/cm 2, 57 psi) to the oil hole and remove the B-3 accum

Page 1174 of 2000

TOYOTA RAV4 2006 Service Repair Manual AX–196U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX 24. REMOVE MANUAL VALVE LEVER SUB-ASSEMBLY (a) Using a chisel and hammer, cut off and remove the spacer. (b) Using a pin punch ( 35

Page 1175 of 2000

TOYOTA RAV4 2006 Service Repair Manual U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNITAX–197 AX 29. REMOVE TRANSAXLE HOUSING (a) Remove the 16 bolts. (b) Tap on the circumference of the transaxle housing with a plastic-faced ha

Page 1176 of 2000

TOYOTA RAV4 2006 Service Repair Manual AX–198U151F AUTOMATIC TRANSAXLE – AUTOMATIC TRANSAXLE UNIT AX 34. REMOVE OVERDRIVE BRAKE GASKET (a) Remove the 2 overdrive brake gaskets from the transaxle case. 35. REMOVE FORWARD CLUTCH ASSEM
