TOYOTA RAV4 2006 Service Repair Manual RS–80SUPPLEMENTAL RESTRAINT SYSTEM – AIRBAG SYSTEM RS (a) Turn the ignition switch OFF. (b) Disconnect the cable from the negative (-) battery terminal, and wait for at least 90 seconds. (c) Di

Page 1730 of 2000

TOYOTA RAV4 2006 Service Repair Manual SUPPLEMENTAL RESTRAINT SYSTEM – AIRBAG SYSTEMRS–81 RS (a) Disconnect the engine room main wire connector from the instrument panel wire. (b) Measure the resistance of the wire harness side con

Page 1731 of 2000

TOYOTA RAV4 2006 Service Repair Manual RS–82SUPPLEMENTAL RESTRAINT SYSTEM – AIRBAG SYSTEM RS DESCRIPTION The front airbag sensor RH consists of the diagnostic circuit, the frontal deceleration sensor, etc. If the center airbag sensor

Page 1732 of 2000

TOYOTA RAV4 2006 Service Repair Manual SUPPLEMENTAL RESTRAINT SYSTEM – AIRBAG SYSTEMRS–83 RS INSPECTION PROCEDURE (a) Turn the ignition switch OFF. (b) Disconnect the cable from the negative (-) battery terminal, and wait for at lea

Page 1733 of 2000

TOYOTA RAV4 2006 Service Repair Manual RS–84SUPPLEMENTAL RESTRAINT SYSTEM – AIRBAG SYSTEM RS DESCRIPTION The front airbag sensor LH consists of the diagnostic circuit, the frontal deceleration sensor, etc. If the center airbag sensor

Page 1734 of 2000

TOYOTA RAV4 2006 Service Repair Manual SUPPLEMENTAL RESTRAINT SYSTEM – AIRBAG SYSTEMRS–85 RS INSPECTION PROCEDURE (a) Turn the ignition switch OFF. (b) Disconnect the cable from the negative (-) battery terminal, and wait for at lea

Page 1735 of 2000

TOYOTA RAV4 2006 Service Repair Manual RS–386SUPPLEMENTAL RESTRAINT SYSTEM – REAR AIRBAG SENSOR RS REMOVAL HINT: • Use the same procedures for the RH side and LH side. • The procedures listed below are for the LH side. CAUTION: B

Page 1736 of 2000

TOYOTA RAV4 2006 Service Repair Manual SUPPLEMENTAL RESTRAINT SYSTEM – REAR AIRBAG SENSORRS–387 RS 20. REMOVE RECLINING REMOTE CONTROL LEVER BEZEL LH (w/o Rear No. 2 Seat) 21. DISCONNECT REAR NO. 1 SEAT OUTER BELT ASSEMBLY LH (See
