Page 297 of 2896
AT-284
DISASSEMBLY
Revision: June 20062007 Versa
48. Remove return spring (2) from parking shaft (3) using a flat-
bladed screwdriver.
(1): Parking pawl
Inspect return spring (2), and replace if damaged or worn.
49. Draw out parking shaft (1), and then remove parking pawl (2)
from transaxle case.
Inspect parking shaft (1) and parking pawl (2), and
replace if damaged or worn.
50. Remove parking actuator support (1) from transaxle case.
Inspect parking actuator support (1), and replace if dam-
aged or worn.
51. Remove snap ring from transaxle case using a flat-bladed
screwdriver.
52. Remove governor cap from transaxle case.
53. Remove O-ring from governor cap.
54. Remove LH differential side oil seal from transaxle case using a
flat-bladed screwdriver.
CAUTION:
Be careful not to scratch transaxle case.
SCIA6996E
SCIA6997E
SCIA6998E
ATM0076D
Page 298 of 2896
REPAIR FOR COMPONENT PARTS
AT-285
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: June 20062007 Versa
REPAIR FOR COMPONENT PARTSPFP:00000
Manual ShaftUCS005W 3
COMPONENTS
REMOVAL
1. Remove detent spring from transaxle case.
2. Drive out retaining pin of manual plate using the pin punch.
1. Manual shaft oil seal 2. Parking rod 3. Retaining pin
4. Parking rod plate 5. Retaining pin 6. Manual plate
7. Manual shaft 8. Detent spring 9. Retaining pin
Refer to GI section to make sure icons (symbol marks) in the figure. Refer to GI-10, "
Components" .
SCIA5907J
SAT3 1 3G
SCIA5381E
Page 299 of 2896
AT-286
REPAIR FOR COMPONENT PARTS
Revision: June 20062007 Versa
3. Pull out retaining pin (2) of parking rod plate (1) using nippers.
4. Pull out retaining pin (1) of manual shaft using nippers.
5. Remove parking rod plate (with parking rod) (3) from manual
shaft (1).
6. Remove parking rod from parking rod plate (3).
7. Remove manual plate (2) from manual shaft (1).
8. Draw out manual shaft (1) from transaxle case.
9. Remove manual shaft oil seal from transaxle case using a flat-
bladed screwdriver.
CAUTION:
Be careful not to scratch transaxle case.
INSPECTION
Check component parts, and replace if damaged or worn.
SCIA5806J
SCIA6514J
SCIA7005E
SAT0 8 0D
Page 300 of 2896

REPAIR FOR COMPONENT PARTS
AT-287
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: June 20062007 Versa
INSTALLATION
1. Drive manual shaft oil seal into transaxle case using a drift [com-
mercial service tool: 22 mm (0.87 in) dia.].
CAUTION:
Do not reuse manual shaft oil seal.
Apply ATF to outer surface of manual shaft oil seal.
2. Install parking rod to parking rod plate.
3. Insert manual shaft (1) to transaxle case, and install manual
plate (2) to manual shaft (1).
4. Install parking rod plate (with parking rod) (3) to manual shaft
(1).
5. Align groove of manual shaft and hole of transaxle case using a
pin punch A [commercial service tool: 2 mm (0.08 in) dia.].
6. Drive retaining pin of manual shaft into transaxle case using Tool
B.
CAUTION:
Do not reuse retaining pin.
7. Set parking rod plate (1) onto manual shaft, and drive retaining
pin (2) of parking rod plate (1).
CAUTION:
The retaining pin end should protrude approx. 3mm (0.12
in) (B) from the outer surface of parking rod plate (1).
SAT0 8 1D
SCIA7005E
Tool number: ST23540000 (J-25689-A)
SCIA7006E
Tool number: ST23540000 (J-25689-A)
SCIA7107E
Page 301 of 2896
AT-288
REPAIR FOR COMPONENT PARTS
Revision: June 20062007 Versa
8. Set manual plate (1) onto manual shaft, and drive retaining pin
(2) of manual plate (1).
CAUTION:
The retaining pin end should protrude approx. 3mm (0.12
in) (B) from the outer surface of manual plate (1).
9. Install detent spring on transaxle case.
10. Tighten detent spring fitting bolt to the specified torque. Refer to
AT-285, "
COMPONENTS" . Tool number: ST23540000 (J-25698-A)
SCIA7108E
SAT0 4 2F
Page 302 of 2896
REPAIR FOR COMPONENT PARTS
AT-289
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: June 20062007 Versa
Oil PumpUCS005W 4
COMPONENTS
DISASSEMBLY
1. Remove seal rings (1) from oil pump assembly (2).
2. Remove bolts in the order as shown in the figure, and remove oil
pump cover.
1. Oil pump housing oil seal 2. Oil pump housing 3. Outer gear
4. Inner gear 5. Oil pump cover 6. Seal ring
Refer to GI section to make sure icons (symbol marks) in the figure. Refer to GI-10, "
Components" .
SCIA5908J
SCIA7016E
SAT0 9 1D
Page 303 of 2896
AT-290
REPAIR FOR COMPONENT PARTS
Revision: June 20062007 Versa
3. Remove inner gear and outer gear from oil pump housing.
4. Remove oil pump housing oil seal using a flat-bladed screw-
driver.
CAUTION:
Be careful not to scratch oil pump housing.
SAT0 9 2D
SCIA2840E
Page 304 of 2896

REPAIR FOR COMPONENT PARTS
AT-291
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: June 20062007 Versa
INSPECTION
Oil Pump Housing, Oil Pump Cover, Inner Gear and Outer Gear
Check for wear or damage. Replace if necessary.
Side Clearances
Measure side clearance of inner gear and outer gear in at least
four places around each outside edge. Clearances measured
values should be within the specified clearance.
If clearance is less than standard, select inner gear and outer
gear as a set so that clearance is within specifications. Refer to
“Parts Information” for the inner gear and outer gear selection.
If clearance is more than standard, replace whole oil pump
assembly except oil pump cover.
Measure clearance between outer gear and oil pump housing.
If not within allowable limit, replace whole oil pump assembly
except oil pump cover.
Seal Ring Clearance
Measure clearance between seal ring and ring groove.
If not within allowable limit, replace oil pump cover assembly.Standard clearance: Refer to AT- 3 8 2 , "
Oil Pump" .
SCIA4957E
Standard clearance and allowable limit:
Refer to AT-382, "
Oil Pump" .
SAT0 9 6D
Standard clearance and allowable limit:
Refer to AT-382, "
Oil Pump" .
SAT0 9 7D
