NISSAN VERSA 2006 Workshop Service Repair Manual EC-152Revision: June 2006
DTC U1000, U1001 CAN COMMUNICATION LINE
2007 Versa
Wiring DiagramUBS00QC0
BBWA2626E

Page 1322 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual DTC U1000, U1001 CAN COMMUNICATION LINE
EC-153
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: June 20062007 Versa
Diagnostic ProcedureUBS00QC1
Go to LAN-47, "CAN System Specification Chart" .

Page 1323 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual EC-154Revision: June 2006
DTC U1010 CAN COMMUNICATION
2007 Versa
DTC U1010 CAN COMMUNICATIONPFP:23710
DescriptionUBS00QC2
CAN (Controller Area Network) is a serial communication line for real time app

Page 1324 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual DTC U1010 CAN COMMUNICATION
EC-155
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: June 20062007 Versa
Diagnostic ProcedureUBS00QC5
1. INSPECTION START
With CONSULT-II
1. Turn ignition switch ON.
2. Select “SE

Page 1325 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual EC-156Revision: June 2006
DTC P0011 IVT CONTROL
2007 Versa
DTC P0011 IVT CONTROLPFP:23796
DescriptionUBS00QC6
SYSTEM DESCRIPTION
*: This signal is sent to the ECM through CAN communication line.
This

Page 1326 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual DTC P0011 IVT CONTROL
EC-157
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: June 20062007 Versa
On Board Diagnosis LogicUBS00QC8
FAIL-SAFE MODE
ECM enters in fail-safe mode when the malfunction is detected.
DTC

DTC P0011 IVT CONTROL
EC-157
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: June 20062007 Versa
On Board Diagnosis LogicUBS00QC8
FAIL-SAFE MODE
ECM enters in fail-safe mode when the malfunction is detected.
DTC Confirmation ProcedureUBS00QC9
CAUTION:
Always drive at a safe speed.
NOTE:
If DTC P0011 is displayed with DTC P0075, first perform trouble diagnosis for DTC P0075.
See EC-173, "
DTC P0075 IVT CONTROL SOLENOID VALVE" .
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait
at least 10 seconds before conducting the next test.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is between 10V and 16V at
idle.
WITH CONSULT-II
1. Turn ignition switch ON and select “DATA MONITOR” mode with
CONSULT-II.
2. Start engine and warm it up to the normal operating tempera-
ture.
3. Maintain the following conditions for at least 6 consecutive sec-
onds.
Hold the accelerator pedal as steady as possible.
4. Let engine idle for 10 seconds.
5. If 1st trip DTC is detected, go to EC-158, "
Diagnostic Procedure" .
If 1st trip DTC is not detected, go to next step.
6. Maintain the following conditions for at least 20 consecutive seconds.
7. If 1st trip DTC is detected, go to EC-158, "
Diagnostic Procedure" .
DTC No. Trouble diagnosis name Detecting condition Possible cause
P0011
0011Intake valve timing control
performanceThere is a gap between angle of target and
phase-control angle degree.
Crankshaft position sensor (POS)
Camshaft position sensor (PHASE)
Intake valve timing control solenoid valve
Accumulation of debris to the signal pick-up
portion of the camshaft
Timing chain installation
Foreign matter caught in the oil groove for
intake valve timing control
Detected items Engine operating condition in fail-safe mode
Intake valve timing control The signal is not energized to the solenoid valve and the valve control does not function
ENG SPEED 2,000 rpm (A constant rotation is maintained.)
COOLAN TEMP/S More than 60°C (140°F)
B/FUEL SCHDL More than 3.87 msec
Shift lever P or N position (A/T, CVT)
Neutral position (M/T)
ENG SPEED 1,200 - 3,175 rpm (A constant rotation is maintained.)
COOLAN TEMP/S 70 - 105°C (158 - 221°F)
Shift lever 1st or 2nd position
Driving location uphillDriving vehicle uphill
(Increased engine load will help maintain the driving
conditions required for this test.)
PBIB0164E

Page 1327 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual EC-158Revision: June 2006
DTC P0011 IVT CONTROL
2007 Versa
WITH GST
Follow the procedure “WITH CONSULT-II” above.
Diagnostic ProcedureUBS00QCA
1. CHECK OIL PRESSURE WARNING LAMP
1. Start engine.

Page 1328 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual DTC P0011 IVT CONTROL
EC-159
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: June 20062007 Versa
6. CHECK TIMING CHAIN INSTALLATION
Check service records for any recent repairs that may cause timing chain misalig
