TROUBLE DIAGNOSIS FOR SYMPTOMS
STC-31
[EPS]
C
D
E
F
H
I
J
K
L
MA
B
STC
Revision: June 20062007 Versa
Unbalance Steering Wheel Turning Force and Return Between Right and LeftUGS0008V
SYMPTOM:
Unbalance steering wheel turning force and return between right and left, while driving.
DIAGNOSTIC PROCEDURE
1. CHECK EPS WARNING LAMP
Confirm EPS warning lamp during engine running.
Does EPS warning lamp turn OFF?
YES >> GO TO 2.
NO >> Go to STC-27, "
EPS Warning Lamp Does Not Turn OFF" .
2. CHECK WHEEL ALIGNMENT
Check wheel alignment. Refer to FSU-6, "
Wheel Alignment Inspection" .
OK or NG
OK >> GO TO 3.
NG >> Adjust wheel alignment. Refer to FSU-6, "
Wheel Alignment Inspection" .
3. CHECK EPS CONTROL UNIT
Check EPS control unit input/output signal. Refer to STC-11, "
EPS Control Unit Input/Output Signal Reference
Va lu e s" .
OK or NG
OK >> GO TO 4.
NG >> Check EPS control unit pin terminals for damage or loose connection with harness connector. If
any items are damaged, repair or replace damaged parts.
4. SYMPTOM CHECK
Check again.
OK or NG
OK >>INSPECTION END
NG >> Check the steering wheel turning force because there may be mechanical malfunction. Refer to
PS-6, "
CHECKING STEERING WHEEL TURNING FORCE" .
Page 2818 of 2896
![NISSAN VERSA 2006 Workshop Service Repair Manual STC-32
[EPS]
TROUBLE DIAGNOSIS FOR SYMPTOMS
Revision: June 20062007 Versa
Unbalance Steering Wheel Turning Force (Torque Variation)UGS0008W
SYMPTOM:
Unbalance steering wheel turning force, while drivi NISSAN VERSA 2006 Workshop Service Repair Manual STC-32
[EPS]
TROUBLE DIAGNOSIS FOR SYMPTOMS
Revision: June 20062007 Versa
Unbalance Steering Wheel Turning Force (Torque Variation)UGS0008W
SYMPTOM:
Unbalance steering wheel turning force, while drivi](/manual-img/5/57401/w960_57401-2817.png)
STC-32
[EPS]
TROUBLE DIAGNOSIS FOR SYMPTOMS
Revision: June 20062007 Versa
Unbalance Steering Wheel Turning Force (Torque Variation)UGS0008W
SYMPTOM:
Unbalance steering wheel turning force, while driving (Torque variation).
DIAGNOSTIC PROCEDURE
1. CHECK EPS WARNING LAMP
Confirm EPS warning lamp during engine running.
Does EPS warning lamp turn OFF?
YES >> GO TO 2.
NO >> Go to STC-27, "
EPS Warning Lamp Does Not Turn OFF" .
2. CHECK STEERING COLUMN INTERMEDIATE SHAFT
Check the connection between intermediate shaft and the mounting part of steering column assembly and
steering gear assembly. Refer to PS-9, "
COMPONENT" .
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
3. CHECK EPS CONTROL UNIT
Check EPS control unit input/output signal. Refer to STC-11, "
EPS Control Unit Input/Output Signal Reference
Values" .
OK or NG
OK >> GO TO 4.
NG >> Check EPS control unit pin terminals for damage or loose connection with harness connector. If
any items are damaged, repair or replace damaged parts.
4. SYMPTOM CHECK
Check again.
OK or NG
OK >>INSPECTION END
NG >> Check the steering wheel turning force because there may be mechanical malfunction. Refer to
PS-6, "
CHECKING STEERING WHEEL TURNING FORCE" .
Page 2819 of 2896

WT-1
ROAD WHEELS & TIRES
E SUSPENSION
CONTENTS
C
D
F
G
H
I
J
K
L
M
SECTION WT
A
B
WT
Revision: June 20062007 Versa PRECAUTIONS .......................................................... 2
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 2
PREPARATION ........................................................... 3
Special Service Tool ................................................. 3
Commercial Service Tools ........................................ 3
NOISE, VIBRATION AND HARSHNESS (NVH)
TROUBLESHOOTING ................................................ 4
NVH Troubleshooting Chart ..................................... 4
ROAD WHEEL ............................................................ 5
Inspection ................................................................. 5
ALUMINUM WHEEL ............................................. 5
STEEL WHEEL ..................................................... 5
ROAD WHEEL TIRE ASSEMBLY .............................. 6
Balancing Wheels .................................................... 6
Rotation .................................................................... 6
LOW TIRE PRESSURE WARNING SYSTEM ............ 7
System Components ................................................ 7
System Description .................................................. 7
BODY CONTROL MODULE (BCM) ...................... 7
TRANSMITTER ..................................................... 8
REMOTE KEYLESS ENTRY RECEIVER ............. 8
COMBINATION METER ....................................... 8
CAN COMMUNICATION ............................................ 9
System Description .................................................. 9
TROUBLE DIAGNOSES .......................................... 10
Wiring Diagram — T/WARN — .............................. 10
Terminals and Reference Values for BCM ..............11
ID Registration Procedure .......................................11
ID REGISTRATION WITH TRANSMITTER
ACTIVATION TOOL .............................................11
ID REGISTRATION WITHOUT TRANSMITTER
ACTIVATION TOOL ............................................ 12
Transmitter Wake Up Operation ............................. 13
CONSULT-II Function (BCM) ................................. 14
How to Perform Trouble Diagnosis for Quick and Accurate Repair ...................................................... 15
INTRODUCTION ................................................. 15
WORK FLOW ...................................................... 15
Preliminary Check .................................................. 16
Self-Diagnosis ........................................................ 16
DESCRIPTION .................................................... 16
FUNCTION .......................................................... 16
Flash Code/Symptom Chart ................................... 19
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC
ITEMS ........................................................................ 20
Data From Transmitter Not Being Received ........... 20
MALFUNCTION CODE NO. 21, 22, 23 OR 24
(DTC C1708, C1709, C1710 OR C1711) ............ 20
Transmitter Malfunction .......................................... 20
MALFUNCTION CODE NO. 31, 32, 33, 34, 41,
42, 43, 44, 45, 46, 47 OR 48 ............................... 20
Transmitter Pressure Malfunction ........................... 21
MALFUNCTION CODE NO. 35, 36, 37 OR 38 ... 21
Vehicle Speed Signal .............................................. 22
MALFUNCTION CODE NO. 52 (DTC C1729) .... 22
TROUBLE DIAGNOSIS FOR SYMPTOMS .............. 23
Low Tire Pressure Warning Lamp Does Not Come
On When Ignition Switch Is Turned On. ................. 23
Low Tire Pressure Warning Lamp Stays On When
Ignition Switch Is Turned On .................................. 23
Low Tire Pressure Warning Lamp Flashes When
Ignition Switch Is Turned On. ................................. 25
Hazard Warning Lamps Flash When Ignition Switch
Is Turned On ........................................................... 26
ID Registration Cannot Be Completed ................... 26
REMOVAL AND INSTALLATION ............................. 27
Transmitter (Pressure Sensor) ............................... 27
REMOVAL ........................................................... 27
INSTALLATION ................................................... 27
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 29
Road Wheel ............................................................ 29
Tire ......................................................................... 29
Page 2820 of 2896

WT-2
PRECAUTIONS
Revision: June 20062007 Versa
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
EES002ES
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WAR NIN G:
To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.
Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Page 2821 of 2896
PREPARATION
WT-3
C
D
F
G
H
I
J
K
L
MA
B
WT
Revision: June 20062007 Versa
PREPARATIONPFP:00002
Special Service ToolEES002ET
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Commercial Service ToolsEES002EF
Tool number
(Kent-Moore No.)
Tool nameDescription
KV991B1000
(J-45295)
Transmitter activation tool
Transmitter wake up operation
ID registration procedure
W EIA0144E
Tool nameDescription
Power toolRemoving wheel nuts
PBIC0190E
Page 2822 of 2896

WT-4
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
Revision: June 20062007 Versa
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTINGPFP:00003
NVH Troubleshooting ChartEES002D6
Use the chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.
×: ApplicableReference page
FA X - 5WT-5
WT-6
WT-29—
—
—
—
FAX -4, "
NVH Troubleshooting Chart
",
FSU-5, "
NVH Troubleshooting Chart
"
RAX-3, "
NVH Troubleshooting Chart
",
RSU-4, "
NVH Troubleshooting Chart
"
Refer to TIRES in this chart
Refer to ROAD WHEEL in this chart
FAX -4, "
NVH Troubleshooting Chart
"
BR-5, "
NVH Troubleshooting Chart
"
PS-5, "
NVH Trouble Shooting Chart
"
Possible cause and SUSPECTED PARTS
Improper installation, looseness
Out-of-round
Imbalance
Incorrect tire pressure
Uneven tire wear
Deformation or damage
Non-uniformity
Incorrect tire size
FRONT AXLE AND FRONT SUSPENSION
REAR AXLE AND REAR SUSPENSION
TIRES
ROAD WHEELS
DRIVE SHAFT
BRAKE
STEERING
SymptomTIRESNoise× ×××××× × × ××××
Shake× ××××× × × × ××××
Vibration××××××
Shimmy× ××××××× × × × ××
Shudder× ××××× × × × × ××
Poor quality
ride or handling× ××××× × × × ×
ROAD WHEELNoise××× × × × × ×××
Shake××× × × × × ×××
Shimmy, Shud-
der×××× ×××××
Poor quality
ride or handling××× × × × ×
Page 2823 of 2896

ROAD WHEEL
WT-5
C
D
F
G
H
I
J
K
L
MA
B
WT
Revision: June 20062007 Versa
ROAD WHEELPFP:40300
InspectionEES002D7
ALUMINUM WHEEL
1. Check tires for wear and improper inflation.
2. Check wheels for deformation, cracks and other damage. If deformed, remove wheel and check wheel
runout.
a. Remove tire from aluminum wheel and mount on a tire balance machine.
b. Set dial indicator as shown.
STEEL WHEEL
1. Check tires for wear and improper inflation.
2. Check wheels for deformation, cracks and other damage. If deformed, remove wheel and check wheel
runout.
a. Remove tire from steel wheel and mount on a tire balance machine.
b. Set two dial indicators as shown.
c. Set each dial indicator to 0.
d. Rotate wheel and check dial indicators at several points around
the circumference of the wheel.
e. Calculate runout at each point as shown.
f. Select maximum positive runout value and the maximum nega-
tive value.
Add the two values to determine total runout. In case a positive
or negative value is not available, use the maximum value (neg-
ative or positive) for total runout. If the total runout value
exceeds the limit, replace steel wheel.Wheel runout
(Dial indicator value): Refer to WT-29, "
Road Wheel" .
SFA975B
Radial runout = (A+B)/2
Lateral runout = (C+D)/2
Wheel runout : Refer to WT-29, "
Road Wheel" .
SEIA0558E
Page 2824 of 2896
WT-6
ROAD WHEEL TIRE ASSEMBLY
Revision: June 20062007 Versa
ROAD WHEEL TIRE ASSEMBLYPFP:40300
Balancing WheelsEES002D8
Adjust wheel balance using road wheel center.
CAUTION:
Be careful not to scratch the road wheel during removal.
Use clip-on type wheel balance weights only.
Wheel balance (Maximum allowable unbalance):
RotationEES002D9
Follow the maintenance schedule for tire rotation service inter-
vals. Refer to MA-7, "
PERIODIC MAINTENANCE" .
Do not include the T-type spare tire when rotating tires.
CAUTION:
When installing wheels, tighten them diagonally by divid-
ing the work two to three times in order to prevent the
wheels from developing any distortion.
Be careful not to tighten wheel nut at torque exceeding
the specification to prevent damage of disc rotor.
Maximum allowable unbalanceDynamic (At rim flange) Less than 5 g (0.18 oz) (one side)
Static (At rim flange) Less than 10 g (0.35 oz)
Wheel nut : 113 N·m (12 kg-m, 83 ft-lb)SM A82 9C
