Blower Motor CircuitEJS0057N
SYMPTOM: Front blower motor operation is malfunctioning.
INSPECTION FLOW
1. CONFIRM SYMPTOM BY PERFORMING OPERATIONAL CHECK - FRONT BLOWER
1. Turn blower control dial to "1" position. Blower should operate on low speed.
2. Turn the blower control dial to "2" position, and continue checking blower speed until all speeds are
checked.
Can the symptom be duplicated?
YES >> GO TO 3.
NO >> GO TO 2.
2. PERFORM COMPLETE OPERATIONAL CHECK
Perform a complete operational check and check for any symptoms. Refer to MTC-33, "
Operational Check" .
Can a symptom be duplicated?
YES >> Refer to MTC-24, "SYMPTOM TABLE" .
NO >> System OK.
3. CHECK FOR SERVICE BULLETINS
Check for any service bulletins.
>> GO TO 4.
4. CHECK FRONT BLOWER MOTOR CIRCUIT
Check front blower motor circuit. Refer to MTC-38, "
DIAGNOSTIC PROCEDURE FOR BLOWER MOTOR" .
OK or NG?
OK >> If the symptom still exists, perform a complete operational check. Refer to MTC-33, "Operational
Check" . If other symptoms exist, refer to MTC-24, "SYMPTOM TABLE" .
NG >> Repair as necessary.
Page 2450 of 2896

MTC-38
TROUBLE DIAGNOSIS
Revision: June 20062007 Versa
DIAGNOSTIC PROCEDURE FOR BLOWER MOTOR
SYMPTOM: Blower motor operation is malfunctioning.
1. CHECK BLOWER MOTOR OPERATION
1. Turn ignition switch ON.
2. Check blower motor operation at each fan speed.
OK or NG
OK >> Inspection End.
NG >>
Blower motor does not operate at any speed, GO TO 2
Blower motor does not operate at one or more of the four speeds, GO TO 8.
2. CHECK POWER SUPPLY FOR BLOWER MOTOR
1. Turn ignition switch OFF.
2. Disconnect front blower motor connector.
3. Turn ignition switch ON.
4. Check voltage between front blower motor harness connector
M62 terminal 1 and ground.
OK or NG
OK >> GO TO 3.
NG >> Check power supply circuit and 15A fuses [Nos. 15 and 17, located in the fuse block (J/B)]. Refer
to PG-76, "
FUSE BLOCK-JUNCTION BOX (J/B)" .
If fuses are OK, check harness for open circuit. Repair or replace if necessary.
If fuses are NG, replace fuse and check harness for short circuit. Repair or replace if necessary.
3. CHECK FRONT BLOWER MOTOR
Check continuity between front blower motor terminals 1 and 2.
NOTE:
Ensure that there are no foreign particles inside the A/C unit assem-
bly for a smooth rotation of the blower motor.
OK or NG
OK >> GO TO 4.
NG >> Replace front blower motor. Refer to MTC-68,
"BLOWER MOTOR" .
WJIA2227E
Terminals
Vo ltag e
(Approx.) (+) (−)
Connector Terminal
Ground
Front blower
motor: M621 Battery voltage
WJIA2228E
1 - 2 : Continuity should exist.
WJIA2230E
Page 2451 of 2896

TROUBLE DIAGNOSIS
MTC-39
C
D
E
F
G
H
I
K
L
MA
B
MTC
Revision: June 20062007 Versa
4. CHECK CIRCUIT CONTINUITY BETWEEN BLOWER MOTOR AND FRONT BLOWER MOTOR RESIS-
TOR
1. Disconnect front blower motor resistor connector.
2. Check continuity between front blower motor harness connector
M62 (A) terminal 2 and front blower motor resistor harness con-
nector M151 (B) terminal 4.
OK or NG
OK >> GO TO 5.
NG >> Repair harness or connector.
5. CHECK FRONT BLOWER MOTOR RESISTOR
1. Disconnect front blower motor resistor connector.
2. Check resistance between front blower motor resistor terminal 4
and 1, 2, 3.
OK or NG
OK >> GO TO 6.
NG >> Replace front blower motor resistor. Refer to MTC-72,
"BLOWER FAN RESISTOR" .
6. CHECK FAN SWITCH
1. Disconnect front air control connector.
2. Check continuity between front air control terminal 9 and 10, 11,
12, 13, 14.
OK or NG
OK >> GO TO 7.
NG >> Replace front air control. Refer to MTC-61, "
CONTROLLER" . 2 - 4 : Continuity should exist.
WJIA2231E
Terminals Resistance (Approx.)
412.15Ω
21.10Ω
30.46Ω
SJIA0730E
Terminals Condition Continuity
914 Fan control dial: OFF
Ye s 10 Fan control dial: 1-speed
11 Fan control dial: 2-speed
12 Fan control dial: 3-speed
13 Fan control dial: 4-speed
SJIA0732E
Page 2452 of 2896

MTC-40
TROUBLE DIAGNOSIS
Revision: June 20062007 Versa
7. CHECK FAN SWITCH GROUND CIRCUIT
Check continuity between front air control harness connector M33
terminal 9 and ground.
OK or NG
OK >> Inspection End.
NG >> Repair harness or connector.
8. CHECK CIRCUIT CONTINUITY BETWEEN FRONT AIR CONTROL AND FRONT BLOWER MOTOR
RESISTOR
1. Turn ignition switch OFF.
2. Disconnect front blower motor resistor and front air control con-
nectors.
3. Check continuity between front air control harness connector
M33 (A) terminals and front blower motor resistor harness con-
nector M151 (B) terminals.
OK or NG
OK >> GO TO 9.
NG >> Repair harness or connector.
9. CHECK FAN SWITCH
Check continuity between front air control terminal 9 and 10, 11, 12,
13, 14.
OK or NG
OK >> Replace the front blower motor resistor. Refer to MTC-72, "BLOWER FAN RESISTOR" .
NG >> Replace front air control. Refer to MTC-61, "
CONTROLLER" . Continuity should exist.
SJIA0734E
AB
Continuity
Connector Terminal Connector Terminal
Front air control:
M3310
Front blower
motor resistor:
M1511
Ye s 11 2
12 3
13 4
SJIA0733E
Terminals Condition Continuity
914 Fan control dial: OFF
Ye s 10 Fan control dial: 1-speed
11 Fan control dial: 2-speed
12 Fan control dial: 3-speed
13 Fan control dial: 4-speed
SJIA0732E
Page 2453 of 2896

TROUBLE DIAGNOSIS
MTC-41
C
D
E
F
G
H
I
K
L
MA
B
MTC
Revision: June 20062007 Versa
Magnet Clutch Circuit (If Equipped)EJS0057O
SYMPTOM: Magnet clutch does not engage.
INSPECTION FLOW
1. CONFIRM SYMPTOM BY PERFORMING OPERATIONAL CHECK - MAGNET CLUTCH
1. Turn ignition switch ON.
2. Turn blower control dial to the desired (1 to 4 speed) position.
3. Press the A/C switch. A/C indicator will turn on.
4. Confirm that the compressor clutch engages (sound or visual inspection).
Can the symptom be duplicated?
YES >> GO TO 3.
NO >> GO TO 2.
2. CHECK FOR ANY SYMPTOMS
Perform a complete operational check for any symptoms. Refer to MTC-33, "
Operational Check" .
Does another symptom exist?
YES >> Refer to MTC-24, "SYMPTOM TABLE" .
NO >> System OK.
3. CHECK FOR SERVICE BULLETINS
Check for any service bulletins.
>> GO TO 4.
4. CHECK COMPRESSOR BELT TENSION
Check compressor belt tension. Refer to EM-13, "
Checking Drive Belts" .
OK or NG
OK >> GO TO 5.
NG >> Adjust or replace A/C compressor belt.
5. CHECK REFRIGERANT PRESSURE
Check refrigerant pressure with manifold gauge connected. Refer to MTC-54, "
Test Reading" .
OK or NG
OK >> GO TO 6.
NG >> Perform trouble diagnosis for unusual pressure. Refer to MTC-55, "
TROUBLE DIAGNOSIS FOR
UNUSUAL PRESSURE" .
6. CHECK MAGNET CLUTCH CIRCUIT
Perform diagnostic procedure for the magnetic clutch. Refer to MTC-42, "
DIAGNOSTIC PROCEDURE FOR
MAGNET CLUTCH" .
OK or NG
OK >> If the symptom still exists, perform a complete operational check. Refer to MTC-33, "Operational
Check" . If other symptoms exist, refer to MTC-24, "SYMPTOM TABLE" .
NG >> Repair as necessary.
Page 2454 of 2896

MTC-42
TROUBLE DIAGNOSIS
Revision: June 20062007 Versa
SYSTEM DESCRIPTION
Thermo control amp. controls A/C compressor operation by intake air temperature and signal from ECM.
The defrost A/C switch controls A/C compressor operation by the BCM when the mode switch is turned to the
(DEF) position.
Low Temperature Protection Control
When intake air temperatures are higher than 4°C (39°F), the com-
pressor turns ON. The compressor turns OFF when intake air tem-
peratures are lower than 2°C (36°F).
DIAGNOSTIC PROCEDURE FOR MAGNET CLUTCH
SYMPTOM: Magnet clutch does not engage in A/C, defrost/foot, or defrost mode.
1. PERFORM AUTO ACTIVE TEST
Refer to PG-21, "
Auto Active Test" .
Does the magnet clutch operate?
YES >> GO TO 5.
NO >> Check 10A fuse (No. 42, located in the IPDM E/R). Refer to PG-24, "
IPDM E/R Terminal Arrange-
ment" .
If fuse is OK, GO TO 2.
If fuse is NG, replace fuse and check harness for short circuit. Repair or replace if necessary.
2. CHECK POWER SUPPLY FOR IPDM E/R
Check power supply to 10A fuse (No. 42 located in the IPDM E/R).
OK or NG
OK >> GO TO 3.
NG >> Check harness for open circuit. Repair or replace if necessary.
SJIA0741E
WJIA2250E
:Battery voltage should exist
Page 2455 of 2896

TROUBLE DIAGNOSIS
MTC-43
C
D
E
F
G
H
I
K
L
MA
B
MTC
Revision: June 20062007 Versa
3. CHECK POWER SUPPLY FOR A/C COMPRESSOR
1. Disconnect A/C compressor connector.
2. Start the engine.
3. Turn blower control dial and A/C switch ON.
4. Check voltage between A/C compressor harness connector F3
terminal 1 and ground.
OK or NG
OK >> Replace magnet clutch. Refer to MTC-84, "Removal and
Installation of Compressor"
NG >> GO TO 4.
4. CHECK CIRCUIT CONTINUITY BETWEEN IPDM E/R AND COMPRESSOR
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector.
3. Check continuity between A/C compressor harness connector
F3 (A) terminal 1 and IPDM E/R harness connector E43 (B) ter-
minal 11.
OK or NG
OK >> Replace IPDM E/R. Refer to PG-29, "Removal and
Installation of IPDM E/R"
NG >> Repair harness or connector.
5. CHECK DEFROST A/C SWITCH
1. Start the engine.
2. Turn the mode control dial to (DEF) position.
Does the magnet clutch operate
OK >> GO TO 6.
NG >> GO TO 22.
6. CHECK BCM INPUT (COMPRESSOR ON) SIGNAL
1. Turn ignition switch OFF.
2. Check compressor ON/OFF signal. Refer to MTC-24, "
CON-
SULT-II Function (BCM)" .
OK or NG
OK >> GO TO 8.
NG >> GO TO 7.1 - Ground :Battery voltage
SJIA0743E
1 - 11 :Continuity should exist
WJIA2233E
A/C SW ON : AIR COND SW ON
A/C SW OFF : AIR COND SW OFF
R J I A 1111E
Page 2456 of 2896
MTC-44
TROUBLE DIAGNOSIS
Revision: June 20062007 Versa
7. CHECK CIRCUIT CONTINUITY BETWEEN FRONT AIR CONTROL AND BCM
1. Turn ignition switch OFF.
2. Disconnect front air control and BCM connector.
3. Check continuity between front air control harness connector
M33 (A) terminal 1and BCM harness connector M18 (B) termi-
nal 27.
OK or NG
OK >> GO TO 8.
NG >> Repair harness or connector.
8. CHECK REFRIGERANT PRESSURE SENSOR
1. Reconnect front air control connector and BCM connector.
2. Check refrigerant pressure sensor. Refer to EC-586, "
REFRIGERANT PRESSURE SENSOR" .
.OK or NG
OK >>WITH CONSULT-II
GO TO 9.
WITHOUT CONSULT-II
GO TO 10.
NG >> Replace as necessary.
9. CHECK BCM INPUT (FAN ON) SIGNAL
Check FAN ON/OFF signal. Refer to MTC-24, "
CONSULT-II Func-
tion (BCM)" .
OK or NG
OK >> GO TO 12.
NG >> GO TO 10.1 - 27 :Continuity should exist
SJIA0759E
FAN CONTROL DIAL ON : FAN ON SIG ON
FAN CONTROL DIAL OFF : FAN ON SIG OFF
R J I A 1111E
