Page 169 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual AT-156
DTC P0755 SHIFT SOLENOID VALVE B
Revision: June 20062007 Versa
DTC P0755 SHIFT SOLENOID VALVE BPFP:31940
DescriptionUCS005PN
Shift solenoid valves A and B are turned ON or OFF by the TCM in res

AT-156
DTC P0755 SHIFT SOLENOID VALVE B
Revision: June 20062007 Versa
DTC P0755 SHIFT SOLENOID VALVE BPFP:31940
DescriptionUCS005PN
Shift solenoid valves A and B are turned ON or OFF by the TCM in response to signals sent from the PNP
switch, vehicle speed and ECM (throttle opening). Gears will then be shifted to the optimum position.
CONSULT-II Reference ValueUCS005PO
On Board Diagnosis LogicUCS005PP
This is an OBD-II self-diagnostic item.
Diagnostic trouble code “P0755 SHIFT SOLENOID/V B” with CONSULT-II or 5th judgement flicker without
CONSULT-II is detected when TCM detects an improper voltage drop when it tries to operate the solenoid
valve.
Possible CauseUCS005PQ
Harness or connector
(The solenoid circuit is open or shorted.)
Shift solenoid valve B
DTC Confirmation ProcedureUCS005PR
CAUTION:
Always drive vehicle at a safe speed.
If performing this “DTC Confirmation Procedure” again, always turn ignition switch OFF and wait
at least 10 seconds before continuing.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Turn ignition switch ON and select “DATA MONITOR” mode for
“A/T” with CONSULT-II.
2. Touch “START”.
3. Start engine.
4. Drive vehicle in D position and allow the transaxle to shift 1 → 2
→ 3 (“GEAR”).
5. If the check result is NG, go to AT-158, "
Diagnostic Procedure" .
WITH GST
Follow the procedure “WITH CONSULT-II”.
WITHOUT CONSULT-II
1. Start engine.
2. Drive vehicle in D
1 → D2 → D3 position.
3. Perform self-diagnosis. Refer to AT-90, "
Diagnostic Procedure Without CONSULT-II" .
4. If the check result is NG, go to AT-158, "
Diagnostic Procedure" .
Gear position 1 2 3 4
Shift solenoid valve A ON (Closed) OFF (Open) OFF (Open) ON (Closed)
Shift solenoid valve B ON (Closed) ON (Closed) OFF (Open) OFF (Open)
Item name Condition Display value
SHIFT S/V BWhen shift solenoid valve B operates.
(When driving in “D
1 ” or “D2 ”.)ON
When shift solenoid valve B does not operate.
(When driving in “D
3 ” or “D4 ”.)OFF
BCIA0031E

Page 170 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual DTC P0755 SHIFT SOLENOID VALVE B
AT-157
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: June 20062007 Versa
Wiring Diagram — AT — SSV/BUCS005PS
BCWA0656E

Page 171 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual AT-158
DTC P0755 SHIFT SOLENOID VALVE B
Revision: June 20062007 Versa
TCM terminal data are reference values, measured between each terminal and ground.
Diagnostic ProcedureUCS005PT
1. CHECK INPUT SI

Page 172 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual DTC P0755 SHIFT SOLENOID VALVE B
AT-159
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: June 20062007 Versa
2. CHECK SHIFT SOLENOID VALVE B CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect TCM connector.
3. Che

Page 173 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual AT-160
DTC P0755 SHIFT SOLENOID VALVE B
Revision: June 20062007 Versa
6. CHECK TCM
1. Check TCM input/output signal. Refer to AT - 7 8 , "
TCM Terminals and Reference Value" .
2. If NG, recheck TCM p

Page 174 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual DTC P1760 OVERRUN CLUTCH SOLENOID VALVE
AT-161
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: June 20062007 Versa
DTC P1760 OVERRUN CLUTCH SOLENOID VALVEPFP:31940
DescriptionUCS005Q1
The overrun clutch solenoid

DTC P1760 OVERRUN CLUTCH SOLENOID VALVE
AT-161
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: June 20062007 Versa
DTC P1760 OVERRUN CLUTCH SOLENOID VALVEPFP:31940
DescriptionUCS005Q1
The overrun clutch solenoid valve is activated by the TCM in response to signals sent from the PNP switch,
overdrive control switch, vehicle speed and ECM (throttle opening). The overrun clutch operation will then be
controlled.
CONSULT-II Reference ValueUCS005Q2
On Board Diagnosis LogicUCS005Q3
This is an OBD-II self-diagnostic item.
Diagnostic trouble code “P1760 OVERRUN CLUTCH S/V” with CONSULT-II or 6th judgement flicker with-
out CONSULT-II is detected when TCM detects an improper voltage drop when it tries to operate solenoid
valve.
Possible CauseUCS005Q4
Harness or connector
(The solenoid circuit is open or shorted.)
Overrun clutch solenoid valve
DTC Confirmation ProcedureUCS005Q5
CAUTION:
Always drive vehicle at a safe speed.
If performing this “DTC Confirmation Procedure” again, always turn ignition switch OFF and wait
at least 10 seconds before continuing.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Turn ignition switch ON and select “DATA MONITOR” mode for
“A/T” with CONSULT-II.
2. Touch “START”.
3. Start engine.
4. Accelerate vehicle to a speed of more than 10 km/h (6 MPH)
with “D” position (OD ON).
5. Release accelerator pedal completely with “D” position (OD
OFF).
6. If the check result is NG, go to AT-163, "
Diagnostic Procedure" .
WITH GST
Follow the procedure “WITH CONSULT-II”.
WITHOUT CONSULT-II
1. Start engine.
2. Drive vehicle under the following conditions:
Selector lever position: “D” position (OD ON)
Vehicle speed: Higher than 10 km/h (6 MPH)
3. Perform self-diagnosis. Refer to AT- 9 0 , "
Diagnostic Procedure Without CONSULT-II" .
4. If the check result is NG, go to AT-163, "
Diagnostic Procedure" .
Item name Condition Display value
OVERRUN/C S/VWhen overrun clutch solenoid valve operates. (When
overrun clutch disengaged. Refer to AT- 2 2
.)ON
When overrun clutch solenoid valve does not operate.
(When overrun clutch engaged. Refer to AT - 2 2
.)OFF
BCIA0031E

Page 175 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual AT-162
DTC P1760 OVERRUN CLUTCH SOLENOID VALVE
Revision: June 20062007 Versa
Wiring Diagram — AT — OVRCSVUCS005Q6
BCWA0657E

Page 176 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual DTC P1760 OVERRUN CLUTCH SOLENOID VALVE
AT-163
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: June 20062007 Versa
TCM terminal data are reference values, measured between each terminal and ground.
Diagnostic Pr
