TROUBLE DIAGNOSIS
LAN-75
[CAN]
C
D
E
F
G
H
I
J
L
MA
B
LAN
Revision: June 20062007 Versa
2. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of BCM.
2. Check the resistance between the BCM harness connector terminals.
OK or NG
OK >> GO TO 3.
NG >> Repair the BCM branch line.
3. CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of BCM. Refer to BCS-16, "
BCM Power Supply and Ground
Circuit Check" .
OK or NG
OK >>Present error: Replace the BCM. Refer to BCS-25, "Removal and Installation of BCM" .
Past error: Error was detected in the BCM branch line.
NG >> Repair the power supply and the ground circuit.
Data Link Connector Branch Line CircuitUKS005WL
INSPECTION PROCEDURE
1. CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the data link connector for damage, bend and loose connection
(connector side and harness side).
OK or NG
OK >> GO TO 2.
NG >> Repair the terminal and connector.
2. CHECK HARNESS FOR OPEN CIRCUIT
Check the resistance between the data link connector terminals.
OK or NG
OK >>Present error: Check the following items again.
–Decision of CAN system type.
–Not received CONSULT-II data (SELECT SYSTEM, SELF-DIAG RESULTS, CAN DIAG SUP-
PORT MNTR).
–Procedure for detecting root cause.
Past error: Error was detected in the data link connector branch line circuit.
NG >> Repair the data link connector branch line.
BCM harness connector
Resistance (Ω)
Connector No. Terminal No.
M18 39 40 Approx. 54 – 66
Data link connector
Resistance (Ω)
Connector No. Terminal No.
M22 6 14 Approx. 54 – 66
Page 2202 of 2896
![NISSAN VERSA 2006 Workshop Service Repair Manual LAN-76
[CAN]
TROUBLE DIAGNOSIS
Revision: June 20062007 Versa
EPS Control Unit Branch Line CircuitUKS005WM
INSPECTION PROCEDURE
1. CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the bat NISSAN VERSA 2006 Workshop Service Repair Manual LAN-76
[CAN]
TROUBLE DIAGNOSIS
Revision: June 20062007 Versa
EPS Control Unit Branch Line CircuitUKS005WM
INSPECTION PROCEDURE
1. CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the bat](/manual-img/5/57401/w960_57401-2201.png)
LAN-76
[CAN]
TROUBLE DIAGNOSIS
Revision: June 20062007 Versa
EPS Control Unit Branch Line CircuitUKS005WM
INSPECTION PROCEDURE
1. CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the EPS control unit for damage, bend and loose connection (unit
side and connector side).
OK or NG
OK >> GO TO 2.
NG >> Repair the terminal and connector.
2. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of EPS control unit.
2. Check the resistance between the EPS control unit harness connector terminals.
OK or NG
OK >> GO TO 3.
NG >> Repair the EPS control unit branch line.
3. CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of EPS control unit. Refer to STC-9, "
Wiring Diagram — EPS
—" .
OK or NG
OK >>Present error: Replace the EPS control unit. Refer to PS-9, "Removal and Installation" .
Past error: Error was detected in the EPS control unit branch line.
NG >> Repair the power supply and the ground circuit.
Intelligent Key Unit Branch Line CircuitUKS005WN
INSPECTION PROCEDURE
1. CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the Intelligent Key unit for damage, bend and loose connection
(unit side and connector side).
OK or NG
OK >> GO TO 2.
NG >> Repair the terminal and connector.
EPS control unit harness connector
Resistance (Ω)
Connector No. Terminal No.
M53 9 16 Approx. 54 – 66
Page 2203 of 2896
![NISSAN VERSA 2006 Workshop Service Repair Manual TROUBLE DIAGNOSIS
LAN-77
[CAN]
C
D
E
F
G
H
I
J
L
MA
B
LAN
Revision: June 20062007 Versa
2. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of Intelligent Key unit.
2. Check the resistance b NISSAN VERSA 2006 Workshop Service Repair Manual TROUBLE DIAGNOSIS
LAN-77
[CAN]
C
D
E
F
G
H
I
J
L
MA
B
LAN
Revision: June 20062007 Versa
2. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of Intelligent Key unit.
2. Check the resistance b](/manual-img/5/57401/w960_57401-2202.png)
TROUBLE DIAGNOSIS
LAN-77
[CAN]
C
D
E
F
G
H
I
J
L
MA
B
LAN
Revision: June 20062007 Versa
2. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of Intelligent Key unit.
2. Check the resistance between the Intelligent Key unit harness connector terminals.
OK or NG
OK >> GO TO 3.
NG >> Repair the Intelligent Key unit branch line.
3. CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of Intelligent Key unit. Refer to BL-123, "
Power Supply and
Ground Circuit Check" .
OK or NG
OK >>Present error: Replace the Intelligent Key unit. Refer to BL-160, "Removal and Installation of
Intelligent Key Unit" .
Past error: Error was detected in the Intelligent Key unit branch line.
NG >> Repair the power supply and the ground circuit.
Combination Meter Branch Line CircuitUKS005WO
INSPECTION PROCEDURE
1. CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the combination meter for damage, bend and loose connection
(unit side and connector side).
OK or NG
OK >> GO TO 2.
NG >> Repair the terminal and connector.
2. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of combination meter.
2. Check the resistance between the combination meter harness connector terminals.
OK or NG
OK >> GO TO 3.
NG >> Repair the combination meter branch line.
3. CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of combination meter. Refer to DI-17, "
Power Supply and
Ground Circuit Inspection" .
OK or NG
OK >>Present error: Replace the combination meter. Refer to DI-23, "Removal and Installation" .
Past error: Error was detected in the combination meter branch line.
NG >> Repair the power supply and the ground circuit.
Intelligent Key unit harness connector
Resistance (Ω)
Connector No. Terminal No.
M52 2 3 Approx. 54 – 66
Combination meter harness connector
Resistance (Ω)
Connector No. Terminal No.
M24 1 2 Approx. 54 – 66
Page 2204 of 2896
![NISSAN VERSA 2006 Workshop Service Repair Manual LAN-78
[CAN]
TROUBLE DIAGNOSIS
Revision: June 20062007 Versa
ABS Actuator and Electric Unit (Control Unit) Branch Line CircuitUKS005WP
INSPECTION PROCEDURE
1. CHECK CONNECTOR
1. Turn the ignition swit NISSAN VERSA 2006 Workshop Service Repair Manual LAN-78
[CAN]
TROUBLE DIAGNOSIS
Revision: June 20062007 Versa
ABS Actuator and Electric Unit (Control Unit) Branch Line CircuitUKS005WP
INSPECTION PROCEDURE
1. CHECK CONNECTOR
1. Turn the ignition swit](/manual-img/5/57401/w960_57401-2203.png)
LAN-78
[CAN]
TROUBLE DIAGNOSIS
Revision: June 20062007 Versa
ABS Actuator and Electric Unit (Control Unit) Branch Line CircuitUKS005WP
INSPECTION PROCEDURE
1. CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the ABS actuator and electric unit (control unit) for damage, bend
and loose connection (unit side and connector side).
OK or NG
OK >> GO TO 2.
NG >> Repair the terminal and connector.
2. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of ABS actuator and electric unit (control unit).
2. Check the resistance between the ABS actuator and electric unit (control unit) harness connector termi-
nals.
OK or NG
OK >> GO TO 3.
NG >> Repair the ABS actuator and electric unit (control unit) branch line.
3. CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of ABS actuator and electric unit (control unit). Refer to BRC-
29, "ABS Control Unit Power and Ground Systems Inspection" .
OK or NG
OK >>Present error: Replace the ABS actuator and electric unit (control unit). Refer to BRC-36,
"Removal and Installation" .
Past error: Error was detected in the ABS actuator and electric unit (control unit) branch line.
NG >> Repair the power supply and the ground circuit.
TCM Branch Line CircuitUKS005WQ
INSPECTION PROCEDURE
1. CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the TCM for damage, bend and loose connection (unit side and
connector side).
OK or NG
OK >> GO TO 2.
NG >> Repair the terminal and connector.
ABS actuator and electric unit (control unit) harness connector
Resistance (Ω)
Connector No. Terminal No.
E33 26 15 Approx. 54 – 66
Page 2205 of 2896
![NISSAN VERSA 2006 Workshop Service Repair Manual TROUBLE DIAGNOSIS
LAN-79
[CAN]
C
D
E
F
G
H
I
J
L
MA
B
LAN
Revision: June 20062007 Versa
2. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of TCM.
2. Check the resistance between the TCM ha NISSAN VERSA 2006 Workshop Service Repair Manual TROUBLE DIAGNOSIS
LAN-79
[CAN]
C
D
E
F
G
H
I
J
L
MA
B
LAN
Revision: June 20062007 Versa
2. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of TCM.
2. Check the resistance between the TCM ha](/manual-img/5/57401/w960_57401-2204.png)
TROUBLE DIAGNOSIS
LAN-79
[CAN]
C
D
E
F
G
H
I
J
L
MA
B
LAN
Revision: June 20062007 Versa
2. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of TCM.
2. Check the resistance between the TCM harness connector terminals.
OK or NG
OK >> GO TO 3.
NG >> Repair the TCM branch line.
3. CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of TCM. Refer to AT-183, "
MAIN POWER SUPPLY AND
GROUND CIRCUIT" (Models with A/T), CVT-42, "Circuit Diagram" (Models with CVT).
OK or NG
OK >>Present error: Replace the TCM. Refer to AT-228, "Removal and Installation" (Models with A/
T), CVT-190, "
Removal and Installation" (Models with CVT).
Past error: Error was detected in the TCM branch line.
NG >> Repair the power supply and the ground circuit.
IPDM E/R Branch Line CircuitUKS005WR
INSPECTION PROCEDURE
1. CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the following terminals and connectors for damage, bend and loose connection (unit side and con-
nector side).
–Models with ABS and/or TCM:
IPDM E/R connector
–Models without ABS and TCM:
IPDM E/R connector
Harness connector E7
Harness connector M69
OK or NG
OK >> GO TO 2.
NG >> Repair the terminal and connector.
2. CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of IPDM E/R.
2. Check the resistance between the IPDM E/R harness connector terminals.
OK or NG
OK >> GO TO 3.
NG >> Repair the IPDM E/R branch line.
TCM harness connector
Resistance (Ω)
Connector No. Terminal No.
E31 5 6 Approx. 54 – 66
IPDM E/R harness connector
Resistance (Ω)
Connector No. Terminal No.
E46 41 40 Approx. 108 – 132
Page 2206 of 2896
![NISSAN VERSA 2006 Workshop Service Repair Manual LAN-80
[CAN]
TROUBLE DIAGNOSIS
Revision: June 20062007 Versa
3. CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of IPDM E/R. Refer to PG-28, "
IPDM E/R Power/Ground NISSAN VERSA 2006 Workshop Service Repair Manual LAN-80
[CAN]
TROUBLE DIAGNOSIS
Revision: June 20062007 Versa
3. CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of IPDM E/R. Refer to PG-28, "
IPDM E/R Power/Ground](/manual-img/5/57401/w960_57401-2205.png)
LAN-80
[CAN]
TROUBLE DIAGNOSIS
Revision: June 20062007 Versa
3. CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of IPDM E/R. Refer to PG-28, "
IPDM E/R Power/Ground Cir-
cuit Inspection" .
OK or NG
OK >>Present error: Replace the IPDM E/R. Refer to PG-29, "Removal and Installation of IPDM E/R"
.
Past error: Error was detected in the IPDM E/R branch line.
NG >> Repair the power supply and the ground circuit.
CAN Communication CircuitUKS005WS
INSPECTION PROCEDURE
1. CONNECTOR INSPECTION
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Disconnect all the unit connectors on CAN communication system.
4. Check terminals and connectors for damage, bend and loose connection.
OK or NG
OK >> GO TO 2.
NG >> Repair the terminal and connector.
2. CHECK HARNESS CONTINUITY (SHORT CIRCUIT)
Check the continuity between the data link connector terminals.
OK or NG
OK >> GO TO 3.
NG >> Check the harness and repair the root cause.
3. CHECK HARNESS CONTINUITY (SHORT CIRCUIT)
Check the continuity between the data link connector and the ground.
OK or NG
OK >> GO TO 4.
NG >> Check the harness and repair the root cause.
Data link connector
Continuity
Connector No. Terminal No.
M22 6 14 No
Data link connector
GroundContinuity
Connector No. Terminal No.
M226No
14 No
Page 2207 of 2896
![NISSAN VERSA 2006 Workshop Service Repair Manual TROUBLE DIAGNOSIS
LAN-81
[CAN]
C
D
E
F
G
H
I
J
L
MA
B
LAN
Revision: June 20062007 Versa
4. CHECK ECM AND IPDM E/R TERMINATION CIRCUIT
1. Remove the ECM and the IPDM E/R.
2. Check the resistance betwee NISSAN VERSA 2006 Workshop Service Repair Manual TROUBLE DIAGNOSIS
LAN-81
[CAN]
C
D
E
F
G
H
I
J
L
MA
B
LAN
Revision: June 20062007 Versa
4. CHECK ECM AND IPDM E/R TERMINATION CIRCUIT
1. Remove the ECM and the IPDM E/R.
2. Check the resistance betwee](/manual-img/5/57401/w960_57401-2206.png)
TROUBLE DIAGNOSIS
LAN-81
[CAN]
C
D
E
F
G
H
I
J
L
MA
B
LAN
Revision: June 20062007 Versa
4. CHECK ECM AND IPDM E/R TERMINATION CIRCUIT
1. Remove the ECM and the IPDM E/R.
2. Check the resistance between the ECM terminals.
3. Check the resistance between the IPDM E/R terminals.
OK or NG
OK >> GO TO 5.
NG >> Replace the ECM and/or the IPDM E/R.
5. CHECK SYMPTOM
Connect all the connectors. Check if the symptoms described in the “Symptom (Results from interview with
customer)” are reproduced.
Inspection result
Reproduced>>GO TO 6.
Non-reproduced>>Start the diagnosis again. Follow the trouble diagnosis procedure when past error is
detected.
6. CHECK UNIT REPRODUCTION
Perform the reproduction test as per the following procedure for each unit.
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Disconnect one of the unit connectors of CAN communication system.
NOTE:
The ECM and the IPDM E/R have a termination circuit. Check other units first.
4. Connect the battery cable to the negative terminal. Check if the symptoms described in the “Symptom
(Results of interview with customer)” are reproduced.
NOTE:
Although unit-related error symptoms occur, do not confuse them with other symptoms.
Inspection result
Reproduced>>Connect the connector. Check other units as per the above procedure.
Non-reproduced>>Replace unit whose connector was disconnected.
ECM
Resistance (Ω)
Te r m i n a l N o .
84 83 Approx. 108 – 132
IPDM E/R
Resistance (Ω)
Te r m i n a l N o .
41 40 Approx. 108 – 132
LKIA0037E
Page 2208 of 2896
LAN-82
[CAN]
TROUBLE DIAGNOSIS
Revision: June 20062007 Versa
