NISSAN VERSA 2006 Workshop Service Repair Manual BR-34
REAR DRUM BRAKE
Revision: June 20062007 Versa
Disassembly and Assembly of Wheel CylinderEFS006JW
DISASSEMBLY
1. Remove boots at the right and left of the wheel cylinder, and pull
out the pistons

Page 818 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)
BR-35
C
D
E
G
H
I
J
K
L
MA
B
BR
Revision: June 20062007 Versa
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
General SpecificationsEFS006JX
Brake PedalEFS006JY
Un

SERVICE DATA AND SPECIFICATIONS (SDS)
BR-35
C
D
E
G
H
I
J
K
L
MA
B
BR
Revision: June 20062007 Versa
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
General SpecificationsEFS006JX
Brake PedalEFS006JY
Unit: mm (in)
Check ValveEFS006JZ
Brake BoosterEFS006K0
Vacuum type
Front Disc Brake EFS006K1
Unit: mm (in) Front brake Brake model CLZ25VA
Cylinder bore diameter 57.2 mm (2.252 in)
Pad
Length × width × thickness11 5 . 0 m m × 41.0 mm × 9.5 mm
(4.528 in × 1.614 in × 0.374 in)
Rotor outer diameter × thickness 260 mm × 22.0 mm (10.24 in × 0.866 in)
Rear brake Brake model LT20D
Cylinder bore diameter 15.87 mm (0.625 in)
Lining
Length × width × thickness194.1 mm × 30.0 mm × 4.0 mm
(7.642 in × 1.181 in × 0.157 in)
Drum outer diameter 228.6 mm (9.000 in)
Master cylinder Cylinder bore diameter 22.22 mm (0.875 in)
Control valve Valve model Electric brake force distribution
Brake booster Booster model C255
Diaphragm diameter 255 mm (10.04 in)
Recommended brake fluid Refer to MA-11, "
RECOMMENDED FLUIDS AND LUBRICANTS" .
Brake pedal free height (from dash panel top surface)A/T, CVT model 172.4 - 182.4 (6.79 - 7.18)
M/T model 162.3 - 172.3 (6.39 - 6.78)
Brake pedal depressed height
[under a force of 490 N (50 kg-f, 110 lb-f) with the engine running]A/T, CVT model 98 (3.86) or more
M/T model 90 (3.54) or more
Clearance between brake pedal lever and the threaded end of stop lamp switch 0.74 - 1.96 (0.0291 - 0.0772)
Pedal play3 - 11 (0.12 - 0.43)
Vacuum leakage
[at vacuum of – 66.7 kPa (– 500 mmHg, – 19.69 inHg]Within 1.3 kPa (10 mmHg, 0.39 inHg) of vacuum for 15 seconds
Vacuum leakage
[at vacuum of – 66.7 kPa (– 500 mmHg, –19.69 inHg)]Within 3.3 kPa (25 mmHg, 0.98 inHg) of vacuum for 15 seconds
Input rod installation standard dimension 154 - 161 mm (6.06 - 6.34 in)
Brake modelCLZ25VA
Brake padStandard thickness (new) 9.5 (0.374)
Repair limit thickness 2.0 (0.079)
Disc rotorStandard thickness (new) 24.0 (0.945)
Repair limit thickness 22.0 (0.866)
Runout limit 0.04 (0.0016)
Maximum uneven wear (mea-
sured at 8 positions)0.02 mm (0.0008 in) or less

Page 819 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual BR-36
SERVICE DATA AND SPECIFICATIONS (SDS)
Revision: June 20062007 Versa
Rear Drum BrakeEFS006K2
Unit: mm (in)
Brake modelLT20D
Brake liningStandard thickness (new) 4.0 (0.157)
Repair limit thickness

Page 820 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual BRC-1
BRAKE CONTROL SYSTEM
F BRAKES
CONTENTS
C
D
E
G
H
I
J
K
L
M
SECTION BRC
A
B
BRC
Revision: June 20062007 VersaABS
PRECAUTIONS .......................................................... 2
Precauti

BRC-1
BRAKE CONTROL SYSTEM
F BRAKES
CONTENTS
C
D
E
G
H
I
J
K
L
M
SECTION BRC
A
B
BRC
Revision: June 20062007 VersaABS
PRECAUTIONS .......................................................... 2
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 2
Precautions for Brake System .................................. 2
Precautions When Using CONSULT-II ..................... 2
CHECK POINTS FOR USING CONSULT-II ......... 2
Precautions for Brake Control .................................. 3
Precautions for CAN System ................................... 3
PREPARATION ........................................................... 4
Special Service Tools ............................................... 4
Commercial Service Tools ........................................ 4
SYSTEM DESCRIPTION ............................................ 5
System Components ................................................ 5
ABS Function ........................................................... 5
EBD Function ........................................................... 5
Fail-Safe Function .................................................... 6
ABS/EBD SYSTEM ............................................... 6
Hydraulic Circuit Diagram ........................................ 6
CAN COMMUNICATION ............................................ 7
System Description .................................................. 7
TROUBLE DIAGNOSIS .............................................. 8
How to Perform Trouble Diagnoses for Quick and
Accurate Repair ....................................................... 8
INTRODUCTION ................................................... 8
WORK FLOW ........................................................ 9
CLARIFY CONCERN .......................................... 10
EXAMPLE OF DIAGNOSIS SHEET ................... 10
Component Parts and Harness Connector Location ....11
Schematic .............................................................. 12
Wiring Diagram — ABS — ..................................... 13
Basic Inspection ..................................................... 17
BRAKE FLUID LEVEL, FLUID LEAK, AND
BRAKE PAD INSPECTION ................................. 17
POWER SYSTEM TERMINAL LOOSENESS AND BATTERY INSPECTION ............................. 17
ABS WARNING LAMP INSPECTION ................. 17
Warning Lamp and Indicator Timing ....................... 18
Control Unit Input/Output Signal Standard ............. 18
REFERENCE VALUE FROM CONSULT-II ......... 18
CONSULT-II Function (ABS) .................................. 20
CONSULT-II START PROCEDURE .................... 20
SELF-DIAGNOSIS .............................................. 20
DATA MONITOR ................................................. 22
ACTIVE TEST ..................................................... 24
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC
ITEMS ........................................................................ 25
Wheel Sensor System ............................................ 25
ABS Control Unit Inspection ................................... 26
Solenoid Valve System Inspection ......................... 27
Actuator Motor, Motor Relay, and Circuit Inspection ... 28
ABS Control Unit Power and Ground Systems
Inspection ............................................................... 29
CAN Communication System Inspection ................ 29
TROUBLE DIAGNOSES FOR SYMPTOMS ............ 30
ABS Works Frequently ........................................... 30
Unexpected Pedal Action ....................................... 31
Long Stopping Distance .......................................... 32
ABS Does Not Work ............................................... 32
Pedal Vibration or ABS Operation Noise ................ 32
WHEEL SENSORS ................................................... 33
Removal and Installation ........................................ 33
REMOVAL ........................................................... 33
INSTALLATION ................................................... 33
SENSOR ROTOR ..................................................... 35
Removal and Installation ........................................ 35
ACTUATOR AND ELECTRIC UNIT (ASSEMBLY) ... 36
Removal and Installation ........................................ 36
REMOVAL ........................................................... 36
INSTALLATION ................................................... 37
