Page 2609 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual POWER STEERING GEAR
PS-15
C
D
E
F
H
I
J
K
L
MA
B
PS
Revision: June 20062007 Versa
Apply an axial load of 490 N (50 kg-f, 111 lb-f) to ball stud
using a dial gauge. Measure amount of stud movement, an

POWER STEERING GEAR
PS-15
C
D
E
F
H
I
J
K
L
MA
B
PS
Revision: June 20062007 Versa
Apply an axial load of 490 N (50 kg-f, 111 lb-f) to ball stud
using a dial gauge. Measure amount of stud movement, and
then make sure that the value is within the specified range.
Replace outer socket and inner socket if the measured value
is outside the standard.
ASSEMBLY
1. Apply recommended grease to teeth part and bush part of rack assembly, if necessary.
2. Apply recommended grease to back of rack assembly, if necessary.
3. Install inner socket to rack assembly. Torque to specified value while holding the flat portion of the rack
next to the inner socket using a suitable tool.
4. Apply recommended grease to inner socket. For application points, refer to PS-13, "
COMPONENT (R24K
TYPE)" .
5. Decide on the neutral position for the rack assembly.
6. Apply recommended grease to around retainer (3), then install
retainer (3), spring (4) and adjusting screw (1) to gear housing
assembly (5).
7. Apply recommended thread locking sealant to the thread (2
turns thread), and then screw in the adjusting screw (1) until it
reaches height “H” from gear housing assembly (5) measured
before disassembling.
8. Tighten lock nut to (2) the specified torque securing it to prevent
adjusting screw (1) from freewheeling condition.
9. Move rack assembly 10 strokes throughout the full stroke so that
the parts can fit with each other.
10. Using Tools A and B, measure rotating torque of pinion assem-
bly. If the measurement is outside of the specified range, read-
just pinion rotating torque. If the measurement is outside of the
specified range for readjust, replace steering gear assembly. Outer socket 0.5 mm (0.020 in) or less
Inner socket 0.2 mm (0.008 in) or less
SGIA0057E
Rack stroke “L” : 65.0 mm (2.559 in)
WGIA0185E
SGIA1300E
Tool numbers A: ST3127S000 (J-25742-1)
B: KV48103400 ( — )
Pinion rotating torque standard
Around neutral position
(within±100°) Average A0.3 - 1.5 N·m (0.03 - 0.15 kg-m,
3 - 13 in-lb)
Maximum variation C 1.86 N·m (0.19 kg-m, 16 in-lb)
MGIA0017E

Page 2610 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual PS-16
POWER STEERING GEAR
Revision: June 20062007 Versa
11. Set dial gauge to the back of rack assembly on the pinion
assembly side around the center of stroke. Measure displace-
ment of rack under to

Page 2611 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)
PS-17
C
D
E
F
H
I
J
K
L
MA
B
PS
Revision: June 20062007 Versa
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Steering WheelEGS00150
Steering AngleEGS00151
Steerin

Page 2612 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual PS-18
SERVICE DATA AND SPECIFICATIONS (SDS)
Revision: June 20062007 Versa
Steering GearEGS00154
Steering gear modelR24K
Rack neutral position, dimension “L” (rack stroke) 65.0 mm (2.559 in)
Pinion

Page 2613 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual RAX-1
REAR AXLE
D DRIVELINE/AXLE
CONTENTS
C
E
F
G
H
I
J
K
L
M
SECTION RAX
A
B
RAX
Revision: June 20062007 Versa PREPARATION ........................................................... 2
Commercial Se

Page 2614 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual RAX-2
PREPARATION
Revision: June 20062007 Versa
PREPARATIONPFP:00002
Commercial Service ToolsEDS003QY
Tool name Description
Power tool Removing wheel nuts
PBIC0190E

Page 2615 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
RAX-3
C
E
F
G
H
I
J
K
L
MA
B
RAX
Revision: June 20062007 Versa
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTINGPFP:00003
NVH Troubleshooting Ch

Page 2616 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual RAX-4
WHEEL HUB
Revision: June 20062007 Versa
WHEEL HUBPFP:43202
On-Vehicle Inspection and ServiceEDS003R0
Check the axle and suspension parts for excessive play, wear, or damage.
Shake each rear wh
