Page 1801 of 2896
EI-36
BODY SIDE TRIM
Revision: June 20062007 Versa
CENTER PILLAR UPPER GARNISH
Removal
WAR NIN G:
Do not reuse center pillar upper garnish if removed.
1. Remove center pillar lower garnish. Refer to EI-34, "
CENTER PILLAR LOWER GARNISH" .
2. Remove front seat belt shoulder anchor. Refer to SB-3,
"Removal and Installation of Front Seat Belt" .
3. Remove front and rear body side welts.
4. Release the resin clips, then remove center pillar upper garnish.
Installation
Installation is in the reverse order of removal.
REAR PILLAR FINISHER
Removal
1. Remove rear seat cushion and rear seatback. Refer to SE-15, "Removal and Installation" .
2. Remove rear body side welt.
3. Release the clips, then remove rear pillar finisher.
Installation
Installation is in the reverse order of removal.
PIIB2575J
PIIB2658J
Page 1802 of 2896
FLOOR TRIM
EI-37
C
D
E
F
G
H
J
K
L
MA
B
EI
Revision: June 20062007 Versa
FLOOR TRIMPFP:74902
Removal and InstallationEIS0096Y
REMOVAL
1. Disconnect both the negative and positive battery cables, then wait at least 3 minutes.
2. Remove front seat assembly RH/LH and rear seat cushion. Refer to SE-12, "
Removal and Installation"
and SE-15, "Removal and Installation" .
3. Remove center console and floor bracket. Refer to IP-11, "
Removal and Installation" .
4. Remove instrument lower cover. Refer to IP-11, "
Removal and Installation" .
1. Clip C101 2. Steering column shaft cover 3. Floor carpet hook
4. Front floor spacer 5. Rear floor spacer 6. Floor trim
Metal clip Clip CF110⇐Vehicle front
LIIA2575E
Page 1803 of 2896
EI-38
FLOOR TRIM
Revision: June 20062007 Versa
5. Remove front kicking plate inner RH/LH, center pillar lower garnish RH/LH, and rear kicking plate inner
RH/LH. Refer to EI-32, "
Removal and Installation" .
6. Disconnect floor harness connector.
7. Remove diagnosis sensor unit. Refer to SRS-52, "
DIAGNOSIS
SENSOR UNIT" .
8. Remove key interlock cable. Refer to AT - 2 3 9 , "
KEY INTER-
LOCK CABLE" .
9. Remove floor carpet hook.
10. Cut floor trim using a blade knife first between openings (1),
then at front edge (2) as shown.
11. Release floor trim metal clips after cutting, then pull out floor trim through door opening.
12. Remove floor spacer RH/LH.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
When replacing the floor trim with a new one, prepare for installation by cutting it like the old one.
Make sure there is a quality fit between floor trim and instrument lower cover by tucking the cut edge
completely.
PIIB6046E
PIIB2580J
PIIB6047E
Page 1804 of 2896
HEADLINING
EI-39
C
D
E
F
G
H
J
K
L
MA
B
EI
Revision: June 20062007 Versa
HEADLININGPFP:73910
Removal and InstallationEIS0096Z
LIIA2576E
Page 1805 of 2896

EI-40
HEADLINING
Revision: June 20062007 Versa
REMOVAL
1. Remove the negative and positive battery cables.
2. Remove front seat assembly RH/LH. Refer to SE-12, "
Removal and Installation" .
3. Remove rear seat cushion and rear seatback. Refer to SE-15, "
Removal and Installation" .
4. Remove front seat belt shoulder anchor RH/LH. Refer to SB-3, "
Removal and Installation of Front Seat
Belt" .
5. Remove center console body assembly. Refer to IP-10, "
INSTRUMENT PANEL ASSEMBLY" .
6. Remove front pillar garnish RH/LH. Refer to EI-33, "
FRONT PILLAR GARNISH" .
7. Remove antenna feeder cable clip, then disconnect antenna
feeder cable connector.
8. Remove front and rear kicking plate inner RH/LH, center pillar lower garnish, center pillar upper garnish,
front and rear body side welt RH/LH. Refer to EI-32, "
Removal and Installation" .
WAR NIN G:
Do not reuse center pillar upper garnish if removed.
9. Remove back door weatherstrip. Refer to EI-31, "
BACK DOOR TRIM" .
10. Release the clips using a suitable tool, then remove the front
and rear assist grips.
11. Remove the sunvisor caps and screws, then remove sunvisor RH/LH.
12. Remove sunvisor holders RH/LH by rotating 45 degrees, then
pulling outward.
1. Headlining 2. Assist grip 3. Sunvisor
4. Cap 5. Sunvisor holder 6. Roof console retainer
7. Roof console/map lamp assembly 8. Antenna feeder cable 9. Room lamp
10. Dual lock fastener 11. Room lamp harness 12. Insulator
13. Finisher A. With sunroof B. Without sunroof
Metal clip Clip C103⇐Vehicle front
PIIB2583J
PIIB2584J
PIIB3982J
Page 1806 of 2896

HEADLINING
EI-41
C
D
E
F
G
H
J
K
L
MA
B
EI
Revision: June 20062007 Versa
13. Release the metal clips, then remove the roof console/map lamp assembly.
14. Release remaining headlining clips.
15. Disconnect antenna feeder cable near rear pillar finisher LH.
16. Disengage the dual lock fastener on the backside of headlining.
Insert a suitable tool into the edge of dual lock fastener, then move the tool side to side horizontally to
release it.
CAUTION:
Excessive up and down force may cause roof panel damage.
17. Position the headlining so the front edge goes through the open-
ing of the right side front door.
18. Position the headlining so the rear edge goes through the open-
ing of the left rear door, then remove headlining.
CAUTION:
2 technicians should be used to avoid damage when
removing or replacing headlining.
During headlining removal and installation, cover the center
console finisher upper surface to prevent damage.
Set A/T shift lever to the D position, and make a space to
remove front end of headlining right side.
Do not bend headlining when removing.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
Avoid headlining damage when installing by inserting rear clips first during assembly.
PIIB2586J
PIIB6049E
PIIB6050E
Page 1807 of 2896
EI-42
LUGGAGE FLOOR TRIM
Revision: June 20062007 Versa
LUGGAGE FLOOR TRIMPFP:84920
Removal and InstallationEIS00970
1. Luggage side lower finisher RH 2. Access cover 3. Shock absorber cover RH
4. Luggage floor center board 5. Luggage floor spacer 6. Tonneau board
7. Clip C101 8. Luggage side lower finisher LH 9. Cargo lamp
10. Shock absorber cover LH 11. Luggage rear plate 12. Striker cover plate
Pawl Metal clip Clip C101
⇐Vehicle front
LIIA2578E
Page 1808 of 2896

LUGGAGE FLOOR TRIM
EI-43
C
D
E
F
G
H
J
K
L
MA
B
EI
Revision: June 20062007 Versa
REMOVAL
CAUTION:
Insert a trim stick or suitable tool between panel on vehicle
and clips (as indicated with arrow) to release clips.
Use a trim stick or suitable tool when removing metal clips
from garnishes.
Be careful not to damage the body while prying to release
clips.
Make sure clips are properly aligned in panel holes on body
when installing, then press them in completely.
1. Disconnect the negative and positive battery cables.
2. Open the rear doors and the back door.
3. Remove the rear seat cushion and seatback and seatback side
RH/LH. Refer to SE-14, "
REAR SEAT" .
4. Lift and remove the luggage floor center board and luggage floor spacer.
5. Detach the tethers, then pull upward to remove the tonneau board.
6. Release the clips, then remove the striker cover and luggage rear plate.
7. Release the clips, then remove the luggage side lower finisher RH/LH.
For LH side, disconnect cargo lamp connector.
INSTALLATION
Installation is in the reverse order of removal.
