REMOTE KEYLESS ENTRY SYSTEM
Revision: June 20062007 Versa
Work FlowEIS0091G
1. Check the symptom and customers requests.
2. Understand outline of system. Refer to BL-55, "
System Description" .

BL-64
REMOTE KEYLESS ENTRY SYSTEM
Revision: June 20062007 Versa
Work FlowEIS0091G
1. Check the symptom and customer's requests.
2. Understand outline of system. Refer to BL-55, "
System Description" .
3. Confirm that power door lock system operates normally.
Refer to BL-23, "
POWER DOOR LOCK SYSTEM" .
4. Repair or replace any malfunctioning parts.
Refer to BL-64, "
Trouble Diagnosis Symptom Chart" .
5. Does remote keyless entry system operate normally? If Yes, GO TO 6. If No, GO TO 4.
6. INSPECTION END
Trouble Diagnosis Symptom ChartEIS0091H
NOTE:
Always check the “Work Flow” before troubleshooting. Refer to BL-64, "Work Flow" .
Always check keyfob battery before replacing keyfob.
Symptom Diagnoses/service procedureReference
page
All function of remote keyless entry system do not
operate.1. Check key switch.BL-70
2. Check keyfob battery and function.
NOTE:
If the result of keyfob function check with CONSULT-II is OK, key-
fob is not malfunctioning.BL-66
3. Check remote keyless entry receiver.BL-73
4. Refer to ID Code Entry Procedure.BL-76
5. Replace BCM.BCS-25
The new ID of keyfob cannot be entered.1. Check keyfob battery and function.
NOTE:
If the result of keyfob function check with CONSULT-II is OK, key-
fob is not malfunctioning.BL-662. Check key switch.BL-70
3. Check door switch.BL-68
4. Check ACC switch.BL-67
5. Replace keyfob. Refer to ID Code Entry Procedure.BL-76
6. Replace BCM.BCS-25
Door lock does not function with keyfob.
(Power door lock system is “OK”.)1. Check keyfob function. (Lock)
NOTE:
If the result of keyfob function check with CONSULT-II is OK, key-
fob is not malfunctioning.BL-75
2. Replace keyfob. Refer to ID Code Entry Procedure.BL-76
3. Check door switch.BL-68
4. Replace BCM.BCS-25
Door unlock does not function with keyfob
(Power door lock system is “ON”)1. Check keyfob function. (Unlock)BL-75
2. Replace keyfob. Refer to ID Code Entry Procedure.
NOTE:
If the result of keyfob function check with CONSULT-II is OK, key-
fob is not malfunctioning.BL-76
3. Replace BCM.BCS-25
Hazard reminder does not activate properly when
pressing lock or unlock button of keyfob.1. Check hazard reminder mode.*
*: Hazard reminder mode can be changed.
First check the hazard reminder setting.BL-61
2. Check hazard function.BL-71
3. Replace BCM.BCS-25

Page 554 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual REMOTE KEYLESS ENTRY SYSTEM
BL-65
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: June 20062007 Versa
Panic alarm does not activate when panic alarm
button is continuously pressed.1. Check panic alarm mode.*
*:

Page 555 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual BL-66
REMOTE KEYLESS ENTRY SYSTEM
Revision: June 20062007 Versa
Keyfob Battery and Function CheckEIS0091I
1. CHECK KEYFOB BATTERY
1. Remove keyfob battery. Refer to BL-78, "
Keyfob Battery Replacement

Page 556 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual REMOTE KEYLESS ENTRY SYSTEM
BL-67
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: June 20062007 Versa
ACC Switch CheckEIS0091J
1. CHECK ACC SWITCH
With CONSULT-II
Check ACC switch (“ACC ON SW”) in “DATA MO

Page 557 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual BL-68
REMOTE KEYLESS ENTRY SYSTEM
Revision: June 20062007 Versa
Door Switch CheckEIS009CF
1. CHECK DOOR SWITCHES INPUT SIGNAL
With CONSULT-II
Check door switches ("DOOR SW-DR", "DOOR SW-AS", "DOOR SW

Page 558 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual REMOTE KEYLESS ENTRY SYSTEM
BL-69
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: June 20062007 Versa
2. CHECK DOOR SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect door switch and BCM.
3. Check continui

Page 559 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual BL-70
REMOTE KEYLESS ENTRY SYSTEM
Revision: June 20062007 Versa
4. CHECK BACK DOOR SWITCH GROUND
Check continuity between back door lock assembly connector D405
terminal 4 and ground.
OK or NG
OK >> B

Page 560 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual REMOTE KEYLESS ENTRY SYSTEM
BL-71
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: June 20062007 Versa
2. CHECK KEY SWITCH
