Page 1241 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual EC-72Revision: June 2006 BASIC SERVICE PROCEDURE 2007 Versa 6. PERFORM IDLE AIR VOLUME LEARNING Refer to EC-78, " Idle Air Volume Learning" . Is Idle Air Volume Learning carried out successfully? Ye s

Page 1242 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual BASIC SERVICE PROCEDURE EC-73 C D E F G H I J K L MA EC Revision: June 20062007 Versa 10. CHECK IGNITION TIMING 1. Run engine at idle. 2. Check ignition timing with a timing light. Refer to EC-75, " I

Page 1243 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual EC-74Revision: June 2006 BASIC SERVICE PROCEDURE 2007 Versa 14. CHECK TARGET IDLE SPEED AGAIN With CONSULT-II 1. Start engine and warm it up to normal operating temperature. 2. Read idle speed in “

Page 1244 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual BASIC SERVICE PROCEDURE EC-75 C D E F G H I J K L MA EC Revision: June 20062007 Versa 18. CHECK ECM FUNCTION 1. Substitute another known-good ECM to check ECM function. (ECM may be the cause of an in

Page 1245 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual EC-76Revision: June 2006 BASIC SERVICE PROCEDURE 2007 Versa 2. Check ignition timing. Timing indicator (1) Method B 1. Remove No. 4 ignition coil (1).  : Vehicle front 2. Connect No. 4 ignition coil

Page 1246 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual BASIC SERVICE PROCEDURE EC-77 C D E F G H I J K L MA EC Revision: June 20062007 Versa Timing indicator (1) Procedure After Replacing ECMUBS00QO6 When replacing ECM, the following procedure must be pe

Page 1247 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual EC-78Revision: June 2006 BASIC SERVICE PROCEDURE 2007 Versa Throttle Valve Closed Position LearningUBS00QO9 DESCRIPTION Throttle Valve Closed Position Learning is an operation to learn the fully close

Page 1248 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual BASIC SERVICE PROCEDURE EC-79 C D E F G H I J K L MA EC Revision: June 20062007 Versa OPERATION PROCEDURE With CONSULT-II 1. Perform EC-77, "Accelerator Pedal Released Position Learning" . 2. Perform
