NISSAN VERSA 2006 Workshop Service Repair Manual CVT-56
TROUBLE DIAGNOSIS
Revision: June 20062007 Versa
41 GTransmission
fluid pressure
sensor B (Pri-
mary pressure
sensor)and “N” position idle 0.7 V
42 LG Sensor ground Always 0 V
46 O Sen

Page 954 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual TROUBLE DIAGNOSIS
CVT-57
D
E
F
G
H
I
J
K
L
MA
B
CVT
Revision: June 20062007 Versa
CONSULT-II Function (TRANSMISSION)UCS005YI
CONSULT-II can display each diagnostic item using the diagnostic test modes

TROUBLE DIAGNOSIS
CVT-57
D
E
F
G
H
I
J
K
L
MA
B
CVT
Revision: June 20062007 Versa
CONSULT-II Function (TRANSMISSION)UCS005YI
CONSULT-II can display each diagnostic item using the diagnostic test modes shown below.
FUNCTION
CONSULT-II REFERENCE VALUE
Diagnostic test mode Function Reference page
Work supportThis mode enables a technician to adjust some devices faster and more accurately by
following the indications on CONSULT-II.CVT-59
Self-diagnostic results Self-diagnostic results can be read and erased quickly.CVT-60
Data monitor Input/Output data in the TCM can be read.CVT-64
CAN diagnostic support
monitorThe results of transmit/receive diagnosis of CAN communication can be read.CVT-66
CALIB data Characteristic information for TCM and CVT assembly can be read. —
Function testPerformed by CONSULT-II instead of a technician to determine whether each system
is “OK” or “NG”.—
ECU part number TCM part number can be read. —
Item name Condition Display value (Approx.)
VSP SENSOR
During drivingApproximately matches the speedometer
reading.
ESTM VSP SIG*
PRI SPEED SEN During driving (lock-up ON) Approximately matches the engine speed.
ENG SPEED SIG Engine running Closely matches the tachometer reading.
SEC HYDR SEN “N” position idle 1.0 V
PRI HYDR SEN “N” position idle 0.7 V
AT F T E M P S E NWhen CVT fluid temperature is 20°C (68°F). 2.0 V
When CVT fluid temperature is 80°C (176°F). 1.0 V
VIGN SEN Ignition switch: ON Battery voltage
VEHICLE SPEED During drivingApproximately matches the speedometer
reading.
PRI SPEED During driving (lock-up ON) Approximately matches the engine speed.
SEC SPEED During driving50 X Approximately matches the speed-
ometer reading.
ENG SPEED Engine running Closely matches the tachometer reading.
GEAR RATIO During driving 2.56 - 0.43
ACC PEDAL OPENReleased accelerator pedal - Fully depressed
accelerator pedal0.0/8 - 8.0/8
SEC PRESS “N” position idle 0.8 MPa
PRI PRESS “N” position idle 0.4 MPa
STM STEP During driving−20 step - 180 step
ISOLT1Lock-up OFF 0.0 A
Lock-up ON 0.7 A
ISOLT2Release your foot from the accelerator pedal. 0.8 A
Press the accelerator pedal all the way down. 0.0 A
ISOLT3Secondary pressure low - Secondary pressure
high.0.8 - 0.0 A
SOLMON1Lock-up OFF 0.0 A
Lock-up ON 0.7 A
SOLMON2“N” position idle 0.8 A
When stalled 0.3 - 0.6 A

Page 955 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual CVT-58
TROUBLE DIAGNOSIS
Revision: June 20062007 Versa
SOLMON3“N” position idle 0.6 - 0.7 A
When stalled 0.4 - 0.6 A
INH SW3MSelector lever in “D” and “L” positions ON
Selector lever in �

CVT-58
TROUBLE DIAGNOSIS
Revision: June 20062007 Versa
SOLMON3“N” position idle 0.6 - 0.7 A
When stalled 0.4 - 0.6 A
INH SW3MSelector lever in “D” and “L” positions ON
Selector lever in “P”, “R” and “N” positions OFF
INH SW4Selector lever in “R” and “D” positions ON
Selector lever in “P”, “N” and “L” positions OFF
INH SW3Selector lever in “D” and “L” positions ON
Selector lever in “P”, “R” and “N” positions OFF
INH SW2Selector lever in “N”, “D” and “L” positions ON
Selector lever in “P” and “R” positions OFF
INH SW1Selector lever in “R”, “N” and “D” positions ON
Selector lever in “P” and “L” positions OFF
BRAKE SWDepressed brake pedal ON
Released brake pedal OFF
FULL SWFully depressed accelerator pedal ON
Released accelerator pedal OFF
IDLE SWReleased accelerator pedal ON
Fully depressed accelerator pedal OFF
SPORT MODE SWWhile pushing overdrive cancel switch ON
Other conditions OFF
INDDRNGSelector lever in “D” position ON
Selector lever in other positions OFF
INDLRNGSelector lever in “L” position ON
Selector lever in other positions OFF
INDNRNGSelector lever in “N” position ON
Selector lever in other positions OFF
INDRRNGSelector lever in “R” position ON
Selector lever in other positions OFF
INDPRNGSelector lever in “P” position ON
Selector lever in other positions OFF
SMCOIL D
During driving Changes ON ⇔ OFF. SMCOIL C
SMCOIL B
SMCOIL A
LUSEL SOL OUTSelector lever in “P” and “N” positions ON
Wait at least for 5 seconds with the selector
lever in “R”, “D” and “L” positionsOFF
STRTR RLY OUTSelector lever in “P” and “N” positions ON
Selector lever in other positions OFF
STRTR RLY MONSelector lever in “P” and “N” positions ON
Selector lever in other positions OFF
RANGESelector lever in “N” or “P” position. N·P
Selector lever in “R” position. R
Selector lever in “D” position. D
Selector lever in “L” position. L Item name Condition Display value (Approx.)

Page 956 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual TROUBLE DIAGNOSIS
CVT-59
D
E
F
G
H
I
J
K
L
MA
B
CVT
Revision: June 20062007 Versa
*: Models without ABS does not indicate.
CONSULT-II SETTING PROCEDURE
Refer to GI-38, "CONSULT-II Start Procedure" .
W

Page 957 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual CVT-60
TROUBLE DIAGNOSIS
Revision: June 20062007 Versa
CAUTION:
Mode of “+1” “0” “-1” “-2” “OFF” can be selected by pressing the “UP” “DOWN” on CONSULT-II
screen. However,

Page 958 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual TROUBLE DIAGNOSIS
CVT-61
D
E
F
G
H
I
J
K
L
MA
B
CVT
Revision: June 20062007 Versa
Operation Procedure
1. Touch “SELF-DIAG RESULTS” on “SELECT DIAG MODE”.
Display shows malfunction experienced

TROUBLE DIAGNOSIS
CVT-61
D
E
F
G
H
I
J
K
L
MA
B
CVT
Revision: June 20062007 Versa
Operation Procedure
1. Touch “SELF-DIAG RESULTS” on “SELECT DIAG MODE”.
Display shows malfunction experienced since the last erasing
operation.
Display Items List
X: Applicable —: Not applicable
BCIA0031E
Items (CONSULT-
II screen terms)Malfunction is detected when...TCM self-
diagnosisOBD-II (DTC)
Reference
page “TRANS-
MISSION”
with CON-
SULT-IIMIL indicator
lamp*1,
“ENGINE” with
CONSULT-II or
GST
CAN COMM CIR-
CUITWhen TCM is not transmitting or receiving CAN communica-
tion signal for 2 seconds or moreU1000 U1000CVT-68
CONTROL
UNIT(CAN)When detecting error during the initial diagnosis of CAN con-
troller of TCMU1010 U1010CVT-71
STARTER RELAY/
CIRCIf this signal is ON other than in “P” or “N” position, this is
judged to be a malfunction
(And if it is OFF in “P” or “N” position, this is judged to be a
malfunction too)P0615 —CVT-72
BRAKE SW/CIRC When the brake switch does not switch to ON or OFF P0703 —CVT-76
PNP SW/CIRCPNP switch 1-4 signals input with impossible pattern
PNP switch 3 monitor terminal open or short circuitP0705 P0705CVT-78
AT F T E M P S E N /
CIRCDuring running, the CVT fluid temperature sensor signal volt-
age is excessively high or lowP0710 P0710CVT-85
INPUT SPD SEN/
CIRCInput speed sensor (primary speed sensor) signal is not
input due to an open circuit
An unexpected signal is input when vehicle is being drivenP0715 P0715CVT-90
VEH SPD SEN/
CIR AT
Signal from vehicle speed sensor CVT [Output speed sen-
sor (Secondary speed sensor)] not input due to open or
short circuit
Unexpected signal input during runningP0720 P0720CVT-95
ENGINE SPEED
SIGTCM does not receive the CAN communication signal
from the ECM
Engine speed is too low while drivingP0725 —CVT-101
BELT DAMG Unexpected gear ratio detected P0730 —CVT-103
TCC SOLENOID/
CIRCNormal voltage not applied to solenoid due to open or short
circuitP0740 P0740CVT-105
A/T TCC S/V
FNCTN
CVT cannot perform lock-up even if electrical circuit is
good
TCM detects as irregular by comparing difference value
with slip rotation
There is big difference engine speed and primary speed
when TCM lock-up signal is onP0744 P0744CVT-110

Page 959 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual CVT-62
TROUBLE DIAGNOSIS
Revision: June 20062007 Versa
L/PRESS SOL/
CIRC
Normal voltage not applied to solenoid due to open or
short circuit
TCM detects as irregular by comparing target value with

CVT-62
TROUBLE DIAGNOSIS
Revision: June 20062007 Versa
L/PRESS SOL/
CIRC
Normal voltage not applied to solenoid due to open or
short circuit
TCM detects as irregular by comparing target value with
monitor valueP0745 P0745CVT-113
PRS CNT SOL/A
FCTNUnexpected gear ratio was detected in the LOW side due to
excessively low line pressureP0746 P0746CVT-118
PRS CNT SOL/B
FCTNSecondary pressure is too high or too low compared with the
commanded value while drivingP0776 P0776CVT-121
PRS CNT SOL/B
CIRC
Normal voltage not applied to solenoid due to cut line,
short, or the like
TCM detects as irregular by comparing target value with
monitor valueP0778 P0778CVT-124
TR PRS SENS/A
CIRCSignal voltage of the transmission fluid pressure sensor A
(secondary pressure sensor) is too high or too low while driv-
ingP0840 P0840CVT-129
PRESS SEN/
FNCTNCorrelation between the values of the transmission fluid
pressure sensor A (secondary pressure sensor) and the
transmission fluid pressure sensor B (primary pressure sen-
sor) is out of specificationP0841 —CVT-134
TR PRS SENS/B
CIRCSignal voltage of the transmission fluid pressure sensor B
(primary pressure sensor) is too high or too low while drivingP0845 P0845CVT-137
SEC/PRESS
DOWNSecondary fluid pressure is too low compared with the com-
manded value while drivingP0868 —CVT-142
TCM-POWER
SUPPLY
When the power supply to the TCM is cut OFF, for exam-
ple because the battery is removed, and the self-diagnosis
memory function stops
This is not a malfunction message (Whenever shutting
OFF a power supply to the TCM, this message appears on
the screen)P1701 —CVT-145
TP SEN/CIRC A/TTCM does not receive the proper accelerator pedal position
signals (input by CAN communication) from ECMP1705 —CVT-150
ESTM VEH SPD
SIG*2
CAN communication with the ABS actuator and the elec-
tric unit (control unit) is malfunctioning
There is a great difference between the vehicle speed sig-
nal from the ABS actuator and the electric unit (control
unit), and the vehicle speed sensor signalP1722 —CVT-152
CVT SPD SEN/
FNCTNA rotation sensor error is detected because the gear does
not change in accordance with the position of the stepping
motor
CAUTION:
One of the “P0720 VEH SPD SEN/CIR AT”, the “P0715
INPUT SPD SEN/CIRC” or the “P0725 ENGINE SPEED
SIG“ is displayed with the DTC at the same timeP1723 —CVT-154
ELEC TH CON-
TROLThe electronically controlled throttle for ECM is malfunction-
ingP1726 —CVT-156
LU-SLCT SOL/
CIRC
Normal voltage not applied to solenoid due to cut line,
short, or the like
TCM detects as irregular by comparing target value with
monitor valueP1740 P1740CVT-158
Items (CONSULT-
II screen terms)Malfunction is detected when...TCM self-
diagnosisOBD-II (DTC)
Reference
page “TRANS-
MISSION”
with CON-
SULT-IIMIL indicator
lamp*1,
“ENGINE” with
CONSULT-II or
GST

Page 960 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual TROUBLE DIAGNOSIS
CVT-63
D
E
F
G
H
I
J
K
L
MA
B
CVT
Revision: June 20062007 Versa
*1: Refer to CVT-33, "Malfunction Indicator Lamp (MIL)" .
*2: Models without ABS does not indicate.
How to Erase Self-

Load next 8 pages

Page: < prev 1-10 ... 921-928 929-936 937-944 945-952 953-960 961-968 969-976 977-984 985-992 ... 2896 next >

maintenance reset brake tyre pressure garage door opener refuelling check transmission fluid
