ENGINE ASSEMBLY
2007 Versa
Use either 2-pole lift type or separate type lift as best you can. If board-on type is used for
unavoidable reasons, support at the rear axle jacking point with a transmission jack or similar tool
before starting work, in preparation for the backward shift of center of gravity.
For supporting points for lifting and jacking point at rear axle, refer to GI-42, "Garage Jack and
Safety Stand and 2-Pole Lift" .
REMOVAL
Remove the engine and the transaxle assembly from the vehicle downward. Separate the engine and the tran-
saxle.
1. Remove engine undercover
2. Drain engine coolant from radiator. Refer to CO-8, "
Changing Engine Coolant" .
CAUTION:
Perform this step when the engine is cold.
Do not spill engine coolant on drive belt.
3. Remove front fender protector (RH and LH); Refer to EI-22, "
FENDER PROTECTOR" .
4. Remove exhaust front tube; Refer to EX-3, "
EXHAUST SYSTEM" .
5. Remove drive shafts (LH and RH) from steering knuckle. Refer to FAX-8, "
FRONT DRIVE SHAFT" .
6. Remove transaxle joint bolts which pierce at oil pan (upper) lower rear side. Refer to AT - 2 5 3 , "
TRAN-
SAXLE ASSEMBLY" (A/T models), CVT-207, "TRANSAXLE ASSEMBLY" (CVT) or MT-15, "TRAN-
SAXLE ASSEMBLY" (M/T models).
7. Remove rear torque rod (1).
NOTE:
A/T model shown CVT and M/T models similar.
8. Remove hood assembly. Refer to BL-14, "
HOOD" .
9. Remove cowl top cover and cowl top extension assembly. Refer to EI-20, "
COWL TOP" .
10. Release fuel pressure. Refer to EC-81, "
FUEL PRESSURE RELEASE" .
11. Remove battery and battery tray; Refer to SC-4, "
BATTERY" .
12. Remove drive belt; Refer to EM-13, "
Components" .
13. Remove air duct and air cleaner case assembly; Refer to EM-16, "
AIR CLEANER AND AIR DUCT" .
14. Remove cooling fan assembly.
15. Remove radiator hose (upper and lower). Refer to CO-11, "
RADIATOR" .
16. Disconnect A/T, CVT fluid cooler hoses. Refer to CO-11, "
RADIATOR"
17. Disconnect all connections of engine harness around the engine mounting insulator (LH), and then tem-
porarily secure the engine harness into the engine side.
CAUTION:
Protect connectors using a resin bag to protect against foreign materials during the operation.
18. Disconnect fuel feed hose at engine side. Refer to EM-33, "
Components" .
19. Disconnect heater hoses, and install plugs them to prevent engine coolant from draining. Refer to CO-20,
"Components" .
20. Disconnect control cable from transaxle. Refer to CVT-191, "
SHIFT CONTROL SYSTEM" (CVT) or AT -
229, "SHIFT CONTROL SYSTEM" (A/T), MT-12, "CONTROL LINKAGE" (MT).
21. Remove ground cable at transaxle side.
22. Remove ground cable between front cover and vehicle.
23. Remove alternator. Refer to SC-24, "
CHARGING SYSTEM" .
LBIA0460E
GI-4
PRECAUTIONS
Revision: June 20062007 Versa
For this reason, if the battery is disconnected or if the battery is discharged, the steering wheel will lock and
steering wheel rotation will become impossible.
If steering wheel rotation is required when battery power is interrupted, follow the procedure below before
starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables.
NOTE:
Supply power using jumper cables if battery is discharged.
2. Use the Intelligent Key or mechanical key to turn the ignition switch to the ″ACC″ position. At this time, the
steering lock will be released.
3. Disconnect both battery cables. The steering lock will remain released and the steering wheel can be
rotated.
4. Perform the necessary repair operation.
5. When the repair work is completed, return the ignition switch to the ″LOCK″ position before connecting
the battery cables. (At this time, the steering lock mechanism will engage.)
6. Perform a self-diagnosis check of all control units using CONSULT-II.
General PrecautionsEAS001ZA
Do not operate the engine for an extended period of time without
proper exhaust ventilation.
Keep the work area well ventilated and free of any flammable
materials. Special care should be taken when handling any flam-
mable or poisonous materials, such as gasoline, refrigerant gas,
etc. When working in a pit or other enclosed area, be sure to
properly ventilate the area before working with hazardous mate-
rials.
Do not smoke while working on the vehicle.
Before jacking up the vehicle, apply wheel chocks or other tire
blocks to the wheels to prevent the vehicle from moving. After
jacking up the vehicle, support the vehicle weight with safety
stands at the points designated for proper lifting before working
on the vehicle.
These operations should be done on a level surface.
When removing a heavy component such as the engine or tran-
saxle/transmission, be careful not to lose your balance and drop
them. Also, do not allow them to strike adjacent parts, especially
the brake tubes and master cylinder.
Before starting repairs which do not require battery power:
Turn off ignition switch.
Disconnect the negative battery terminal.
If the battery terminals are disconnected, recorded memory of
radio and each control unit is erased.
Battery posts, terminals and related accessories contain lead
and lead compounds. Wash hands after handling.
SGI285
SGI231
SEF 2 89 H
