2006 NISSAN VERSA spark plugs

TROUBLE DIAGNOSIS
EC-83
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: June 20062007 Versa
TROUBLE DIAGNOSISPFP:00004
Trouble Diagnosis IntroductionUBS00PKE
INTRODUCTION
The engine has an ECM to control major systems such as fuel con-
trol, ignition control, idle air control system, etc. The ECM accepts
input signals from sensors and instantly drives actuators. It is essen-
tial that both input and output signals are proper and stable. At the
same time, it is important that there are no malfunctions such as vac-
uum leaks, fouled spark plugs, or other malfunctions with the engine.
It is much more difficult to diagnose an incident that occurs intermit-
tently rather than continuously. Most intermittent incidents are
caused by poor electric connections or improper wiring. In this case,
careful checking of suspected circuits may help prevent the replace-
ment of good parts.
A visual check only may not find the cause of the incidents. A road
test with CONSULT-II (or GST) or a circuit tester connected should
be performed. Follow the Work Flow on EC-84, "
WORK FLOW" .
Before undertaking actual checks, take a few minutes to talk with a
customer who approaches with a driveability complaint. The cus-
tomer can supply good information about such incidents, especially
intermittent ones. Find out what symptoms are present and under
what conditions they occur. A Diagnostic Worksheet like the example
on EC-88, "
Worksheet Sample" should be used.
Start your diagnosis by looking for conventional malfunctions first.
This will help troubleshoot driveability malfunctions on an electroni-
cally controlled engine vehicle.
MEF036D
SEF 2 33 G
SEF 2 34 G

EC-312Revision: June 2006
DTC P0300 - P0304 MULTIPLE CYLINDER MISFIRE, NO. 1 - 4 CYLINDER MIS-
FIRE
2007 Versa
7. CHECK SPARK PLUG
Check the initial spark plug for fouling, etc.
OK or NG
OK >> Replace spark plug(s) with standard type one(s). For
spark plug type, refer to MA-18, "
Changing Spark Plugs"
.
NG >> 1. Repair or clean spark plug.
2. GO TO 8.
8. CHECK FUNCTION OF IGNITION COIL-III
1. Reconnect the initial spark plugs.
2. Crank engine for about three seconds, and recheck whether spark is generated between the spark plug
and the grounded portion.
OK or NG
OK >>INSPECTION END
NG >> Replace spark plug(s) with standard type one(s). For spark plug type, refer to MA-18, "
Changing
Spark Plugs" .
9. CHECK COMPRESSION PRESSURE
Check compression pressure. Refer to EM-62, "
CHECKING COMPRESSION PRESSURE" .
OK or NG
OK >> GO TO 10.
NG >> Check pistons, piston rings, valves, valve seats and cylinder head gaskets.
10. CHECK FUEL PRESSURE
1. Install all removed parts.
2. Release fuel pressure to zero. Refer to EC-81, "
FUEL PRESSURE RELEASE" .
3. Install fuel pressure gauge and check fuel pressure. Refer to EC-81, "
FUEL PRESSURE CHECK" .
OK or NG
OK >> GO TO 12.
NG >> GO TO 11.
11 . DETECT MALFUNCTIONING PART
Check the following.

Fuel pump and circuit (Refer to EC-570, "FUEL PUMP" .)

Fuel pressure regulator (Refer to EC-81, "FUEL PRESSURE CHECK" .)

Fuel lines (Refer to EM-33, "FUEL INJECTOR AND FUEL TUBE" .)

Fuel filter for clogging
>> Repair or replace.
SEF 1 56 I
Spark should be generated.
At idling: Approximately 350 kPa (3.57 kg/cm
2 , 51 psi)

EC-338Revision: June 2006
DTC P0420 THREE WAY CATALYST FUNCTION
2007 Versa
7. CHECK FUNCTION OF IGNITION COIL-II
1. Turn ignition switch OFF.
2. Disconnect spark plug and connect a known-good spark plug.
3. Crank engine for about 3 seconds, and recheck whether spark is generated between the spark plug and
the grounded metal portion.
OK or NG
OK >> GO TO 8.
NG >> Check ignition coil, power transistor and their circuits. Refer to EC-576, "
IGNITION SIGNAL" .
8. CHECK SPARK PLUG
Check the initial spark plug for fouling, etc.
OK or NG
OK >> Replace spark plug(s) with standard type one(s). For
spark plug type, refer to MA-18, "
Changing Spark Plugs"
.
NG >> 1. Repair or clean spark plug.
2. GO TO 9.
9. CHECK FUNCTION OF IGNITION COIL-III
1. Reconnect the initial spark plugs.
2. Crank engine for about 3 seconds, and recheck whether spark is generated between the spark plug and
the grounded portion.
OK or NG
OK >>INSPECTION END
NG >> Replace spark plug(s) with standard type one(s). For spark plug type, refer to MA-18, "
Changing
Spark Plugs" .
10. CHECK FUEL INJECTOR
1. Turn ignition switch OFF.
2. Remove fuel injector assembly.
Refer to EM-33, "
FUEL INJECTOR AND FUEL TUBE" .
Keep fuel hose and all fuel injectors connected to fuel tube.
3. Disconnect all ignition coil harness connectors.
4. Reconnect all fuel injector harness connectors disconnected.
5. Turn ignition switch ON.
Make sure fuel does not drip from fuel injector.
OK or NG
OK (Does not drip.)>>GO TO 11.
NG (Drips.)>>Replace the fuel injector(s) from which fuel is dripping.Spark should be generated.
SEF 1 56 I
Spark should be generated.

MA-1
MAINTENANCE
L MAINTENANCE
CONTENTS
C
D
E
F
G
H
I
J
K
M
SECTION MA
A
B
MA
Revision: June 20062007 Versa PRECAUTIONS .......................................................... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 3
PREPARATION ........................................................... 4
Special Service Tools ............................................... 4
Commercial Service Tools ........................................ 4
GENERAL MAINTENANCE ....................................... 5
Explanation of General Maintenance ....................... 5
General Maintenance ............................................... 5
PERIODIC MAINTENANCE ....................................... 7
Introduction of Periodic Maintenance ....................... 7
Schedule 1 ............................................................... 7
EMISSION CONTROL SYSTEM MAINTE-
NANCE .................................................................. 7
CHASSIS AND BODY MAINTENANCE ............... 8
Schedule 2 ............................................................... 9
EMISSION CONTROL SYSTEM MAINTE-
NANCE .................................................................. 9
CHASSIS AND BODY MAINTENANCE ............. 10
RECOMMENDED FLUIDS AND LUBRICANTS .......11
Fluids and Lubricants ..............................................11
SAE Viscosity Number ........................................... 12
Anti-freeze Coolant Mixture Ratio .......................... 12
ENGINE MAINTENANCE ......................................... 13
Drive Belts .............................................................. 13
Checking Drive Belts .............................................. 13
Tension Adjustment ................................................ 13
Changing Engine Coolant ...................................... 13
DRAINING ENGINE COOLANT ......................... 13
REFILLING ENGINE COOLANT ........................ 14
FLUSHING COOLING SYSTEM ......................... 15
Inspection ............................................................... 15
LEVEL CHECK ................................................... 15
CHECKING COOLING SYSTEM FOR LEAKS ... 15
Checking Fuel Lines ............................................... 15
Changing Air Cleaner Filter .................................... 16
REMOVAL ........................................................... 16
INSPECTION AFTER REMOVAL ....................... 16
INSTALLATION ................................................... 16Changing Engine Oil ............................................... 16
Engine Oil Filter ...................................................... 17
REMOVAL ........................................................... 17
INSTALLATION ................................................... 17
INSPECTION AFTER INSTALLATION ................ 18
Changing Spark Plugs ............................................ 18
............................................................................ 18
INSPECTION AFTER REMOVAL ....................... 18
INSTALLATION ................................................... 19
Checking EVAP Vapor Lines .................................. 19
CHASSIS AND BODY MAINTENANCE ................... 20
Changing In-cabin Microfilter .................................. 20
Checking Exhaust System ...................................... 20
Checking CVT Fluid ................................................ 20
FLUID LEVEL CHECK ........................................ 20
FLUID CONDITION CHECK ............................... 21
Changing CVT Fluid ............................................... 21
Checking Clutch Fluid Level and Leaks ................. 22
Checking Clutch System ........................................ 22
Checking M/T Oil .................................................... 22
OIL LEAKAGE AND OIL LEVEL ......................... 22
Changing M/T Oil .................................................... 22
DRAINING ........................................................... 22
FILLING ............................................................... 22
Checking A/T Fluid ................................................. 22
Changing A/T Fluid ................................................. 23
Balancing Wheels ................................................... 24
Rotation .................................................................. 24
Checking Brake Fluid Level and Leaks .................. 24
Checking Brake Lines and Cables ......................... 24
Changing Brake Fluid ............................................. 25
Checking Disc Brake .............................................. 25
ROTOR ................................................................ 25
CALIPER ............................................................. 25
PAD ..................................................................... 25
WHEEL CYLINDER ............................................ 26
LINING ................................................................ 26
Axle and Suspension Parts .................................... 26
Drive Shaft .............................................................. 27

PERIODIC MAINTENANCE
MA-7
C
D
E
F
G
H
I
J
K
MA
B
MA
Revision: June 20062007 Versa
PERIODIC MAINTENANCEPFP:00026
Introduction of Periodic MaintenanceELS001YD
Two different maintenance schedules are provided, and should be used, depending upon the conditions in
which the vehicle is mainly operated. After 60,000 miles (96,000 km) or 48 months, continue the periodic
maintenance at the same mileage/time intervals.
Schedule 1ELS001YE
EMISSION CONTROL SYSTEM MAINTENANCE
Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. [ ]: At the mileage intervals only Schedule 1Follow Periodic Maintenance Schedule 1 if your driving habits frequently includes
one or more of the following driving conditions:

Repeated short trips of less than 5 miles (8 km).

Repeated short trips of less than 10 miles (16 km) with outside temperatures
remaining below freezing.

Operating in hot weather in stop-and-go “rush hour” traffic.

Extensive idling and/or low speed driving for long distances, such as police,
taxi or door-to-door delivery use.

Driving in dusty conditions.

Driving on rough, muddy, or salt spread roads.

Towing a trailer, using a camper or a car-top carrier.Emission Control Sys-
tem MaintenanceMA-7
Chassis and Body
Maintenance
MA-8
Schedule 2Follow Periodic Maintenance Schedule 2 if none of the driving conditions shown
in Schedule 1 apply to your driving habits.Emission Control Sys-
tem MaintenanceMA-9Chassis and Body
MaintenanceMA-10
MAINTENANCE OPERATIONMAINTENANCE INTERVAL
Reference Section -
Page or - Content Title Perform at number of
miles, kilometers or
months, whichever
comes first.Miles x
1,000
(km x 1,000)
Months3.75
(6)
37.5
(12)
611 . 2 5
(18)
915
(24)
1218.75
(30)
1522.5
(36)
1826.25
(42)
2130
(48)
24
Drive belt NOTE (1)MA-13
Air cleaner filter NOTE (2) [R]MA-16
EVAP vapor linesI*MA-19
Fuel linesI*MA-15
Fuel filter NOTE (3)—
Engine coolant NOTE (4)MA-13
Engine oil R R R R R R R RMA-16
Engine oil filter (Use
genuine oil filter or
equivalent)RRRRRRRRMA-17
Spark plugs (Iridium/
platinum-tipped type)Replace every 105,000 miles (169,000 km)MA-18
Intake and exhaust
valve clearance NOTE (5)EM-107, "Va lv e C l e a r -
ance"

MA-8
PERIODIC MAINTENANCE
Revision: June 20062007 Versa
Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. [ ]: At the mileage intervals only
(1) After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found
damaged.
(2) If operating mainly in dusty conditions, more frequent maintenance may be required.
(3) Maintenance-free item. For service procedures, go to the FL section.
(4) After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months.
(5) If valve noise increases, inspect valve clearance.
* Maintenance items and intervals with “*” are recommended by NISSAN for reliable vehicle operation. The owner need not perform
such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are
required.
CHASSIS AND BODY MAINTENANCE
Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. L = Lubricate. MAINTENANCE OPERATIONMAINTENANCE INTERVAL
Reference Section -
Page or - Content Title Perform at number of
miles, kilometers or
months, whichever
comes first.Miles x
1,000
(km x
1,000)
Months33.75
(54)
2737.5
(60)
3041.25
(66)
3345
(72)
3648.75
(78)
3952.5
(84)
4256.25
(90)
4560
(96)
48
Drive beltNOTE
(1)I*MA-13
Air cleaner filterNOTE
(2)[R]MA-16
EVAP vapor linesI*MA-19
Fuel linesI*MA-15
Fuel filterNOTE
(3)—
Engine coolantNOTE
(4)R*MA-13
Engine oil R R R R R R R RMA-16
Engine oil filter (Use
genuine oil filter or
equivalent)RRRRRRRRMA-17
Spark plugs (Iridium/
platinum-tipped type)Replace every 105,000 miles (169,000 km)MA-18
Intake and exhaust
valve clearance NOTE
(5)EM-107
MAINTENANCE OPERATIONMAINTENANCE INTERVAL
Reference
Section -
Page or -
Content Title Perform at number of
miles, kilometers or
months, whichever
comes first.Miles x
1,000
(km x
1,000)
Months3.75
(6)
37.5
(12)
611 . 2 5
(18)
915
(24)
1218.75
(30)
1522.5
(36)
1826.25
(42)
2130
(48)
24
Brake lines & cables I IMA-24
Brake pads, rotors,
drums & liningsIIIIMA-25
Manual transaxle oil
or automatic tran-
saxle fluidNOTE (1) I IMA-20 , MA-
22 or MA-22
CVT fluid NOTE (2) I I
Steering gear & link-
age, axle & suspen-
sion partsIIIIMA-26
, PS-
13
Tire rotation NOTE (3)WT-6
Front drive shaft boots I I I IMA-27

MA-10
PERIODIC MAINTENANCE
Revision: June 20062007 Versa
(1) After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belt if found
damaged or if the auto belt tensioner reading reaches the maximum limit.
(2) Maintenance-free item.
(3) After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months.
(4) If valve noise increases, inspect valve clearance.
Maintenance items and intervals with “*” are recommended by NISSAN for reliable vehicle operation. The owner need not perform such
maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are
required.
CHASSIS AND BODY MAINTENANCE
Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. L = Lubricate.
(1) Using transmission fluid other than Genuine NISSAN CVT Fluid NS-2 will damage the CVT, which is not covered by the NIS-
SAN new vehicle limited warranty.
(2) Refer to “Tire rotation” under the “GENERAL MAINTENANCE” heading earlier in this section.Spark plugs (Iridium/plati-
num-tipped type)Replace every 105,000 miles (169,000 km)MA-18
Intake and exhaust valve
clearance)NOTE (4)EM-107, "Valve Clear-
ance"
MAINTENANCE OPERATIONMAINTENANCE INTERVAL
Reference
Section - Page
or - Content
Title Perform at number of miles,
kilometers or months,
whichever comes first.Miles x
1,000
(km x
1,000)
Months7.5
(12)
615
(24)
1222.5
(36)
1830
(48)
2437.5
(60)
3045
(72)
3652.5
(84)
4260
(96)
48
MAINTENANCE OPERATIONMAINTENANCE INTERVAL
Reference Sec-
tion - Page or -
Content Title Perform at number of miles, kilo-
meters or months, whichever
comes first.Miles x 1,000
(km x 1,000)
Months7.5
(12)
615
(24)
1222.5
(36)
1830
(48)
2437.5
(60)
3045
(72)
3652.5
(84)
4260
(96)
48
Brake lines & cables I I I IMA-24
Brake pads, rotors, drums & lin-
ings IIIIMA-25
Manual transaxle oil or automatic
transaxle fluidIIIIMA-22 or MA-22
CVT fluid NOTE (1) IIIIMA-20
Steering gear & linkage, axle &
suspension partsIIMA-26, PS-13
Tire rotation NOTE (2)MA-24
Front drive shaft boots I I I IMA-27
Exhaust system I IMA-20
In-cabin microfilter R R R RMA-20

MA-18
ENGINE MAINTENANCE
Revision: June 20062007 Versa
2. Apply new engine oil to the oil seal contact surface of new oil fil-
ter.
3. Screw oil filter manually until it touches the installation surface,
then tighten it by 2/3 turn. Or tighten to specification.
INSPECTION AFTER INSTALLATION
1. Check the engine oil level. Refer to LU-5, "ENGINE OIL LEVEL" .
2. Start engine, and make sure there is no leaks of engine oil.
3. Stop engine and wait for 10 minutes.
4. Check the engine oil level and adjust engine oil. Refer to LU-5, "
ENGINE OIL LEVEL" .
Changing Spark PlugsELS0020O
1. Remove intake manifold. Refer to EM-18, "INTAKE MANIFOLD" .
2. Remove ignition coil.
CAUTION:

Handle ignition coil carefully and avoid impacts.

Never disassemble.
3. Remove spark plug using suitable tool.
CAUTION:
Never drop or shock it.
INSPECTION AFTER REMOVAL
CAUTION:

Never drop or shock spark plug.
SM A01 0
Oil filter: : 17.7 N·m (1.8 kg-m, 13 ft-lb)
SM A22 9B
PBIC3871E
