Page 2385 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual TRANSAXLE ASSEMBLY MT-23 D E F G H I J K L MA B MT Revision: June 20062007 Versa DISASSEMBLY 1. Remove drain plug and gasket from clutch housing, and drain oil. 2. Remove filler plug and gasket from t

Page 2386 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual MT-24 TRANSAXLE ASSEMBLY Revision: June 20062007 Versa 9. Remove spring (1) of selector from return bushing (2). 10. Remove bearing preloading shim from mainshaft assembly. 11. Move 1st-2nd fork rod (

Page 2387 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual TRANSAXLE ASSEMBLY MT-25 D E F G H I J K L MA B MT Revision: June 20062007 Versa 17. Remove input shaft assembly (1), mainshaft assembly (2), and 1st-2nd fork rod (3) from clutch housing. 18. Remove f

Page 2388 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual MT-26 TRANSAXLE ASSEMBLY Revision: June 20062007 Versa 23. Remove retaining pin from control lever (1) using a suitable tool. 24. Remove control lever. 25. Remove shift finger (1) from transaxle case.

Page 2389 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual TRANSAXLE ASSEMBLY MT-27 D E F G H I J K L MA B MT Revision: June 20062007 Versa 29. Remove bushings (1) from transaxle case using a suitable tool. 30. Remove mainshaft rear bearing outer race and shi

Page 2390 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual MT-28 TRANSAXLE ASSEMBLY Revision: June 20062007 Versa 34. Remove busings (1) from clutch housing using a suitable tool. 35. Remove two way connector (1) from clutch housing. 36. Remove pinion gear (1

Page 2391 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual TRANSAXLE ASSEMBLY MT-29 D E F G H I J K L MA B MT Revision: June 20062007 Versa 2. Install two way connector (1) into clutch housing. 3. Install bushings (1) until they are flush with end face of clu

Page 2392 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual MT-30 TRANSAXLE ASSEMBLY Revision: June 20062007 Versa 7. Install shim and mainshaft rear bearing outer race into transaxle case using Tool (A). 8. Install bushings (1) into transaxle case using a sui
