Page 2489 of 2896
DUCTS AND GRILLES
MTC-77
C
D
E
F
G
H
I
K
L
MA
B
MTC
Revision: June 20062007 Versa
DEFROSTER NOZZLE AND SIDE DEFROSTER DUCTS (LH/RH)
Removal
1. Remove instrument upper finisher. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Remove screws and then remove side defroster duct (RH) and side defroster duct (LH).
3. Remove screws, and then remove defroster nozzle.
Installation
Installation is in the reverse order of removal.
SIDE VENTILATOR DUCTS
Removal
1. Remove instrument panel and pad. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Remove screws (A), and then remove side ventilator duct (left)
(1).
3. Remove screw (A) and clip (B), and then remove side ventilator
duct (right) (1).
1. Side defroster duct (RH) 2. Side defroster duct (LH) 3. Defroster nozzle
A. Side defroster duct screw B. Defroster nozzle screw
WJIA2199E
SJIA0661E
SJIA0662E
Page 2490 of 2896
MTC-78
DUCTS AND GRILLES
Revision: June 20062007 Versa
Installation
Installation is in the reverse order of removal.
CENTER VENTILATOR DUCTS
Removal
1. Remove instrument panel & pad. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Remove screws (A), and then remove center ventilator ducts
(1).
Installation
Installation is in the reverse order of removal.
SIDE FOOT DUCTS
NOTE:
The side foot ducts are part of the A/C unit assembly case.
Removal
1. Remove A/C unit assembly. Refer to MTC-64, "A/C UNIT ASSEMBLY" .
2. Remove screws (A), and then remove side foot duct (LH) (1).
3. Remove screws (A), and then remove side foot duct (RH) (1).
Installation
Installation is in the reverse order of removal.
FLOOR DUCTS
Removal
1. Remove front seats and center console assembly. Refer to SE-10, "FRONT SEAT" and IP-10, "INSTRU-
MENT PANEL ASSEMBLY" .
SJIA0663E
SJIA0664E
SJIA0665E
Page 2491 of 2896
DUCTS AND GRILLES
MTC-79
C
D
E
F
G
H
I
K
L
MA
B
MTC
Revision: June 20062007 Versa
2. Disengage claws (A), and then remove front floor duct (1).
3. Peel back floor trim to a point where floor duct is visible.
4. Remove clips (A), and then remove rear floor duct (left) (1) and
rear floor duct (right) (2).
Installation
Installation is in the reverse order of removal.
SJIA0667E
SJIA0668E
Page 2492 of 2896

MTC-80
REFRIGERANT LINES
Revision: June 20062007 Versa
REFRIGERANT LINESPFP:92600
HFC-134a (R-134a) Service ProcedureEJS0058D
SETTING OF SERVICE TOOLS AND EQUIPMENT
Discharging Refrigerant
WAR NIN G:
Avoid breathing A/C refrigerant and oil vapor or mist. Exposure may irritate eyes, nose and throat.
Remove HFC-134a (R-134a) refrigerant from the A/C system using certified service equipment meeting
requirements of SAE J2210 HFC-134a (R-134a) recycling equipment or SAE J2201 HFC-134a (R-134a)
recovery equipment. If an accidental system discharge occurs, ventilate the work area before resum-
ing service. Additional health and safety information may be obtained from the refrigerant and oil man-
ufacturers.
Evacuating System and Charging Refrigerant
1. Shut-off valve 2. A/C service valve 3. Recovery/recycling equipment
A. Preferred (best) method
WJIA2195E
1. Shut-off valve 2. A/C service valve 3. Recovery/recycling equipment
4. Refrigerant container (HFC-134a) 5. Weight scale (J-39650) 6. Evacuating vacuum pump (J-39699)
WJIA2196E
Page 2493 of 2896
REFRIGERANT LINES
MTC-81
C
D
E
F
G
H
I
K
L
MA
B
MTC
Revision: June 20062007 Versa
7. Manifold gauge set (J-39183) A. Preferred (best) method B. Alternative method
C. For charging
*1MTC-18, "
OIL RETURN OPERA-
TION"
*2MTC-92, "Checking for Refrigerant
Leaks"
*3MTC-94, "CHECKING PROCE-
DURE"
*4MTC-52, "PERFORMANCE TEST
DIAGNOSIS"
WJIA1923E
Page 2494 of 2896
MTC-82
REFRIGERANT LINES
Revision: June 20062007 Versa
ComponentsEJS0058E
Type 1 A/C System
WJIA2200E
1. Evaporator 2. Expansion valve 3. Low-pressure service valve
4. High-pressure service valve 5. Refrigerant pressure sensor 6. Shaft seal
7. Drain hose
Page 2495 of 2896
REFRIGERANT LINES
MTC-83
C
D
E
F
G
H
I
K
L
MA
B
MTC
Revision: June 20062007 Versa
Type 2 A/C System
WJIA2202E
1. Evaporator 2. Expansion valve 3. Low-pressure service valve
4. High-pressure service valve 5. Refrigerant pressure sensor 6. Shaft seal
7. Drain hose
Page 2496 of 2896
MTC-84
REFRIGERANT LINES
Revision: June 20062007 Versa
Idler Pulley - Without A/C
Refer to MTC-5, "Precautions for Refrigerant Connection" .
Removal and Installation of CompressorEJS0058F
REMOVAL
1. Use the recovery/recycling equipment to evacuate the refrigerant.
2. Remove the two engine undercovers, using power tools.
3. Remove low-pressure flexible hose nut (A) and high-pressure
flexible hose bolt (B) from compressor.
CAUTION:
Cap or wrap the joint of the pipe with suitable material such
as vinyl tape to avoid the entry of air.
NOTE:
Type 1 shown, type 2 is similar.
4. Remove A/C compressor belt. Refer to EM-13, "
DRIVE BELTS"
.
5. Disconnect compressor connector (C).
WJIA2204E
1. Idler pulley 2. Bracket 3. Shaft
SJIA0671E
