2006 NISSAN VERSA Workshop Service Repair Manual

tow brakes maintenance reset remote start air bleeding suspension

Page 1217 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual EC-48Revision: June 2006
ON BOARD DIAGNOSTIC (OBD) SYSTEM
2007 Versa
Therefore, when electrical controlled throttle and part of ECM related diagnoses are continuously detected as
NG for 5 trips, ECM w

EC-48Revision: June 2006
ON BOARD DIAGNOSTIC (OBD) SYSTEM
2007 Versa
Therefore, when electrical controlled throttle and part of ECM related diagnoses are continuously detected as
NG for 5 trips, ECM warns the driver that engine control system malfunctions and MIL circuit is open by means
of operating fail-safe function.
The fail-safe function also operates when above diagnoses except MIL circuit are detected, and demands the
driver to repair the malfunction.
Emission-related Diagnostic InformationUBS00QBH
EMISSION-RELATED DIAGNOSTIC INFORMATION ITEMS
×: Applicable —: Not applicable Engine operating condition in fail-safe mode Engine speed will not rise more than 2,500 rpm due to the fuel cut
Items
(CONSULT-II screen terms)DTC*
1
SRT codeTe s t v a l u e /
Test limit
(GST only)TripMIL light-
ing upReference
page CONSULT-II
GST*
2ECM*3
CAN COMM CIRCUIT U1000
1000*4——1 (CVT)
1 (A/T)
2 (M/T)× (CVT)
× (A/T)
— (M/T)EC-151
CAN COMM CIRCUIT U1001
1001*4——2—EC-151
CONTROL UNIT(CAN) U1010 1010 — —1 (CVT)
1 (A/T)
2 (M/T)× (CVT)
× (A/T)
— (M/T)EC-154
NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED.P0000 0000———
Flashing*5EC-62
INT/V TIM CONT-B1 P0011 0011 — — 2×EC-156
A/F SEN1 HTR (B1) P0031 0031 —×2×EC-161
A/F SEN1 HTR (B1) P0032 0032 —×2×EC-161
HO2S2 HTR (B1) P0037 0037 —×2×EC-166
HO2S2 HTR (B1) P0038 0038 —×2×EC-166
INT/V TIM V/CIR-B1 P0075 0075 — — 2×EC-173
MAF SEN/CIRCUIT P0101 0101 — — 2×EC-178
MAF SEN/CIRCUIT P0102 0102 — — 1×EC-187
MAF SEN/CIRCUIT P0103 0103 — — 1×EC-187
IAT SEN/CIRCUIT P0112 0112 — — 2×EC-195
IAT SEN/CIRCUIT P0113 0113 — — 2×EC-195
ECT SEN/CIRC P0117 0117 — — 1×EC-200
ECT SEN/CIRC P0118 0118 — — 1×EC-200
TP SEN 2/CIRC P0122 0122 — — 1×EC-206
TP SEN 2/CIRC P0123 0123 — — 1×EC-206
ECT SENSOR P0125 0125 — — 1×EC-212
IAT SENSOR P0127 0127 — — 2×EC-215
THERMSTAT FNCTN P0128 0128 — — 2×EC-218
A/F SENSOR1 (B1) P0130 0130 —×2×EC-220
A/F SENSOR1 (B1) P0131 0131 —×2×EC-227
A/F SENSOR1 (B1) P0132 0132 —×2×EC-233
A/F SENSOR1 (B1) P0133 0133××2×EC-239
HO2S2 (B1) P0137 0137××2×EC-248
HO2S2 (B1) P0138 0138××2×EC-257
HO2S2 (B1) P0139 0139××2×EC-267
FUEL SYS-LEAN-B1 P0171 0171 — — 2×EC-276
FUEL SYS-RICH-B1 P0172 0172 — — 2×EC-284

Page 1218 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual ON BOARD DIAGNOSTIC (OBD) SYSTEM
EC-49
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: June 20062007 VersaFTT SENSOR P0181 0181 — — 2×EC-291
FTT SEN/CIRCUIT P0182 0182 — — 2×EC-297
FTT SEN/CIRCUIT P0183

ON BOARD DIAGNOSTIC (OBD) SYSTEM
EC-49
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: June 20062007 VersaFTT SENSOR P0181 0181 — — 2×EC-291
FTT SEN/CIRCUIT P0182 0182 — — 2×EC-297
FTT SEN/CIRCUIT P0183 0183 — — 2×EC-297
TP SEN 1/CIRC P0222 0222 — — 1×EC-302
TP SEN 1/CIRC P0223 0223 — — 1×EC-302
MULTI CYL MISFIRE P0300 0300 — — 2×EC-308
CYL 1 MISFIRE P0301 0301 — — 2×EC-308
CYL 2 MISFIRE P0302 0302 — — 2×EC-308
CYL 3 MISFIRE P0303 0303 — — 2×EC-308
CYL 4 MISFIRE P0304 0304 — — 2×EC-308
KNOCK SEN/CIRC-B1 P0327 0327 — — 2 —EC-315
KNOCK SEN/CIRC-B1 P0328 0328 — — 2 —EC-315
CKP SEN/CIRCUIT P0335 0335 — — 2×EC-319
CMP SEN/CIRC-B1 P0340 0340 — — 2×EC-327
TW CATALYST SYS-B1 P0420 0420× ×2×EC-334
EVAP PURG FLOW/MON P0441 0441××2×EC-340
EVAP SMALL LEAK P0442 0442××2×EC-346
PURG VOLUME CONT/V P0443 0443 — — 2×EC-354
PURG VOLUME CONT/V P0444 0444 — — 2×EC-362
PURG VOLUME CONT/V P0445 0445 — — 2×EC-362
VENT CONTROL VALVE P0447 0447 — — 2×EC-369
VENT CONTROL VALVE P0448 0448 — — 2×EC-376
EVAP SYS PRES SEN P0451 0451 — — 2×EC-382
EVAP SYS PRES SEN P0452 0452 — — 2×EC-385
EVAP SYS PRES SEN P0453 0453 — — 2×EC-391
EVAP GROSS LEAK P0455 0455 — — 2×EC-398
EVAP VERY SML LEAK P0456 0456
×*6×2×EC-406
FUEL LEV SEN SLOSH P0460 0460 — — 2×EC-415
FUEL LEVEL SENSOR P0461 0461 — — 2×EC-417
FUEL LEVL SEN/CIRC P0462 0462 — — 2×EC-419
FUEL LEVL SEN/CIRC P0463 0463 — — 2×EC-419
VEH SPEED SEN/CIRC*7P0500 0500 — — 2×EC-421
ISC SYSTEM P0506 0506 — — 2×EC-423
ISC SYSTEM P0507 0507 — — 2×EC-425
ECM P0605 0605 — — 1 or 2 — or ×EC-427
SENSOR POWER/CIRC P0643 0643 — — 1×EC-430
PNP SW/CIRC P0705 0705 — — 2×AT - 9 7 (A/T),
CVT-78
(CVT)
ATF TEMP SEN/CIRC P0710 0710 — — 2×AT- 1 0 2
(A/T),
CVT-85
(CVT)
INPUT SPD SEN/CIRC P0715 0715 — — 2×CVT-90
VEH SPD SEN/CIR AT*7P0720 0720 — — 2×AT- 1 0 7 (A/T),
CVT-95
(CVT) Items
(CONSULT-II screen terms)DTC*
1
SRT codeTe s t v a l u e /
Te s t l i m i t
(GST only)TripMIL light-
ing upReference
page CONSULT-II
GST*
2ECM*3

Page 1219 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual EC-50Revision: June 2006
ON BOARD DIAGNOSTIC (OBD) SYSTEM
2007 Versa
ENGINE SPEED SIG P0725 0725 — — 2×AT- 11 3
A/T 1ST GR FNCTN P0731 0731 — — 2×AT- 11 7
A/T 2ND GR FNCTN P0732 0732 — �

EC-50Revision: June 2006
ON BOARD DIAGNOSTIC (OBD) SYSTEM
2007 Versa
ENGINE SPEED SIG P0725 0725 — — 2×AT- 11 3
A/T 1ST GR FNCTN P0731 0731 — — 2×AT- 11 7
A/T 2ND GR FNCTN P0732 0732 — — 2×AT- 1 2 1
A/T 3RD GR FNCTN P0733 0733 — — 2×AT- 1 2 4
A/T 4TH GR FNCTN P0734 0734 — — 2×AT- 1 2 8
TCC SOLENOID/CIRC P0740 0740 — — 2×AT- 1 3 4
A/T TCC S/V FNCTN P0744 0744 — — 2×AT- 1 3 9
(A/T),
CVT-110

(CVT)
L/PRESS SOL/CIRC P0745 0745 — — 2×AT- 1 4 5
PRS CNT SOL/A FCTN P0746 0746 — — 1×CVT-118
SFT SOL A/CIRC P0750 0750 — — 1×AT- 1 5 1
SFT SOL B/CIRC P0755 0755 — — 1×AT- 1 5 6
PRS CNT SOL/B FCTN P0776 0776 — — 2×CVT-121
PRS CNT SOL/B CIRC P0778 0778 — — 2×CVT-124
TR PRS SENS/A CIRC P0840 0840 — — 2×CVT-129
TR PRS SENS/B CIRC P0845 0845 — — 2×CVT-137
P-N POS SW/CIRCUIT P0850 0850 — — 2×EC-436
C L O S E D L O O P - B 1 P 11 4 8 11 4 8 — — 1×EC-442
ENG OVER TEMP P1217 1217 — — 1×EC-443
CTP LEARNING P1225 1225 — — 2 —EC-460
CTP LEARNING P1226 1226 — — 2 —EC-462
COLD START CONTROL P1421 1421 — — 2×EC-464
ASCD SW P1564 1564 — — 1 —EC-466
ASCD BRAKE SW P1572 1572 — — 1 —EC-473
ASCD VHL SPD SEN P1574 1574 — — 1 —EC-483
NATS MALFUNCTIONP1610 -
P16151610 - 1615 — — 2 —BL-212
TP SEN/CIRC A/T P1705 1705 — — 1×CVT-150
IN PULY SPEED P1715 1715 — — 2 —EC-485 (A/T),
EC-486
(CVT)
LU-SLCT SOL/CIRC P1740 1740 — — 2×CVT-158
O/R CLTCH SOL/CIRC P1760 1760 — — 2×AT- 1 6 1
STEP MOTR CIRC P1777 1777 — — 1×CVT-164
STEP MOTR FNC P1778 1778 — — 2×CVT-168
BRAKE SW/CIRCUIT P1805 1805 — — 2 —EC-488
ETC MOT PWR P2100 2100 — — 1×EC-493
ETC FUNCTION/CIRC P2101 2101 — — 1×EC-499
ETC MOT PWR P2103 2103 — — 1×EC-493
ETC MOT P2118 2118 — — 1×EC-506
ETC ACTR P2119 2119 — — 1×EC-511
APP SEN 1/CIRC P2122 2122 — — 1×EC-513
APP SEN 1/CIRC P2123 2123 — — 1×EC-513
APP SEN 2/CIRC P2127 2127 — — 1×EC-519
Items
(CONSULT-II screen terms)DTC*
1
SRT codeTe s t v a l u e /
Test limit
(GST only)TripMIL light-
ing upReference
page CONSULT-II
GST*
2ECM*3

Page 1220 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual ON BOARD DIAGNOSTIC (OBD) SYSTEM
EC-51
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: June 20062007 Versa
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescribed by SAE J2012.
*3: In Diagnostic

ON BOARD DIAGNOSTIC (OBD) SYSTEM
EC-51
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: June 20062007 Versa
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescribed by SAE J2012.
*3: In Diagnostic Test Mode II (Self-diagnostic results), this number is controlled by NISSAN.
*4: The troubleshooting for this DTC needs CONSULT-II.
*5: When the ECM in the mode of displaying SRT status, MIL may flash. For the details, refer to EC-56, "
How to Display SRT Status" .
*6: SRT code will not be set if the self-diagnostic result is NG.
*7: When the fail-safe operations for both self-diagnoses occur, the MIL illuminates.
DTC AND 1ST TRIP DTC
The 1st trip DTC (whose number is the same as the DTC number) is displayed for the latest self-diagnostic
result obtained. If the ECM memory was cleared previously, and the 1st trip DTC did not reoccur, the 1st trip
DTC will not be displayed.
If a malfunction is detected during the 1st trip, the 1st trip DTC is stored in the ECM memory. The MIL will not
light up (two trip detection logic). If the same malfunction is not detected in the 2nd trip (meeting the required
driving pattern), the 1st trip DTC is cleared from the ECM memory. If the same malfunction is detected in the
2nd trip, both the 1st trip DTC and DTC are stored in the ECM memory and the MIL lights up. In other words,
the DTC is stored in the ECM memory and the MIL lights up when the same malfunction occurs in two consec-
utive trips. If a 1st trip DTC is stored and a non-diagnostic operation is performed between the 1st and 2nd
trips, only the 1st trip DTC will continue to be stored. For malfunctions that blink or light up the MIL during the
1st trip, the DTC and 1st trip DTC are stored in the ECM memory.
Procedures for clearing the DTC and the 1st trip DTC from the ECM memory are described in EC-60, "
HOW
TO ERASE EMISSION-RELATED DIAGNOSTIC INFORMATION" .
For malfunctions in which 1st trip DTCs are displayed, refer to EC-48, "
EMISSION-RELATED DIAGNOSTIC
INFORMATION ITEMS" . These items are required by legal regulations to continuously monitor the system/
component. In addition, the items monitored non-continuously are also displayed on CONSULT-II.
1st trip DTC is specified in Service $07 of SAE J1979. 1st trip DTC detection occurs without lighting up the MIL
and therefore does not warn the driver of a malfunction. However, 1st trip DTC detection will not prevent the
vehicle from being tested, for example during Inspection/Maintenance (I/M) tests.
When a 1st trip DTC is detected, check, print out or write down and erase (1st trip) DTC and Freeze Frame
data as specified in Work Flow procedure Step 2, refer to EC-84, "
WORK FLOW" . Then perform DTC Confir-
mation Procedure or Overall Function Check to try to duplicate the malfunction. If the malfunction is dupli-
cated, the item requires repair.
How to Read DTC and 1st Trip DTC
DTC and 1st trip DTC can be read by the following methods.
WITH CONSULT-II
WITH GST
CONSULT-II or GST (Generic Scan Tool) Examples: P0340, P0850, P1148, etc.
These DTCs are prescribed by SAE J2012.
(CONSULT-II also displays the malfunctioning component or system.)
NO TOOLS
The number of blinks of the MIL in the Diagnostic Test Mode II (Self-Diagnostic Results) indicates the DTC.
Example: 0340, 0850, 1148, etc.
These DTCs are controlled by NISSAN.
1st trip DTC No. is the same as DTC No.
Output of a DTC indicates a malfunction. However, GST or the Diagnostic Test Mode II do not indi-
cate whether the malfunction is still occurring or has occurred in the past and has returned to nor-
mal. CONSULT-II can identify malfunction status as shown below. Therefore, using CONSULT-II (if
available) is recommended.
APP SEN 2/CIRC P2128 2128 — — 1×EC-519
TP SENSOR P2135 2135 — — 1×EC-526
APP SENSOR P2138 2138 — — 1×EC-532
A/F SENSOR1 (B1) P2A00 2A00 —×2×EC-540
Items
(CONSULT-II screen terms)DTC*
1
SRT codeTe s t v a l u e /
Te s t l i m i t
(GST only)TripMIL light-
ing upReference
page CONSULT-II
GST*
2ECM*3

Page 1221 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual EC-52Revision: June 2006
ON BOARD DIAGNOSTIC (OBD) SYSTEM
2007 Versa
A sample of CONSULT-II display for DTC and 1st trip DTC is shown below. DTC or 1st trip DTC of a malfunc-
tion is displayed in SELF

EC-52Revision: June 2006
ON BOARD DIAGNOSTIC (OBD) SYSTEM
2007 Versa
A sample of CONSULT-II display for DTC and 1st trip DTC is shown below. DTC or 1st trip DTC of a malfunc-
tion is displayed in SELF-DIAGNOSTIC RESULTS mode of CONSULT-II. Time data indicates how many times
the vehicle was driven after the last detection of a DTC.
If the DTC is being detected currently, the time data will be [0].
If a 1st trip DTC is stored in the ECM, the time data will be [1t].
FREEZE FRAME DATA AND 1ST TRIP FREEZE FRAME DATA
The ECM records the driving conditions such as fuel system status, calculated load value, engine coolant tem-
perature, short term fuel trim, long term fuel trim, engine speed, vehicle speed, absolute throttle position, base
fuel schedule and intake air temperature at the moment a malfunction is detected.
Data which are stored in the ECM memory, along with the 1st trip DTC, are called 1st trip freeze frame data.
The data, stored together with the DTC data, are called freeze frame data and displayed on CONSULT-II or
GST. The 1st trip freeze frame data can only be displayed on the CONSULT-II screen, not on the GST. For
details, see EC-116, "
Freeze Frame Data and 1st Trip Freeze Frame Data" .
Only one set of freeze frame data (either 1st trip freeze frame data or freeze frame data) can be stored in the
ECM. 1st trip freeze frame data is stored in the ECM memory along with the 1st trip DTC. There is no priority
for 1st trip freeze frame data and it is updated each time a different 1st trip DTC is detected. However, once
freeze frame data (2nd trip detection/MIL on) is stored in the ECM memory, 1st trip freeze frame data is no
longer stored. Remember, only one set of freeze frame data can be stored in the ECM. The ECM has the fol-
lowing priorities to update the data.
For example, the EGR malfunction (Priority: 2) was detected and the freeze frame data was stored in the 2nd
trip. After that when the misfire (Priority: 1) is detected in another trip, the freeze frame data will be updated
from the EGR malfunction to the misfire. The 1st trip freeze frame data is updated each time a different mal-
function is detected. There is no priority for 1st trip freeze frame data. However, once freeze frame data is
stored in the ECM memory, 1st trip freeze data is no longer stored (because only one freeze frame data or 1st
trip freeze frame data can be stored in the ECM). If freeze frame data is stored in the ECM memory and freeze
frame data with the same priority occurs later, the first (original) freeze frame data remains unchanged in the
ECM memory.
Both 1st trip freeze frame data and freeze frame data (along with the DTCs) are cleared when the ECM mem-
ory is erased. Procedures for clearing the ECM memory are described in EC-48, "
EMISSION-RELATED
DIAGNOSTIC INFORMATION ITEMS" .
SYSTEM READINESS TEST (SRT) CODE
System Readiness Test (SRT) code is specified in Service $01 of SAE J1979.
As part of an enhanced emissions test for Inspection & Maintenance (I/M), certain states require the status of
SRT be used to indicate whether the ECM has completed self-diagnosis of major emission systems and com-
ponents. Completion must be verified in order for the emissions inspection to proceed.
If a vehicle is rejected for a State emissions inspection due to one or more SRT items indicating “INCMP”, use
the information in this Service Manual to set the SRT to “CMPLT”.
In most cases the ECM will automatically complete its self-diagnosis cycle during normal usage, and the SRT
status will indicate “CMPLT” for each application system. Once set as “CMPLT”, the SRT status remains
“CMPLT” until the self-diagnosis memory is erased.
PBIB09 11 E
Priority Items
1Freeze frame data Misfire — DTC: P0300 - P0304
Fuel Injection System Function — DTC: P0171, P0172
2 Except the above items (Includes A/T or CVT related items)
3 1st trip freeze frame data

Page 1222 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual ON BOARD DIAGNOSTIC (OBD) SYSTEM
EC-53
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: June 20062007 Versa
Occasionally, certain portions of the self-diagnostic test may not be completed as a result of the custom

ON BOARD DIAGNOSTIC (OBD) SYSTEM
EC-53
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: June 20062007 Versa
Occasionally, certain portions of the self-diagnostic test may not be completed as a result of the customer's
normal driving pattern; the SRT will indicate “INCMP” for these items.
NOTE:
The SRT will also indicate “INCMP” if the self-diagnosis memory is erased for any reason or if the ECM mem-
ory power supply is interrupted for several hours.
If, during the state emissions inspection, the SRT indicates “CMPLT” for all test items, the inspector will con-
tinue with the emissions test. However, if the SRT indicates “INCMP” for one or more of the SRT items the
vehicle is returned to the customer untested.
NOTE:
If MIL is ON during the state emissions inspection, the vehicle is also returned to the customer untested even
though the SRT indicates “CMPLT” for all test items. Therefore, it is important to check SRT (“CMPLT”) and
DTC (No DTCs) before the inspection.
SRT Item
The table below shows required self-diagnostic items to set the SRT to “CMPLT”.
*: If completion of several SRTs is required, perform driving patterns (DTC confirmation procedure), one by one based on the priority for
models with CONSULT-II.
SRT Set Timing
SRT is set as “CMPLT” after self-diagnosis has been performed one or more times. Completion of SRT is
done regardless of whether the result is OK or NG. The set timing is different between OK and NG results and
is shown in the table below.
SRT item
(CONSULT-II indication)Perfor-
mance
Priority*Required self-diagnostic items to set the SRT to “CMPLT”Corresponding DTC
No.
CATALYST 2 Three way catalyst function P0420
EVAP SYSTEM 2 EVAP control system purge flow monitoring P0441
1 EVAP control system P0442
2 EVAP control system P0456
HO2S 2 Air fuel ratio (A/F) sensor 1 P0133
Heated oxygen sensor 2 P0137
Heated oxygen sensor 2 P0138
Heated oxygen sensor 2 P0139
Self-diagnosis resultExample
DiagnosisIgnition cycle
← ON → OFF ← ON → OFF ← ON → OFF ← ON →
All OK Case 1 P0400 OK (1) — (1) OK (2) — (2)
P0402 OK (1) — (1) — (1) OK (2)
P1402 OK (1) OK (2) — (2) — (2)
SRT of EGR “CMPLT” “CMPLT” “CMPLT” “CMPLT”
Case 2 P0400 OK (1) — (1) — (1) — (1)
P0402 — (0) — (0) OK (1) — (1)
P1402 OK (1) OK (2) — (2) — (2)
SRT of EGR “INCMP” “INCMP” “CMPLT” “CMPLT”
NG exists Case 3 P0400 OK OK — —
P0402 — — — —
P1402 NG — NGNG
(Consecutive
NG)
(1st trip)
DTC1st trip DTC — 1st trip DTCDTC
(= MIL “ON”)
SRT of EGR “INCMP” “INCMP” “INCMP” “CMPLT”

Page 1223 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual EC-54Revision: June 2006
ON BOARD DIAGNOSTIC (OBD) SYSTEM
2007 Versa
OK: Self-diagnosis is carried out and the result is OK.
NG: Self-diagnosis is carried out and the result is NG.
—: Self-diagnosis

Page 1224 of 2896

NISSAN VERSA 2006 Workshop Service Repair Manual ON BOARD DIAGNOSTIC (OBD) SYSTEM
EC-55
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: June 20062007 Versa
SRT Service Procedure
If a vehicle has failed the state emissions inspection due to one or more SRT items

Load next 8 pages

Page: < prev 1-10 ... 1185-1192 1193-1200 1201-1208 1209-1216 1217-1224 1225-1232 1233-1240 1241-1248 1249-1256 ... 2896 next >

wiper blades oil pressure wiring diagram coolant reservoir headlamp ignition
