Page 977 of 2896
CVT-80
DTC P0705 PARK/NEUTRAL POSITION SWITCH
Revision: June 20062007 Versa
Wiring Diagram — CVT — PNP/SWUCS005Z8
BCWA0670E
Page 978 of 2896
DTC P0705 PARK/NEUTRAL POSITION SWITCH
CVT-81
D
E
F
G
H
I
J
K
L
MA
B
CVT
Revision: June 20062007 Versa
TCM terminal data are reference values, measured between each terminal and ground.
Terminal Wire color Item Condition Data (Approx.)
27 GR PNP switch 1Selector lever in “R”, “N” and “D” positions. 0 V
Selector lever in “P” and “L” positions. Battery voltage
32 YPNP switch 3
(monitor)Selector lever in “D” and “L” positions. 0 V
Selector lever in “P”, “R” and “N” positions.8.0 V - Battery volt-
age
34 SB PNP switch 2Selector lever in “N”, “D” and “L” positions. 0 V
Selector lever in “P” and “R” positions.10.0 V - Battery
voltage
35 W PNP switch 3Selector lever in “D” and “L” positions. 0 V
Selector lever in “P”, “R” and “N” positions.8.0 V - Battery volt-
age
36 W PNP switch 4Selector lever in “R” and “D” positions. 0 V
Selector lever in “P”, “N” and “L” positions.10.0 V - Battery
voltage
Page 979 of 2896

CVT-82
DTC P0705 PARK/NEUTRAL POSITION SWITCH
Revision: June 20062007 Versa
Diagnostic ProcedureUCS005Z9
1. CHECK PNP SW SIGNALS
With CONSULT-II
1. Turn ignition switch ON. (Do not start engine.)
2. Select “ECU INPUT SIGNALS” in “DATA MONITOR” mode for
“TRANSMISSION” with CONSULT-II.
3. Change selector lever to “P”, “R”, “N”, “D” and “L” positions to
check the value of “INH SW1” “INH SW2” “INH SW3” “INH SW4”
and “INH SW3M”.
Without CONSULT-II
1. Turn ignition switch ON. (Do not start engine.)
2. Change selector lever to “P“, “R”, “N”, “D” and “L” positions to
check voltage between the TCM connector terminals and
ground.
OK or NG
OK >> GO TO 5.
NG >> GO TO 2.
Shift
posi-
tion “INH SW1” “INH SW2” “INH SW3” “INH SW4” “INH SW3M”
P OFF OFF OFF OFF OFF
R ON OFF OFF ON OFF
N ON ON OFF OFF OFF
DONONONON ON
L OFF ON ON OFF ON
SCIA2276E
Shift
positionConnector E32
Te r m i n a l
27 - Ground 34 - Ground 35 - Ground 36 - Ground32 -
Ground
PBattery volt-
age10.0 V - Bat-
tery voltage8.0 V - Bat-
tery voltage10.0 V - Bat-
tery voltage8.0 V -
Battery
voltage
R0 V10.0 V - Bat-
tery voltage8.0 V - Bat-
tery voltage0 V8.0 V -
Battery
voltage
N0 V 0 V8.0 V - Bat-
tery voltage10.0 V - Bat-
tery voltage8.0 V -
Battery
voltage
D0 V0 V0 V0 V0 V
LBattery volt-
age0 V 0 V10.0 V - Bat-
tery voltage0 V
SCIA2024E
Page 980 of 2896

DTC P0705 PARK/NEUTRAL POSITION SWITCH
CVT-83
D
E
F
G
H
I
J
K
L
MA
B
CVT
Revision: June 20062007 Versa
2. CHECK PNP SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect TCM connector.
3. Check continuity between TCM connector terminals and ground.
4. If OK, check harness for short-circuit to ground or power supply.
OK or NG
OK >> GO TO 5.
NG >> GO TO 3.
3. CHECK HARNESS BETWEEN TCM AND PNP SWITCH
1. Turn ignition switch OFF.
2. Disconnect TCM connector and CVT unit harness connector.
3. Check continuity between TCM connector terminals and CVT
unit harness connector terminals.
4. If OK, check harness for short to ground and short to power.
5. Reinstall any part removed.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace damaged parts.
Connector Terminal Condition Continuity
E3227 - groundSelect lever in “P” and “L” positions No
Select lever in other positions Yes
34 - groundSelect lever in “P” and “R” positions No
Select lever in other positions Yes
35 - groundSelect lever in “P”, “R” and “N” posi-
tionsNo
Select lever in other positions Yes
36 - groundSelect lever in “P”,“N” and “L” posi-
tionsNo
Select lever in other positions Yes
32 - groundSelect lever in “P”, “R” and “N” posi-
tionsNo
Select lever in other positions Yes
SCIA5258E
Item Connector Terminal Continuity
TCM E32 27
Ye s
CVT unit harness connector F46 4
TCM E32 34
Ye s
CVT unit harness connector F46 5
TCM E32 35
Ye s
CVT unit harness connector F46 14
TCM E32 32
Ye s
CVT unit harness connector F46 18
TCM E32 36
Ye s
CVT unit harness connector F46 15
SCIA3182E
Page 981 of 2896

CVT-84
DTC P0705 PARK/NEUTRAL POSITION SWITCH
Revision: June 20062007 Versa
4. DETECT MALFUNCTIONING ITEM
Check PNP switch. Refer to CVT-84, "
Component Inspection" .
OK or NG
OK >> GO TO 5.
NG >> Repair or replace damaged parts.
5. CHECK DTC
Perform CVT-78, "
DTC Confirmation Procedure" .
OK or NG
OK >>INSPECTION END
NG >> GO TO 6.
6. CHECK TCM
1. Check TCM input/output signals. Refer to CVT-54, "
TCM Input/Output Signal Reference Values" .
2. If NG, re-check TCM pin terminals for damage or loose connection with harness connector.
OK or NG
OK >>INSPECTION END
NG >> 1. Repair or replace damaged parts.
2. Replace the transaxle assembly. Refer to CVT-207, "
Removal and Installation" .
Component InspectionUCS005ZA
PNP SWITCH
1. Change selector lever to various positions to check the continu-
ity between terminals on the PNP switch and ground.
2. If NG, check continuity with control cable disconnected. (Refer to step 1 above.)
3. If OK, with the control cable disconnected, adjust the control cable. Refer to CVT-195, "
Adjustment of CVT
Position" .
4. If NG, even when the control cable is disconnected, replace the transaxle assembly. Refer to CVT-207,
"Removal and Installation" .
PNP SW Shift position Connector Terminal Continuity
SW 1“R”, “N”, “D”
F464 - Ground Ye s
other positions No
SW 2“N”, “D”, “L”
5 - Ground Ye s
other positions No
SW 3“D”, “L”
14 - Ground Ye s
other positions No
SW 4“R”, “D”
15 - Ground Ye s
other positions No
SW 3 Moni-
tor“D”, “L”
18 - Ground Ye s
other positions No
SCIA4678E
Page 982 of 2896

DTC P0710 CVT FLUID TEMPERATURE SENSOR CIRCUIT
CVT-85
D
E
F
G
H
I
J
K
L
MA
B
CVT
Revision: June 20062007 Versa
DTC P0710 CVT FLUID TEMPERATURE SENSOR CIRCUITPFP:31020
DescriptionUCS005ZB
The CVT fluid temperature sensor is included in the control valve assembly.
The CVT fluid temperature sensor detects the CVT fluid temperature and sends a signal to the TCM.
CONSULT-II Reference ValueUCS005ZC
Remarks: Specification data are reference values.
On Board Diagnosis LogicUCS005ZD
This is an OBD-II self-diagnostic item.
Diagnostic trouble code “P0710 ATF TEMP SEN/CIRC” with CONSULT-II is detected when TCM receives
an excessively low or high voltage from the sensor.
Possible CauseUCS005ZE
Harness or connectors
(Sensor circuit is open or shorted.)
CVT fluid temperature sensor
DTC Confirmation ProcedureUCS005ZF
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously performed, always turn ignition switch OFF and
wait at least 10 seconds before performing the next test.
After the repair, touch “ERASE” on “SELF-DIAG RESULTS” and then perform the following procedure to con-
firm the malfunction is eliminated.
WITH CONSULT-II
1. Turn ignition switch ON. (Do not start engine.)
2. Select “DATA MONITOR” mode for “TRANSMISSION” with
CONSULT-II.
3. Start engine and maintain the following conditions for at least 10
minutes (Total).
VEHICLE SPEED: 10 km/h (6 MPH) or more
ENG SPEED: 450 rpm more than
ACC PEDAL OPEN: More than 1.0/8
RANGE: “D” position
4. If DTC is detected, go to CVT-87, "
Diagnostic Procedure" .
WITH GST
Follow the procedure “WITH CONSULT-II”.
Item name Condition Display value (Approx.)
AT F T E M P S E N When CVT fluid temperature is 20°C (68°F). 2.0 V
When CVT fluid temperature is 80°C (176°F). 1.0 V
BCIA0031E
Page 983 of 2896
CVT-86
DTC P0710 CVT FLUID TEMPERATURE SENSOR CIRCUIT
Revision: June 20062007 Versa
Wiring Diagram — CVT — FTSUCS005ZG
BCWA0671E
Page 984 of 2896

DTC P0710 CVT FLUID TEMPERATURE SENSOR CIRCUIT
CVT-87
D
E
F
G
H
I
J
K
L
MA
B
CVT
Revision: June 20062007 Versa
TCM terminal data are reference values, measured between each terminal and ground.
Diagnostic ProcedureUCS005ZH
1. CHECK CVT FLUID TEMPERATURE SENSOR SIGNAL
With CONSULT-II
1. Start engine.
2. Select “ECU INPUT SIGNALS” in “DATA MONITOR” mode for
“TRANSMISSION” with CONSULT-II.
3. Read out the value of “ATF TEMP SEN”.
Without CONSULT-II
1. Start engine.
2. Check voltage between TCM connector terminals.
3. Turn ignition switch OFF.
4. Disconnect TCM connector.
5. Check if there is continuity between connector terminal and
ground.
OK or NG
OK >> GO TO 5.
NG >> GO TO 2.
2. CHECK CVT FLUID TEMPERATURE SENSOR CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect the TCM connector.
3. Check resistance between TCM connector terminals.
OK or NG
OK >> GO TO 5.
NG >> GO TO 3.
Terminal Wire color Item Condition Data (Approx.)
42 LG Sensor ground Always 0 V
47 GCVT fluid tempera-
ture sensorWhen CVT fluid temperature is 20°C (68°F). 2.0 V
When CVT fluid temperature is 80°C (176°F). 1.0 V
Item name ConditionDisplay value
(Approx.)
AT F T E M P S E NWhen CVT fluid temperature is 20°C
(68°F).2.0 V
When CVT fluid temperature is 80°C
(176°F).1.0 V
SCIA2277E
Name Connector TerminalTemperature
°C (°F)Voltage
(Approx.)
CVT fluid tem-
perature sen-
sorE32 47 - 4220 (68) 2.0 V
80 (176) 1.0 V
SCIA2027E
Name Connector TerminalTemperature
°C (°F)Resistance
(Approx.)
CVT fluid tem-
perature sensorE32 47 - 4220 (68) 6.5 kΩ
80 (176) 0.9 kΩ
SCIA2510E
