2006 NISSAN VERSA turn signal bulb

LT-1
LIGHTING SYSTEM
K ELECTRICAL
CONTENTS
C
D
E
F
G
H
I
J
L
M
SECTION LT
A
B
LT
Revision: June 20062007 Versa PRECAUTIONS .......................................................... 4
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 4
HEADLAMP (FOR USA) ............................................ 5
Component Parts and Harness Connector Location ..... 5
System Description .................................................. 5
OUTLINE ............................................................... 5
HEADLAMP OPERATION .................................... 6
COMBINATION SWITCH READING FUNCTION ..... 6
EXTERIOR LAMP BATTERY SAVER CONTROL ..... 6
CAN COMMUNICATION SYSTEM DESCRIP-
TION ......................................................................... 6
Schematic ................................................................ 7
Wiring Diagram ........................................................ 8
Terminals and Reference Values for BCM ............. 12
Terminals and Reference Values for IPDM E/R ..... 12
How to Perform Trouble Diagnoses ....................... 12
Preliminary Check .................................................. 12
CHECK POWER SUPPLY AND GROUND CIR-
CUIT FOR BCM .................................................. 12
CHECK POWER SUPPLY AND GROUND CIR-
CUIT FOR IPDM E/R .......................................... 12
CONSULT-II Function (BCM) ................................. 12
CONSULT-II START PROCEDURE .................... 12
WORK SUPPORT ............................................... 12
DATA MONITOR ................................................. 12
ACTIVE TEST ..................................................... 13
SELF-DIAGNOSTIC RESULTS .......................... 13
CONSULT-II Function (IPDM E/R) ......................... 13
CONSULT-II START PROCEDURE .................... 13
DATA MONITOR ................................................. 14
ACTIVE TEST ..................................................... 14
Headlamp High Beam Does Not Illuminate (Both
Sides) ..................................................................... 14
Headlamp High Beam Does Not Illuminate (One
Side) ....................................................................... 17
High Beam Indicator Lamp Does Not Illuminate .... 18
Headlamp Low Beam Does Not Illuminate (Both
Sides) ..................................................................... 18Headlamp Low Beam Does Not Illuminate (One
Side) ....................................................................... 21
Headlamps Do Not Turn OFF ................................. 22
Aiming Adjustment .................................................. 23
PREPARATION BEFORE ADJUSTING .............. 23
LOW BEAM AND HIGH BEAM ........................... 23
ADJUSTMENT USING AN ADJUSTMENT
SCREEN (LIGHT/DARK BORDERLINE) ............ 24
Bulb Replacement .................................................. 25
HEADLAMP (HIGH/LOW) ................................... 25
PARKING (CLEARANCE) LAMP ........................ 25
FRONT TURN SIGNAL LAMP ............................ 25
Removal and Installation ........................................ 25
REMOVAL ........................................................... 25
INSTALLATION ................................................... 25
Disassembly and Assembly .................................... 26
DISASSEMBLY ................................................... 26
ASSEMBLY ......................................................... 26
HEADLAMP (FOR CANADA) - DAYTIME LIGHT
SYSTEM - .................................................................. 27
Component Parts and Harness Connector Location ... 27
System Description ................................................. 27
OUTLINE ............................................................. 27
HEADLAMP OPERATION ................................... 28
COMBINATION SWITCH READING FUNCTION ... 29
EXTERIOR LAMP BATTERY SAVER CONTROL ... 29
CAN Communication System Description .............. 29
Schematic ............................................................... 30
Wiring Diagram — DTRL — ................................... 31
Terminals and Reference Values for BCM .............. 35
Terminals and Reference Values for IPDM E/R ...... 35
How to Perform Trouble Diagnoses ....................... 35
Preliminary Check .................................................. 35
CHECK BCM CONFIGURATION ........................ 35
CHECK POWER SUPPLY AND GROUND CIR-
CUIT FOR BCM .................................................. 35
CHECK POWER SUPPLY AND GROUND CIR-
CUIT FOR IPDM E/R .......................................... 35
CONSULT-II Function (BCM) ................................. 35
CONSULT-II Function (IPDM E/R) ......................... 35

LT-2Revision: June 20062007 Versa Daytime Light Control Does Not Operate Properly
(High Beam Headlamps Operate Properly) ............ 35
Aiming Adjustment .................................................. 37
PREPARATION BEFORE ADJUSTING .............. 37
LOW BEAM AND HIGH BEAM ........................... 37
ADJUSTMENT USING AN ADJUSTMENT
SCREEN (LIGHT/DARK BORDERLINE) ............ 38
Bulb Replacement .................................................. 39
HEADLAMP (HIGH/LOW) ................................... 39
PARKING (CLEARANCE) LAMP ......................... 39
FRONT TURN SIGNAL LAMP ............................ 39
Removal and Installation ........................................ 39
REMOVAL ........................................................... 39
INSTALLATION .................................................... 39
Disassembly and Assembly .................................... 40
DISASSEMBLY ................................................... 40
ASSEMBLY ......................................................... 40
FRONT FOG LAMP .................................................. 41
Component Parts and Harness Connector Location ... 41
System Description ................................................. 41
OUTLINE ............................................................. 41
FOG LAMP OPERATION .................................... 42
COMBINATION SWITCH READING FUNCTION ... 42
EXTERIOR LAMP BATTERY SAVER CONTROL ... 42
CAN Communication System Description .............. 42
Wiring Diagram — F/FOG — .................................. 43
Terminals and Reference Values for BCM .............. 45
Terminals and Reference Values for IPDM E/R ...... 45
How to Proceed With Trouble Diagnosis ................ 45
Preliminary Check .................................................. 45
CHECK POWER SUPPLY AND GROUND CIR-
CUIT FOR BCM ................................................... 45
CHECK POWER SUPPLY AND GROUND CIR-
CUIT FOR IPDM E/R ........................................... 45
CONSULT-II Function (BCM) .................................. 45
CONSULT-II Function (IPDM E/R) .......................... 45
Front Fog lamps Do Not Illuminate (Both Sides) .... 45
Front Fog Lamp Does Not Illuminate (One Side) ... 48
Aiming Adjustment .................................................. 49
Bulb Replacement .................................................. 49
Removal and Installation ........................................ 50
REMOVAL ........................................................... 50
INSTALLATION .................................................... 50
TURN SIGNAL AND HAZARD WARNING LAMPS ... 51
Component Parts and Harness Connector Location ... 51
System Description ................................................. 51
TURN SIGNAL OPERATION ............................... 51
HAZARD LAMP OPERATION ............................. 52
REMOTE KEYLESS ENTRY SYSTEM OPERA-
TION .................................................................... 53
COMBINATION SWITCH READING FUNCTION ... 53
CAN Communication System Description .............. 53
Schematic ............................................................... 54
Wiring Diagram — TURN — ................................... 55
Terminals and Reference Values for BCM .............. 59
How to Proceed With Trouble Diagnosis ................ 59
Preliminary Check .................................................. 59
CHECK POWER SUPPLY AND GROUND CIR-
CUIT FOR BCM ................................................... 59CONSULT-II Function (BCM) ..................................59
Turn Signals Do Not Operate ..................................59
Front Turn Signal Lamp Does Not Operate ............59
Rear Turn Signal Lamp Does Not Operate .............60
Hazard Warning Lamp Does Not Operate But Turn
Signal Lamp Operates ............................................62
Turn Signal Indicator Lamp Does Not Operate .......63
Bulb Replacement of Front Turn Signal Lamp ........64
Bulb Replacement of Rear Turn Signal Lamp .........64
Removal and Installation of Front Turn Signal Lamp ...64
Removal and Installation of Rear Turn Signal Lamp ...64
LIGHTING AND TURN SIGNAL SWITCH ................65
Removal and Installation .........................................65
REMOVAL ............................................................65
INSTALLATION ....................................................65
HAZARD SWITCH .....................................................66
Removal and Installation .........................................66
REMOVAL ............................................................66
INSTALLATION ....................................................66
COMBINATION SWITCH ..........................................67
Wiring Diagram — COMBSW — ............................67
Combination Switch Reading Function ...................68
Terminals and Reference Values for BCM ..............68
CONSULT-II Function (BCM) ..................................68
Combination Switch Inspection ...............................68
Removal and Installation .........................................70
STOP LAMP ..............................................................71
Wiring Diagram — STOP/L — ................................71
Bulb Replacement of High-Mounted Stop Lamp .....72
Bulb Replacement of Rear Combination Lamp for
Stop Lamp ...............................................................72
Removal and Installation of High-Mounted Stop
Lamp .......................................................................72
REMOVAL ............................................................72
INSTALLATION ....................................................72
Removal and Installation of Rear Combination
Lamp for Stop Lamp ................................................72
BACK-UP LAMP .......................................................73
Wiring Diagram — BACK/L — ................................73
Bulb Replacement ...................................................74
Removal and Installation .........................................74
PARKING, LICENSE PLATE AND TAIL LAMPS ......75
Component Parts and Harness Connector Location ...75
System Description .................................................75
OPERATION BY LIGHTING SWITCH .................75
COMBINATION SWITCH READING FUNCTION ...76
EXTERIOR LAMP BATTERY SAVER CONTROL ...76
CAN Communication System Description ..............76
Schematic ...............................................................77
Wiring Diagram — TAIL/L — ...................................78
Terminals and Reference Values for BCM ..............81
Terminals and Reference Values for IPDM E/R ......81
How to Proceed With Trouble Diagnosis ................81
Preliminary Check ...................................................81
CHECK POWER SUPPLY AND GROUND CIR-
CUIT FOR BCM ...................................................81
CHECK POWER SUPPLY AND GROUND CIR-
CUIT FOR IPDM E/R ...........................................81
CONSULT-II Function (BCM) ..................................81

HEADLAMP (FOR USA)
LT-17
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: June 20062007 Versa
8. CHECK HEADLAMP CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector.
3. Check continuity between IPDM E/R harness connector (A) and
headlamp harness connector (B).
OK or NG
OK >> Replace IPDM E/R. Refer to PG-29, "Removal and
Installation of IPDM E/R" .
NG >> Repair harness or connector.
Headlamp High Beam Does Not Illuminate (One Side)EKS00IMC
1. HEADLAMP HIGH BEAM FUSE INSPECTION
Inspect 10A fuse No. 34 (LH) or fuse No. 35 (RH).
OK or NG
OK >> GO TO 2.
NG >> Repair harness.
2. CHECK BULB
Check headlamp bulb which does not illuminate.
OK or NG
OK >> GO TO 3.
NG >> Replace bulb. Refer to LT-25, "
HEADLAMP (HIGH/LOW)" .
3. CHECK HEADLAMP INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect headlamp connector.
3. Lighting switch is turned to HIGH position.
4. Check voltage between headlamp harness connector and
ground.
OK or NG
OK >> GO TO 4.
NG >> GO TO 5.
CircuitAB
Continuity
Connector Terminal Connector Terminal
RH
E4756 E26
1 Yes
LH 55 E25
WKIA5470E
Terminal
Voltage (+)
(−)
Headlamp connector Terminal
RH E26
1 Ground Battery voltage
LH E25
WKIA5552E

LT-18
HEADLAMP (FOR USA)
Revision: June 20062007 Versa
4. CHECK HEADLAMP GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between headlamp harness connector and
ground.
OK or NG
OK >> Check connecting condition headlamp harness connec-
tor.
NG >> Repair harness or connector.
5. CHECK HEADLAMP CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector.
3. Check continuity between IPDM E/R harness connector (A) and
headlamp harness connector (B).
OK or NG
OK >> Replace IPDM E/R. Refer to PG-29, "Removal and
Installation of IPDM E/R" .
NG >> Repair harness or connector.
High Beam Indicator Lamp Does Not IlluminateEKS00IW4
1. BULB INSPECTION
Inspect CAN communication system. Refer to LAN-44, "
TROUBLE DIAGNOSIS" .
OK or NG
OK >> Replace combination meter. Refer to DI-23, "Removal and Installation" .
NG >> Repair as necessary.
Headlamp Low Beam Does Not Illuminate (Both Sides)EKS00IMD
1. CHECK COMBINATION SWITCH INPUT SIGNAL
With CONSULT-II
1. Select “BCM” on CONSULT-II. Select “HEAD LAMP” on
“SELECT TEST ITEM” screen.
2. Select “DATA MONITOR” on “SELECT DIAG MODE” screen.
Make sure that “HEAD LAMP SW 1” and “HEAD LAMP SW 2”
turns ON-OFF linked with operation of lighting switch.
Without CONSULT-II
Refer to LT- 6 8 , "
Combination Switch Inspection" .
OK or NG
OK >> GO TO 2.
NG >> Check combination switch (lighting switch). Refer to LT- 6 8 , "
Combination Switch Inspection" .
Headlamp connector Terminal
Ground Continuity
RH E26
2Yes
LH E25
PKIC0961E
CircuitAB
Continuity
Connector Terminal Connector Terminal
RH
E47 56 E26
1Yes
LH 55 E25
WKIA5470E
When lighting switch is 2ND
position: HEAD LAMP SW 1 ON
: HEAD LAMP SW 2 ON
PKIA7586E

HEADLAMP (FOR USA)
LT-21
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: June 20062007 Versa
8. CHECK HEADLAMP CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector.
3. Check continuity between IPDM E/R harness connector (A) and
headlamp harness connector (B).
OK or NG
OK >> Replace IPDM E/R. Refer to PG-29, "Removal and
Installation of IPDM E/R" .
NG >> Repair harness or connector.
Headlamp Low Beam Does Not Illuminate (One Side)EKS00IME
1. HEADLAMP LOW BEAM FUSE INSPECTION
Inspect 15A fuse No. 40 (LH) and fuse No. 41 (RH).
OK or NG
OK >> GO TO 2.
NG >> Repair harness.
2. CHECK BULB
Check bulb of headlamp which does not illuminate.
OK or NG
OK >> GO TO 3.
NG >> Replace bulb. Refer to LT-25, "
HEADLAMP (HIGH/LOW)" .
3. CHECK HEADLAMP INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect headlamp connector.
3. Lighting switch is turned to 2ND position.
4. Check voltage between headlamp harness connector and
ground.
OK or NG
OK >> GO TO 4.
NG >> GO TO 5.
CircuitAB
Continuity
Connector Terminal Connector Terminal
RH
E4754 E26
3Yes
LH 52 E25
WKIA5471E
Te r m i n a l
Vo ltag e (+)
(−)
Headlamp connector Terminal
RH E26
3 Ground Battery voltage
LH E25
WKIA5551E

HEADLAMP (FOR USA)
LT-25
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: June 20062007 Versa
Bulb ReplacementEKS00IMH
CAUTION:
After installing bulb, be sure to install plastic cap and bulb socket securely to ensure watertightness.
HEADLAMP (HIGH/LOW)
1. Turn lighting switch OFF.
2. Remove the headlamp. Refer to LT- 2 5 , "
Removal and Installation" .
3. Remove back cover.
4. Unlock retaining spring and remove bulb from headlamp.
PARKING (CLEARANCE) LAMP
1. Turn lighting switch OFF.
2. Remove the headlamp. Refer to LT- 2 5 , "
Removal and Installation" .
3. Turn bulb socket counterclockwise and unlock it.
4. Remove bulb from its socket.
FRONT TURN SIGNAL LAMP
1. Turn lighting switch OFF.
2. Remove the headlamp. Refer to LT- 2 5 , "
Removal and Installation" .
3. Turn bulb socket counterclockwise and unlock it.
4. Remove bulb from its socket.
Removal and InstallationEKS00IMI
REMOVAL
1. Disconnect the negative battery terminal.
2. Remove front bumper fascia. Refer to EI-14, "
FRONT BUMPER" .
3. Remove headlamp bolts (A).
4. Pull headlamp (1) toward the vehicle front, disconnect connec-
tor, and remove headlamp.
INSTALLATION
Installation is in the reverse order of removal.

After installation, perform aiming adjustment. Refer to LT-23, "Aiming Adjustment" .
PKIC1223E

LT-26
HEADLAMP (FOR USA)
Revision: June 20062007 Versa
Disassembly and AssemblyEKS00IMJ
DISASSEMBLY
1. Remove back cover.
2. Unlock retaining spring and remove bulb (High/Low).
3. Turn parking (clearance) lamp bulb socket counterclockwise and unlock it.
4. Remove parking (clearance) lamp bulb from its socket.
5. Turn front turn signal lamp bulb socket counterclockwise and unlock it.
6. Remove front turn signal lamp bulb from its socket.
7. Remove the bumper stay.
ASSEMBLY
Assembly is in the reverse order of disassembly.
CAUTION:

After installing bulb, be sure to install plastic cap securely to insure water tight seal.
1. Retaining spring 2. Parking (clearance) lamp bulb 3. Parking (clearance) lamp bulb socket
4. Halogen bulb (High/Low) 5. Back cover 6. Front turn signal lamp bulb socket
7. Front turn signal lamp bulb 8. Headlamp housing assembly 9. Bumper stay
A. Screw
WKIA5418E

HEADLAMP (FOR CANADA) - DAYTIME LIGHT SYSTEM -
LT-39
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: June 20062007 Versa
Bulb ReplacementEKS00IM5
CAUTION:
After installing bulb, be sure to install plastic cap and bulb socket securely to ensure watertightness.
HEADLAMP (HIGH/LOW)
1. Turn lighting switch OFF.
2. Remove the headlamp. Refer to LT- 2 5 , "
Removal and Installation" .
3. Remove back cover.
4. Unlock retaining spring and remove bulb from headlamp.
PARKING (CLEARANCE) LAMP
1. Turn lighting switch OFF.
2. Remove the headlamp. Refer to LT- 2 5 , "
Removal and Installation" .
3. Turn bulb socket counterclockwise and unlock it.
4. Remove bulb from its socket.
FRONT TURN SIGNAL LAMP
1. Turn lighting switch OFF.
2. Remove the headlamp. Refer to LT- 2 5 , "
Removal and Installation" .
3. Turn bulb socket counterclockwise and unlock it.
4. Remove bulb from its socket.
Removal and InstallationEKS00IM6
REMOVAL
1. Disconnect the negative battery terminal.
2. Remove front bumper fascia. Refer to EI-14, "
FRONT BUMPER" .
3. Remove headlamp bolts (A).
4. Pull headlamp (1) toward the vehicle front, disconnect connec-
tor, and remove headlamp.
INSTALLATION
Installation is in the reverse order of removal.

After installation, perform aiming adjustment. Refer to LT-37, "Aiming Adjustment" .
PKIC1223E
