MITSUBISHI SPYDER 1990 Service Repair Manual E N G I N E O V E R H A U L G e n e r a t o r GENERATOR REMOVAL (1) Remove drive belt. (2) Remove generator. (3) Remove generator (4) Remove bracket. INSTALLATION (1) Install bracket.

Page 218 of 2103

MITSUBISHI SPYDER 1990 Service Repair Manual ENGINE OVERHAUL SYSTEM11301840018Ignition coil fasteners cylinder Rear of REMOVAL The electronic ignition coil pack attaches to the cylinder head cover. (1) Disconnect electrical con

Page 219 of 2103

MITSUBISHI SPYDER 1990 Service Repair Manual ENGINE OVERHAUL Ignition Remove crankshaft position sensor mounting screw.Re- move sensor Revision

Page 220 of 2103

MITSUBISHI SPYDER 1990 Service Repair Manual ENGINE OVERHAUL . INSTALLATION (1) Install crankshaft position sensor. Target alignment (2) The target magnet has locating dowels that fit into off-set machined locating holes in end o

Page 221 of 2103

MITSUBISHI SPYDER 1990 Service Repair Manual ENGINE OVERHAUL Ignition INSPECTION SPARK PLUG CABLE (1) must be between 3,000 to 12,000 ohms per foot of cable. Replace any cable not within toleran ce. IGNITION COIL (1) Meas

Page 222 of 2103

MITSUBISHI SPYDER 1990 Service Repair Manual E N G I N E O V E R H A U L TIMING BELT11301860021 REMOVAL Caution Camshaft or crankshaft should not be rotate after timing belt is removed. Damage to valve components may occ ur

Page 223 of 2103

MITSUBISHI SPYDER 1990 Service Repair Manual ENGINE OVERHAUL Belt Tensioner pin (9) When tensioner is removed from it is necessary to compress the plunger into the tensioner body. the tensioner into a vise slowly compress the plunge

Page 224 of 2103

MITSUBISHI SPYDER 1990 Service Repair Manual ENGINE OVERHAUL Timing INSTALLATION11301870017 (1) Install camshaft seal into cylinder head using Tool until flush with the head. NOTE Shaft seal lip surface must be free of v
