OVERHAUL Front Clutch
FRONT CLUTCH
DISASSEMBLY AND REASSEMBLY
.
,
,
,__
Disassembly steps
Snap ring 2. Clutch reaction plate
3.Clutch disc 4. Snap ring
5.Return spring6. Front clutch piston7.D-ring6.D-ring9. Front clutch retainer
TSB Revision
Page 1258 of 2103
AUTOMATIC TRANSAXLE
OVERHAUL Front Clutch..
21750264
750264
Shear
droopPlate Plate Plate
DISASSEMBLY SERVICE
SNAP RING
(1) Compress the return spring with special tool..
(2) Remove the snap ring.
REASSEMBLY SERVICE POINTS
SNAP RING INSTALLATION
(1) Compress the return spring with the special tool.
(2) Install the snap ring.
CLUTCH REACTION PLATE’:
(1) Install the clutch reaction plate with‘ missing tooth
portions (A in the illustration) in alignment.
NOTE
This design is to facilitate escape of automatic tr ansmis-
sion fluid and improve the cooling efficiency of th e plate
and disc.
. .
(2) Install the innermost the reaction plate with t heir shear
droops directed as shown in the illustration.
Identification of reaction plate
mm (in.)
Plate No.ThicknessIdentification mark
15.0A
23.1
3.1 I
3.7 I
TSB Revision
Page 1259 of 2103
AUTOMATIC TRANSAXLE
OVERHAUL Front Clutch
R I N G S E L E C T I O N
Check clearance snap ring and
plate. To of
the clutch reaction plate down with (11 Ibs.). force.
If clearance is out of standard value, select a sna p ring to
obtain the standard value.
Standard value: mm in.)
NOTE
To install the return spring snap rings, set the rings with their
end gaps
TSB Revision
Page 1260 of 2103
AUTOMATIC TRANSAXLE
OVERHAUL Rear Clutch
.
REAR CLUTCH.
DISASSEMBLY AND REASSEMBLY
__ 13 9 8
Disassembly steps
1.Seal ring
Snap ring5.Thrust race
6.Seal ring7.Snap ring8.Clutch reactionplate9.Clutch disc
10.Clutch plate 11. Clutch pressure plate 12. Wave spring13.Return spring14.Rear clutch piston
15.Rear clutch retainer
16.D-ring
17.D-ring
TSB Revision
Page 1261 of 2103

AUTOMATIC
Rear
750274
D I S A S S E M B L YD I S A S S E M B L Y
WAVE
(1) Compress the return. spring with (1) Compress the return. spring with
(2) Using a screwdriver, remove (2) Using a screwdriver, remove
,,
,,
,,,,
I’I’
,,
REASSEMBLY SERVICE POINTS
WAVE SPRING INSTALLATION
(1) Compress clutch reaction plate with the special tool.
(2) Install the wave spring.
Shear droopClutch disc,I
reaction
PRESSURE PLATE CLUTCH PLATE
CLUTCH REACTION PLATE INSTALLATION
(1) Install the clutch pressure plate, clutch plate
s and clutch
reaction plate with their missing tooth portions (Ain the
illustration) in alignment.
NOTE
This design is to facilitate escape of automatic tr ansmis-
sion fluid and improve the cooling efficiency of th e plates
and disc.
(2)Install the clutch reaction plate with its shear dr oop directed
as shown in the illustration.
SNAP RING SELECTION
(1) Check clearance between the snap ring and clutc h reac-
tion plate. To check the clearance, hold entire
circumfer-
ence of the clutch reaction plate down with (11
force. If clearance is out of standard value, sele ct
a snap ring to obtain the standard value.
Standard value: mm in.)
Page 1262 of 2103
AUTOMATIC TRANSAXLE
OVERHAUL
Install the input shaft with one of its groove
the punch mark on the rear clutch
Revision
Page 1263 of 2103
AUTOMATIC TRANSAXLE
OVERHAUL End Clutch
ENDCLUTCH
DISASSEMBLY AND REASSEMBLY
Disassembly steps
1. Seal ring 2. Snap ring3. Clutch reaction plate
4. Clutch disc 5. Clutch plate
6
8.Return Spring9. End clutch piston10.Oil seal11.D-ring12. End clutch retainer
13.Oil seal
TSB RevisionI
Page 1264 of 2103

AUTOMATIC TRANSAXLE
OVERHAUL End Clutch
2175063
TSB Revision
DISASSEMBLY SERVICE POINT
END CLUTCH ,
Remove the piston. If it is hard to remove, place the retainer
on the workbench with piston side down and blow air through
the oil passage in the back of retainer.
REASSEMBLY SERVICE POINTS
SNAP RING INSTALLATION
Fit a new snap ring to the Guide of the special tool, and
install it to the retainer. Be sure to fit snap ring to the lowest
possible portion of the Guide.
Put the Installer over the Guide and use a press to install
the snap ring in the groove. If the snap ring is in stalled in
the groove, stop using the press. Do not use the pr ess more
than Further, be sure not to support the portion
(center protruded portion) marked with arrows in th e
illustration.
SNAP RING
Check clearance between the snap ring and clutch re action
plate. To check the clearance, hold entire circumfe rence of
the clutch reaction plate down with 50 (11 tbs.) force. If
clearance is out of standard value, select ring to obtain
the standard value.
Standard value: mm in.)
