Page 1977 of 2103
Section A-A
III
INTERIOR Front Seat
INSTALLATION SERVICE POINT
SEAT ANCHOR COVER INSTALLATION
the rear tab of the seat anchor cover in the front seat
rear mounting bracket. Then rotate the cover in the direction
of arrow to install the side tabs in the side holes of the bracket.
Side tab
Rear tab
Section B-B
tabs
TSB Revision
Page 1978 of 2103
INTERIOR Front Seat
DISASSEMBLY AND REASSEMBLY52200150242
power
manual
8.3
11.3Nm8.3
D i s a s s e m b l y s t e p s1. Clip
2. Height adjuster knob
3. Seat slide adjuster lever
4. Reclining adjuster lever 5. Power seat switch knob
6. Power seat switch cover
7. Front seat side shield cover
8. Front seat hinge cover
9. Front inner seat belt
10. Power seat switch 11. Front seat cushion assembly
12. Front seat cushion cover
13. Front seat cushion pad 14. Front seat cushion frame
15. Stay
16. Lumber support knob (Driver’s
seat)
17. Front seat back assembly
18. Headrestraint guide
19. Front seat back cover
20. Front seat back pad
21. Front seat back frame
22. Front seat adjuster inner cover
23. Reclining memory knob 24. Seat adjuster assembly
Revision
Page 1979 of 2103
INTERIOR Seat
INSPECTION
POWER SEAT SWITCH CONTINUITY CHECK
Switch position
Rear height
UP0 0
switch0 0
Down0 0
0 0
All switchesOFF
ALL POWER SEAT MOTORS CHECK
(1) Disconnect each motor at the connector.
(2)Connect the terminals of each motor directly to the battery
and check that the motor turns freely and each adju sting
mechanism operates in the directions shown in the t able
below.
(3)If there is any malfunction, replace the power seat adjuster
assembly.
Name ofDirection of Terminal Terminal Stop position
motor operation
Front height, UpStops within
Rear height the limit of
Downoperation
Slide
Forwardrange.
B a c k w a r d
TSB Revision
Page 1980 of 2103
INTERIOR Rear Seat
REAR SEAT
REMOVAL AND INSTALLATION
4.9 Nm
5 3 . 6
(Split Seat)>
4.9N m
Removal steps
1 . R e a r s e a t c u s h i o n
2. Rear seat hook
3. Rear seat back
N m
N O T E Metal clip position
Striker removal steps
3. Quarter trim, lower(Refer to
4. Striker
TSB Revision
Page 1981 of 2103
INTERIOR Rear Seat
Rear seat hook
Rear seat cushion 0 0 0 0 0 0 4 0
Rear
Hook
hook hole
REMOVAL SERVICE POINT
SEAT CUSHION REMOVAL.
While keeping the rear seat hook pulled, lift up the rear seat
cushion to remove it.
INSTALLATION SERVICE POINTS
SEAT BACK INSTALLATION
Push the rear seat back in the direction indicated in the
illustration; then securely attach the attachment w ire to the
body
hook and install the rear’ seat back.
REAR SEAT CUSHION INSTALLATION
(1) the rear seat cushion attachment wire below the
rear seat back.
(2) Pass the rear inner seat belt through the rear s eat cushion.
(3) Insert the rear seat’ cushion lock plate into the rear seat
hook holes.
TSB Revision
Page 1982 of 2103
INTERIOR Rear Seat
DISASSEMBLY AND REASSEMBLY
ECLIPSE
9.4
Revision
Disassembly steps
Rear seat cushion cover
2. Rear seat cushion pad
3. Knob
4. Garnish
5. Rear seat back hinge
6. Rear seat back cover
Rear seat back pad
8. Rear seat back frame 0 0 0 0 5 3 1 5
Page 1983 of 2103
ECLIPSE SPYDER
INTERIOR Rear Seat
4
Disassembly steps
1. Rear seat cushion cover
2. Rear seat cushion pad
3. Rear seat back cover
4. Rear seat back pad
TSB RevisionI
Page 1984 of 2103
INTERIOR Front Seat Belt
FRONT SEAT BELT
GENERAL IMFORMATION
OPERATION
lWhen the ignition switch is turned ON, the deci-
sion circuit operates and the seat belt warning
light inside of the combination meter flashes
four times for 6 seconds.
l
The decision circuit output makes the seat belt
warning buzzer sound intermittently for 6 se-
conds to indicate unfastening of the seat belt.
SPECIAL TOOLS
lWhen the seat belt is buckled (seatbelt switch
is turned ON), the seat belt warning buzzer
stops sounding.
When the ignition switch is turned OFF, both
seat belt warning light and buzzer do not oper-
ate.
TSB Revision
