BELT INSTALLATION
(1) Align the timing marks on the camshaft sprocket ; crank-
shaft sprocket and oil pump sprocket.
,
. . .
(2) After aligning the timing mark on the oil pump sprocket,’
remove the cylinder block plug and insert a Phillips screw-
driver with a diameter of 8 mm in.), and check
be sure that the screwdriver goes mm (2.36 in.)
or more. If the screwdriver will only go in 20
25 mm
in,) before striking the counterbalance shaft,
turn the sprocket once, realign the timing mark and check
that the screwdriver goes in 60 mm (2.36 in.) or mo re.
Do not take out the screwdriver until the timing ‘b elt is
installed.
(3) Install the timing belt so as not to be
the sprockets, by the following procedure.
Caution
If the timing belt is to install that
the mark indicates the clockwise direction.
(4) Set the tension pulley so that the pin
are at the
bottom, press the tension pulley lightly against th e timing
belt.
TSB Revision
(5) Screw the tool into the engine left support until
its end makes contact with the tensioner
At that
point, screw the tool in
and then remove
the set wire attached to the
tensioner.
(6) Remove the tool.
(7) Tighten the center bolt to the specified torque .
Specified torque: 48 (35
Page 306 of 2103

ENGINE Belt
48
Auto tensioner
A
BELT TENSION ADJUSTMENT
(1) After turning the crankshaft
of a revolution counter-
clockwise, turn it clockwise until the timing marks are
aligned.
(2) Loosen the tension pulley fixing bolt, and then use the
special tool and a torque wrench to
the fixing
bolt to the specified torque while applying tension to the
timing belt.,
Standard value:
3.5 Nm (2.6
belt tension torque> ,
Caution
When tightening the fixing bolt, do not let the ten sion
pulley turn with the bolt.
(3) Turn the crankshaft two revolutions ‘clockwise so that
the timing marks are aligned.
leaving it for 15 min-
utes, measure the amount of protrusion of the auto ten-
sioner.
Standard value (A): 3.8-4.5 mm in.)
(4) If the amount of protrusion is outside the standard value,,
repeat the operation in steps ‘(1) to, (3).
(5) Check again that the timing marks of each sproc ket are
aligned.
BELT FRONT LOWER COVER/TIMING
BELT FRONT UPPER COVER INSTALLATION
II the bolts, being
thread length mm (in.)
850
1.97)
1.10)
not to mistake the bolt size!
Flange bolt
(7.2-8.7)
Flange bolt
(7.2-8.7)
Washer
a s s e m b l e d b o l t
Flange bolt
TSB Revision
Page 307 of 2103
E N G I N E Timing belt
REMOVAL AND INSTALLATION
Nm
R e m o v a l s t e p s
2 .
l
REMOVAL SERVICE
SPROCKET
(1) Use the special tool to remove bolt.
Use the special tool to remove crankshaft sprocket.
Page 308 of 2103

ENGINE Timing Belt
TIMING BELT REMOVAL,,
Caution
If timing belt “B” is to be reused, use
it with an arrow on its flat side indicating the tu rning
direction (to the right).
CounterbalanceINSTALLATION SERVICE POINTS
TIMING BELT INSTALLATION
Install timing belt
by the procedure.
(1) Ensure that crankshaft sprocket “B” timing mark and the
counterbalance shaft sprocket timing mark are align ed.
(2) Fit timing belt
over crankshaft sprocket “B” and the
silent shaft sprocket. Ensure that there is no slac k in
the belt.
BELT TENSION ADJUSTMENT
Adjust the tension of timing belt by the following procedure.
(1) Temporarily fix the timing belt tensioner such that
the center of the tensioner pulley is to the left a nd above
the center of the installation bolt, and temporarily attach
the tensioner pulley so that the flange is toward t he front
of the engine.,
(2) Holding the timing belt “B” up with your
in the direction of the
belt so that the tension side of the belt is taut.
Now tighten
the bolt to fix the tensioner.. ,
Caution
When tightening the ensure that the
pulley shaft does not rotate, with
it to rotate with the bolt can
on the belt.
(3) Press the belt at the shown point by check
belt tension. If not,
S t a n d a r d v a l u e : 5 - 7 m m
. ,
TSB Revision
Page 309 of 2103
E N G I N E T i m i n g
Crankshaft
sprocketCrankshaft
