Page 1969 of 2103
REMOVAL AND INSTALLATION
N O T E
Cowl side trim removal steps1. Scuff plate
2. Cowl side trim
Front pillar
and front roof rail
trim removal steps
3. Front pillar trim
4.
5. holder
6. Inside rear view mirror stay cover
7. Inside rear view mirror
8. Front roof rail trim
Metal clip position Resin clip position
0 0 0 0 4 7 5 4
Quarter steps
l Door(Refer to ening weatherstrip
42 Door O p e n i n g W e a t h e r s t r i p . )
l Rear seat (Refer to
9. Front outer seat belt anchor plate
10. Belt guide cover 11. Rear outer seat belt anchor plate
12. Rear speaker garnish
13. Quarter trim, lower
14. Clip15. Quarter trim, side
TSB Revision
Page 1970 of 2103
INTERIOR Trims
Section D-D
Metal clip position
Resin clip position
19
0 0 0 0 4 7 5 0
SectionG-G
Rear end trim
Luggage compartment side trimremoval steps
16. Luggage compartment floor board17. Partition trim
18. Rear end trim
19. Luggage compartment side trim
Partition trim removal steps
16. Luggage floor board
17. trim
Rear end trim steps
16. Luggage compartment floor board
18. Rear
trim,
Revision
Page 1971 of 2103
lower
Belt guide
cover
REMOVAL SERVICE POINT ,
END TRIM REMOVAL
(1) Remove the four lower clips of end
(2) Remove the six upper clips of the rear end trim , and
then pull up the trim.
INSTALLATION SERVICE POINT
OUTER SEAT BELT ANCHOR PLATE
INSTALLATION
Install the anchor along bead of the
BELT GUIDE COVER INSTALLATION
Accurately insert the belt guide 5 claws into the h oles on
quarter trim, lower.
TSB Revision
Page 1972 of 2103
HEADLINING
INTERIOR Headlining
SPECIAL TOOL
ToolTool number and name
General service toolApplication
Removal of trims, etc.
HEADLINING
REMOVAL AND INSTALLATION
52100140178
and Post-installation Operationl Front Pillar Trim and Quarter Trim Upper Removaland Installation (Refer to
NOTE Metal clip position
Removal steps
a s s e m b l y
2. holder
3. Dome light assembly
4. Rear roof rail trim
5. Headlining
TSB Revision
Rear roof rail trimI
Page 1973 of 2103
INTERIOR Headlining
,
00003744
NOTE Metal clip position
Rear roof rail
Removal steps
1. assembly
2. holder
3. Rear roof rail trim
4. Sunroof inner weatherstrip 5. Sunroof switch cover
6. Sunroof switch panel
7. Headlining
Tab
REMOVAL SERVICE POINT
DOME LIGHT ASSEMBLY REMOVAL
Press and pull the tab downward to remove the dome light
assembly.
INSTALLATION SERVICE POINT
SUNROOF INNER WEATHERSTRIP
INSTALLATION
Install the sunroof inner weatherstrip with its adhered joint
located toward the rear of the vehicle and on its c enter line.
Adhered joint
Front of vehicle
Page 1974 of 2103
INTERIOR Inside Rear View Mirror
INSIDE REAR VIEW MIRROR
REMOVAL AND INSTALLATION
with sunrooh
1
1
00003741
Removal steps
1. Harness cover
2. Inside rear view mirror
REMOVAL AND INSTALLATION
Removal steps
1. Inside rear view mirror stay cover
2. Harness connector 3.
rear view mirror
TSB Revision
Page 1975 of 2103
INTERIORInside Rear View Mirror 7
ISlit IREMOVAL SERVICE POINT’
REAR VIEW MIRROR REMOVAL
a narrow flat-tip. into
rear view mirror bracket, keep the spring pushed
in and
remove the inside rear view mirror in the direction of the
arrow in the illustration.
NOTE
While the spring is pushed in, the connection betwe en the
spring and the
of the button is released.
Revision .
Page 1976 of 2103

INTERIOR Front Seat
FRONT SEAT
REMOVAL AND INSTALLATION
1.
Front seat assembly
2. Harness connector
3. Seat anchor cover 4. Front seat assembly
22
removal steps
Gear box
TSB Revision
N O T EAfter temporarily tightening the seat mounting nutsand bolts in every installation location, fully ten them to thespecified torque.
REMOVAL SERVICE POINTS OF FRONT SEAT
ASSEMBLY WHEN THERE IS A MALFUNCTION
IN THE POWER SEAT SLIDE MECHANISM
If the seat will not slide due to a malfunction of the slide
motor or the slide switch and the seat mounting nut s and
b o l t s c o n s e q u e n t l y c a n n o t b e r e m o v e d , slide the seat by
the following procedure.
(1)Remove the bolts which secure the gear box to the left
and right ends of the rails.
(2) Remove the gear shaft from the left side. Pull the gear
box at the right side toward you to disengage the g ear
of the slide rail.
(3) Push the seat with your hand to slide it to a p osition
where the seat mounting nut and bolt can be removed .
