WINDSHIELD WIPER AND WASHERREMOVAL AND INSTALLATION
1
Wiper motor and assemblyremoval steps
Wiper arm and blade ‘assembly
2. Front deck garnish
3. Wiper motor and link assembly
l B r a k e.‘bolt’ (Refer Cylinder Booster)
6. 7. Washer motor Washer
Washer nozzle and washer hose
removal steps
4. Washer hose connection5. Washer nozzle
TSB Revision ,
Page 1946 of 2103
E X T E R I O R W i n d s h i e l d W i p e r a n d W a s h e r
,
5
Wiper motor and link assemblyremoval steps
1. Wiper arm and blade assembly2. Front deck garnish
3. Wiper motor and link assembly
Washer nozzle and washer hoseremoval steps
4. Washer hose connection5. Washer nozzle
TSB Revision
Washer tank steps
6. Washer tank (Refer to 7. Washer motor
Page 1947 of 2103
EXTERIOR Windshield Wiper and Washer,
CAUTION: SRSBefore removal of bag module and clockspring, refer to the follows:GROUP SRS Service Precautions.
GROUP Air Bag Module and ClockSpring.
Column switch removal steps
l Air bag module (Refer to GROUP Air Bag Module and Clock Spring.)l Steering wheel (Refer to GROUP Steering Wheel and Shaft.)
9. Column cover, lower
10. Column cover, upper
11. Column switch assembly
(with built-in wiper and washer
switch, and wiper relay)
12. Clock spring* (Refer to GROUP Air Bag Module and Clock
Spring.)
NOTE
Do not remove parts marked with* from the column sw itch
except when removal is absolutely necessary.
TSB Revision
Page 1948 of 2103

EXTERIOR Windshield Wiper and Washer
I
Inspection while operatingspeed speed
stop
INSTALLATION SERVICE POINT
WIPER ARM AND ASSEMBLY
INSTALLATION
Adjust the wiper and blade assembly so that the cle arances
between the wiper blade edges and the ceramic line are
at the standard value.
Standard value (A): 47
5 mm (1.85 in.)
(B):
5 mm in.)
INSPECTION51101270022
WASHER MOTOR CHECK
(1) With the washer motor installed to the washer t ank, fill
the washer tank with water.
(2) When the battery is connected as shown in the f igure,
check that the water squirts out strongly.
WIPER MOTOR CHECK
Do not remove the motor and link assembly when chec king.
Wiper Motor at Low Speed and High Speed Operation
Connect a battery to the wiper motor as shown in the illustration
and inspect motor operation at low speed and high speed.
Wiper Motor at Stop Position Operation
(1) Run the wiper motor at low speed, disconnect th e battery,
and stop the motor.
(2) Reconnect the battery as shown in the illustrat ion, and
confirm that after the motor starts turning at low speed,
it stops at the automatic stop position.
TSB Revision
Page 1949 of 2103
E X T E R I O R Windshield Wiper and
C O L U M N S W I T C H
Intermittent Wiper Relay (Intermittent
Check)
(1) Connect the column switch connector.
(2) Turn the ignition switch to ACC.
(3) Inspect the intermittent
wiper
switch is turned to
Vehicles with variable intermittent control
FAST
2 seconds
SLOW: Approx. 15 seconds
,
,
,
Revision
Page 1950 of 2103

EXTERIOR Rear Wiper and Washer
REAR WIPER AND WASHER51100010045
GENERAL
OPERATION
Low-speed wiper operationI n t e r m i t t e n t w i p e r
,
l
When the wiper switch is placed in the ON
(LO) position with the ignition switch in the ACC
or ON position, the wiper operates continuously
at low speed.
Auto wiper stop operation
lWhen the wiper switch is placed in the OFF position, the cam contacts of wiper motor
causes current to flow through the auto wiper
stop circuit, allowing the wiper blades to cycle
before they reach to the stop positions. l
When the wiper switch
placed in the
position with the ignition switch in ACC or ON
position, the intermittent relay is turned
on and off.
lWhen the contacts are closed, the wiper motor
is energized.
lWhen the wiper motor is energized, the relay
contacts open; however, the cam contacts keep
the wiper motor energized until the wiper blades
return to their stop position.
SERVICE SPECIFICATION
I Standard valueI
Rear wiper blade installation position mm (in.)I
TROUBLESHOOTING51100070043
TROUBLESHOOTING HINTS
1. Wipers does not operate. 1) Windshield wiper is not operative, either.
l Check the multi-purpose fuse No. 9.
2. Low-speed wiper operation is inoperative. l Check the wiper switch.
3. Intermittent wiper operation is inoperative.
lCheck terminal voltage of wiper switch (with
a built-in intermittent wiper relay) with the intermittent wiper relay energezed. (see
table below.)
4. Wiper does not stop. l Check the wiper motor.
l Check the intermittent wiper relay.
l Check the wiper switch.
5. Washer is inoperative. 1) Wiper is operative.l Check the washer motor.
l Check the washer switch.
Terminal No. Voltage Check
6
Battery positive voltage
O-Battery positive voltage (alternating)
Intermittent wiper relay or rear wiper switch
Intermittent wiper relay
(Normal)
TSB Revision
Page 1951 of 2103
EXTERIOR Rear Wiper and
REAR WIPER AND WASHER
REMOVAL AND INSTALLATION
Non-turbo
Wiper and washer switch removal
steps
l Center air outlet assembly
(Refer to GROUP 55 Ventilators.)
1. Wiper and washer switch
Wiper motor removal steps
2. Wiper blade 3 . W i p e r a r m 4. Spacer assembly
l o w e r (Refer to GROUP Trims.)
5. Wiper motor - 5
- - - -7.45.4
8
Washer tank and hose removalsteps
l
Quarter upper trim (L.H.),
quarter lower trim (L.H.) rear end trim,
rear side trim,
upper (Refer, to GROUP Trims.)
6. Washer nozzle 7. Joint assembly
8. Tube assembly
Hose assembly
10. Washer tank 11.
motor
TSB Revision
Page 1952 of 2103
51-22EXTERIOR Rear and Washer
Turbo
0 0 0 0 3 5 3 3
Wiper and washer switch removal
steps
l Center air outlet assembly
(Refer to GROUP 55 Ventilators.)
1. Wiper and washer switch
Wiper motor removal steps
2. Wiper blade 3 . W i p e r a r m 4. Spacer assembly
l o w e r t r i m
(Refer to GROUP Trims.)
5. Wiper motor
TSB Revision
Washer tank and hose removal
steps
l Quarter upper trim (L.H.), quarter
lower trim (L.H.), rear end trim, rear
side trim,
upper trim (Refer to T r i m s )
6. Washer nozzle
7. Joint assembly
8. Tube assembly
9. Hose assembly
10. Tube assembly
Spare tire
11. Washer tank
12. Washer motor
