MITSUBISHI SPYDER 1990 Service Repair Manual BODY Electric Convertible Top
(2) Depress lower clips.
(3)While holding lower clip, push the lower front of the switch
past the lower clip 5 mm in.)].
(4) Depress upper clip

Page 1930 of 2103

MITSUBISHI SPYDER 1990 Service Repair Manual NOTES

Page 1931 of 2103

MITSUBISHI SPYDER 1990 Service Repair Manual E X T E R I O R
CONTENTS
AERO PARTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . .11REAR BUMPER. . . . . . . . . . . . . . . . . . . . . . . . . . .4
Aero Parts . . . . . . . . . . . . . .

E X T E R I O R
CONTENTS
AERO PARTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . .11REAR BUMPER. . . . . . . . . . . . . . . . . . . . . . . . . . .4
Aero Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11REAR WIPER AND WASHER . . . . . . . . . . . . .20Sealant and Adhesive . . . . . . . . . . . . . . . . . . . . . . . .11General Information. . . . . . . . . . . . . . . . . . . . . . . . .20
DOOR MIRROR. . . . . . . . . . . . . . . . . . . . . . . . . . . 25Rear Wiper and ‘Washer. . . .. . . . . . . . . . . . . . . . .21
Door Mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25Service ‘Specification. . . . . . . . . . . . . . . . . . . . . . . .20
Special Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
25Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
FRONT BUMPER. . . . . . . . . . . . . . . . . . . . . . . . .2WINDSHIELD WIPER AND WASHER* . . . . . .13
6General Information. . . .. . . . . . . . . . . . . . . . . . . .13GARNISHES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Service Specification. . . . . . . . . . . . . . . . . . . . . . . .13
MOLDINGS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Molding. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7Windshield Wiper and Washer . . .. . . . . . . . . .15
Sealant and Adhesive . . . . . . . . . . . . . . . . . . . . . . . .7
WARNINGS REGARDING SERVICING OF SUPPLEMENTAL RESTRA INT SYSTEM (SRS) EQUIPPED VEHICLES
WARNING! (1)
Improper service or maintenance of anycomponentof the SRS, or any SRS-related component, can lead to personalinjury or death to personnel (from inadvertent firing of the air bag) the the SRS inoperative). Service or maintenance of any SRS component or SRS -related component must be performed only at an authorized. MITSUBISHI dealer.(3) MITSUBISHI dealer personnel must thoroughly rev iew this manual, and especially its Supplemental
Restraint System (SRS) and GROUP 00 Maintenance Service, before beginning any service or maintenance of any
component of the SRS or any SRS-related component.
NOTE
The includes the following components: warning light, air bag module, and interconnecting wiring.Other components (that may have to be removed/installed in connection with service or maintenance) areindicated in the table of contents by an asterisk

Page 1932 of 2103

MITSUBISHI SPYDER 1990 Service Repair Manual EXTERIOR Front Bumper
FRONT BUMPER
,
REMOVAL AND INSTALLATIONPre-removal and Post-installation Operation
Splash shield Removal and Installation
(Refer to GROUP 42
Under Cover.)
6
1

Page 1933 of 2103

MITSUBISHI SPYDER 1990 Service Repair Manual EXTERIOR Front Bumper
DISASSEMBLY AND REASSEMBLY
8
Disassembly
1. Front fog light bezel
2. Air intake cover
3. Front license plate bracket
4. Bolt plate
5. Front bumper side plate 6.

Page 1934 of 2103

MITSUBISHI SPYDER 1990 Service Repair Manual REAR BUMPER
REMOVAL AND INSTALLATION
EXTERIOR Rear Bumper
and Post-installation Operation
Rear End Trim and Rear Side Trim Removal and
Installation (Refer to GROUP
Trims.)
5
Remov

Page 1935 of 2103

MITSUBISHI SPYDER 1990 Service Repair Manual EXTERIOR Rear, Bumper
DISASSEMBLY AND REASSEMBLY
6
8 ’
3
Disassembly steps
1. License plate light
2. Back-up light
3. Rear bumper lower plate
4. Rear bumper reinforcement 5. Rear bumper core
6

Page 1936 of 2103

MITSUBISHI SPYDER 1990 Service Repair Manual 51-6EXTERIOR Garnishes , .
GARNISHES
REMOVAL AND INSTALLATION
13Nm91
9 .
3
Front deck garnish removal steps
1. Wiper arm assembly
2. Front deck garnish
Rear panel garnish removal steps
