MITSUBISHI SPYDER 1990 Service Repair Manual ENGINE (TURBO) AND ENGINE> Troubleshooting INSPECTION PROCEDURE USING AN ANALYZER VOLUME AIR FLOW SENSOR Measurement method 1. Disconnect the volume air flow sensor connector, and

Page 634 of 2103

MITSUBISHI SPYDER 1990 Service Repair Manual ENGINE (TURBO) AND ENGINE> Troubleshooting . . Observation conditions (pattern changes with engine changes.) . id 10-- 0Time Wave pattern observation points Check to be sure that

Page 635 of 2103

MITSUBISHI SPYDER 1990 Service Repair Manual ENGINE (TURBO) AND ENGINE> CAMSHAFT POSITION SENSOR AND POSITION SENSOR Measurement method 1.Connect the analyzer special patterns pickup to position sensor terminal 2. 2.Disconnect t

Page 636 of 2103

MITSUBISHI SPYDER 1990 Service Repair Manual ENGINE (TURBO) AND ENGINE> Troubleshooting Analyzer Examples of abnormal wave , l Example 1 Cause problem Sensor interface malfunction Wave pattern characteristics Rectangular wave p

Page 637 of 2103

MITSUBISHI SPYDER 1990 Service Repair Manual ENGINE (TURBO) AND ENGINE> Troubleshooting Standard Wave Pattern Observation conditions FunctionSpecial patterns Pattern height Variable Standard wave pattern Variable knobAdjust while vi

Page 638 of 2103

MITSUBISHI SPYDER 1990 Service Repair Manual Analyzer STEPPER MOTOR Engine (Turbo)> Measurement method 1. Disconnect the stepper motor connector, and connect the special tool (test harness: in between. 2. Connect the analyzer s

Page 639 of 2103

MITSUBISHI SPYDER 1990 Service Repair Manual Wave pattern observation pointsCheck that the standard wave pattern appears when t he stepper operating. Point A: Presence or absence of induced voltage fro m the motor turni

Page 640 of 2103

MITSUBISHI SPYDER 1990 Service Repair Manual ENGINE (TURBO) AND ENGINE> Analyzer IGNITION COIL AND IGNITION l Ignition coil primary Refer to GROUP 16 Ignition System. l Ignition power transistor control signal. Measurement
