Page 1625 of 2103
REAR SUSPENSION Upper ‘Arm
U P P E R A R M A S S E M B L Y
REMOVAL AND INSTALLATION
Post-installation Operationl Wheel Alignment Check and Adjustment(Refer to
457Nm
57Nm
41
39 Nm
Removal steps
1. Upper arm and knuckle connecting
bolt2. arm assembly mounting
3. Upper arm assembly
4. Upper arm bracket
CautionIndicates parts which should be temporarily tighten ed,and then fulltightened with the on the groundin the unlaen condition.
TSB Revision
Page 1626 of 2103
Upper armUpper armbracket
that the dimension shown in the at the
value.
REAR SUSPENSION Upper Arm Assembly
I N S T A L L A T I O N
UPPER ARM
Tighten the upper arm installation bolt
Standard value (A) 37.2 2 mm (1.46 in.)
Upper arm bracket
installation nut and bolt
NOTE
If the upper arm bracket is
with
standard value, the dimensibn is
follows;
B: 213.5 mm (8.4 in.).
C: 289.2 mm (10.6 in.)
Upper end of upper armbracket
Center of the
arm
INSPECTION
lCheck the bushings for wear and deterioration.
lCheck the upper arm for bends
lCheck all bolts for condition and
TSB Revision
Page 1627 of 2103
REAR SUSPENSION Trailing Arm Assembly
TRAILING ARM ASSEMBLY
REMOVAL AND INSTALLATION
Post-installation OperationlWheel nment Check and Adjustment
(Refer to
137-157
118-13785-99
steps
1. Knuckle and trailing arm assembly
connecting bolt
2. Grommet
3. Trailing arm assembly mounting bolt
4. Stopper
5. Trailing arm assembly
Indicates parts which should be and then fully tightened with the vehicles on the g roundin the unladen condition.
lCheck the bushings for and
Check the trailing arm for bends or damage.
TSB Revision
Page 1628 of 2103
2 REAR SUSPENSION Lower Arm and Toe
LOWER ARM AND TOE CONTROL ARM ASSEMBLIES
REMOVAL AND INSTALLATION
Post-installation OperationlWheel Alignment Check and Adjustment
(Refer to , ,
89-78
39 Nm
Lower arm assembly removal steps
1. Lower arm cover
2. Stabilizer link ball joint and lower
arm connection3. ABS wheel-speed sensor clamp
bolts
with 4. Lower arm assembly and knuckleconnecting bolt5. Lower arm assembly mounting bolt
6. Lower arm assembly Toe
control arm assembly removal
steps
7. Toe control arm ball joint andknuckle , 6. control mounting
9. arm ,
Cautionl Indicates which should tightened,
and then fully with on the groundin the unladen
Cord
REMOVAL’ SERVICE POINTS
CONTROL ARM BALL JOINT AND
KNUCKLE DISCONNECTION
Caution
1.Be sure to tie the cord of the special tool to a ne arby
part.
2. Loosen the nut but do not remove it.
T S B. .
Page 1629 of 2103

REAR SUSPENSION Lower Arm and Toe Control Arm Assemblies
Toe controlarm sideEccentric
CONTROL, ARM
BOLT REMOVAL
Make mating marks on the toe control arm’ and eccen tric
cam bolt before removing the bolt.
INSPECTION
lCheck the bushings for wear and deterioration.
l Check the lower arm or toe control arm for bends or
damage.
lCheck bolts for condition and straightness.
BALL JOINT BREAKAWAY TORQUE CHECK
(1) After shaking the ball joint stud several times , install the
nut to the stud and use the special tool to measure the
breakaway torque of the ball joint.
Standard value: Nm
When the measured value exceeds the standard value ,
replace the toe control arm assembly.
(3) When the measured value is lower than the stand ard
value, check that the ball joint turns smoothly wit hout
excessive play. If so, it is possible to use that b all joint.
BALL JOINT DUST COVER CHECK
If there are any cracks in or damage to the dust co ver, replace
the arm assembly.
CONTROL ARM BALL JOINT DUST COVER
REPLACEMENT
Replace the dust cover by the following procedure o nly if
the dust cover has become damaged by accident durin g
servicing.
(1) Remove the dust cover.
(2) Apply multi-purpose grease to the lip and insid e of the
dust cover.
(3) Drive in the dust cover with the special tool u ntil it is
fully seated.
TSB Revision
Page 1630 of 2103
REAR SUSPENSION Shock Absorber
. .
SHOCK ABSORBER ASSEMBLY34100510067
REMOVAL AND INSTALLATION
and Post-installation Operation
(1) Service Lid Removal and Installation (Refer to
( 2 ) L u g g a g e c o m p a r t m e n t s i d e t r i m
98 Nm
Removal steps
1. Cap
2 . F l a n g e n u t s
3. Bolt
4 . S h o c k a b s o r b e r
INSPECTION
lCheck the rubber parts for cracks
lCheck the shock, absorber for oil leakage
or abnormal noise.
TSB Revision
Page 1631 of 2103
REAR SUSPENSION Shock Absorber
DISASSEMBLY AND REASSEMBLY
Disassembly steps
n u t
Upper bushing A 4. Upper bracket assembly
5. Upper spring pad
6. Upper bushing
22Nm16
6
8
. 10
7.Collar8.Cup assembly9.Dust cover10.Bump rubber11.Coil spring
12. Shock absorber assembly
DISASSEMBLY SERVICE POINTS
SELF-LOCKING NUT REMOVAL
(1)
the coil spring using the special tools.
Caution
1. Install the special tools evenly, and so that th e
maximum length will be attained the
installation range.
2.Do not use an impact wrench to tighten the special
tool bolt.
TSB Revision
Page 1632 of 2103
REAR SUSPENSION Shock
Coil spriedgeBracket
(2) While holding the piston remove
Caution
Do not use an impact wrench to tighten the self-loc king
n u t .
REASSEMBLY SERVICE POINTS
COIL SPRING INSTALLATION
(1) Use the special tools to compress the coil spring and
, install it to the shock absorber.
Caution
not use an wrench to tighten the special
tool bolt.
(2) Align the edge of the coil spring to the steppe d part of
the shock absorber spring seat.
UPPER BRACKET
the bracket as shown in the ,
.
SELF-LOCKING NUT INSTALLATION
Temporarily tighten the ‘self-locking
(2) Remove the special tools and
tighten
self-locking nut to the ,
Caution
Do not use an wrench.
Revision
