STEERING Power Steering Pump Engine (Turbo) and
Terminal assembly
Direct round edgeto the cam
9
PRESSURE SWITCH ASSEMBLY INSTALLATION
Fit the. spring to the oil pump body with the larger diameter
end at. the terminal assembly side.
ROTOR INSTALLATION
Install the rotor to the pulley assembly so that th e rotor’s
punch mark is at the pump cover side.
CAM RING INSTALLATION
Install the cam ring with the punch mark facing the side plate.
VANE INSTALLATION
Install the vanes on the rotor, paying close attention to the
installation direction.
DRIVE PULLEY INSTALLATION
Use the special tool to secure the drive pulley, an d then
install the drive pulley mounting nuts.
TSB Revision
Page 1818 of 2103
S T E E R I N G ower Steering Oil Pump Engine (Turbo) and Engine>
INSPECTION
l Check the flow control valve for
Check the pulley assembly for wear or damage.
l Check the groove of rotor and vane for “stepped” we ar.
l Check the contact surface of cam ring and vanes for
“stepped” wear.
l Check the vanes for damage.
TSB Revision
Page 1819 of 2103
STEERINGPower Steering Hoses
Operation
l Fluid, Draining (Refer to l Front Bumper Removal(Refer to GROUP 51 Front Bumper.)l Tank Removal (Refer to GROUP 51 Windshield Wiper and
POWER STEERING HOSES ENGINE
REMOVAL AND
11 Nm
11
3.9 Nm2.9
Removal steps
1.Oil reservoir
h o s e
Suction hose5.Return hose6.Return hose7.Pressure tube
8.Return tube
T S B R e v i s i o n
9.Pressure10. Return 11.Pressure tubs
12.tube13. fascia bracketFront14.Air guide duct15.Cooler tubs
Page 1820 of 2103
STEERING Power Steering Hoses Engine .
White line
REMOVAL POINT
PRESSURE HOSE REMOVAL
Caution
A/C compressor is below the oil pump, so coverthe
compressor with a shop towel before removing-any
INSTALLATION SERVICE POINT
PRESSURE HOSE INSTALLATION
When the pressure hose is installed, align the white line on
the
hose with the white line on the pressure tube
so that together they form a straight line.
Revision
Page 1821 of 2103
STEERING Power Steering Hoses Engine (Turbo) and
POWER STEERING HOSES
ENGINE (TURBO) AND ENGINE>
REMOVAL AND INSTALLATION
Post-installation Operationl Front Bumper Installation(Refer to GROUP 51 Front Bumper.)lDrive-belt Tension Adjustment Engine (Turbo):Refer to GROUP On-vehicle Service, Engine: Refer to GROUP 11 E-On-vehicle Service.)lPower Steering Fluid Supplying l Power Steering Fluid Line Bleeding (Refer to
23-26 Nm
34 Nm
25
11 Nm 11 Nm88
118
Removal steps
1. Brake fluid reservoir assembly
2. Clutch fluid reservoir assembly
3. A/C compressor4.Oil reservoir
hose
Suction hose
8.Return hose
9.Return hose
10.Return tube11.Pressure tube 12. Pressure hose13.Return hosePressure tube
15.Return tube16. fascia bracket
17. Air guide duct
18.Cooler tube
TSB Revision
Page 1822 of 2103

STEERING Power Steering Hoses Engine (Turbo) and Engine>
REMOVAL SERVICE
BRAKE FLUID RESERVOIR ASSEMBLY
REMOVAL
Disconnect the brake fluid level sensor connector and
the brake fluid reservoir assembly from the dash panel with
the hose still attached.
NOTE
Place the removed reservoir assembly in a place whe re it
will not be a hindrance when removing and installin g the
power steering gear box, and tie it with a cord.
CLUTCH FLUID RESERVOIR ASSEMBLY
REMOVAL
Remove the clutch fluid reservoir assembly from the dash
panel with the hose still attached.
NOTE
Place the removed reservoir assembly in a place whe re it
will not be a hindrance when removing and installin g the
power steering hoses, and tie it with a cord.
A/C COMPRESSOR REMOVAL
Disconnect the A/C compressor connector remove the
compressor from the compressor bracket with the hos e still
attached.
NOTE
Place the removed in a where it will not be a hindrance when
removing and installing the power steering hoses an d tie
it with a cord.
Caution
Do not damage the joint between the A/C hose and the
A/C pipe.
PRESSURE HOSE/SUCTION HOSE REMOVAL
Caution
Generator is below the oil pump, so cover the gener ator
with a shop towel before removing any of the hoses.
INSTALLATION SERVICE POINT
PRESSURE HOSE INSTALLATION
(1) Connect the pressure hose so that its slit part contacts
the oil pump’s guide bracket.
TSB Revision
Page 1823 of 2103
STEERINGPower Steering Hoses Engine (Turbo) and ,
White line
(2) When the pressure hose is installed, align the
on the pressure hose with the white line on the pressure
tube so that together they form a straight line.
TSB Revision
