AUTOMATIC1 ENGINE (NON-TURBO)> Control
TRANSAXLE CONTROL
Be not to subject the to any shocks
trol cable and shift lever assembly.
4.9Nm
9.9 N m
8.3
i s - -11 Nm8.3
NOTE Resin clip position
Transaxle control cable assemblyremoval steps
1. Air cleaner and air intake hose as-sembly
2. Center panel
3. Cup holder assembly
4. Floor console assembly
5. Console side cover (L.H.)
6. Console side cover (R.H.)
7. Nut
8. Clip 9. Clip
10. Transaxle control cable connection
Nut12. EATX-ECM13. Transaxle control cable assembly
Selector lever assembly removalsteps
2. Center panel
3. Cup holder assembly
4. Floor console assembly
5. Console side cover (L.H.)
6. Console side cover (R.H.)
9. Clip
10. Transaxle controlcable connection14. Snap pin
15. Key interlock cable connection
16. Shift lock cable connection
17. Overdrive switch/position indicator
light connector
18. Selector lever assembly
TSB Revision
Page 1194 of 2103
AUTOMATIC TRANSAXLE
ENGINE Transaxle Control
NUT INSTALLATION
al controllever(1) Put the selector lever in the “N” position.
(2) Loosen the adjusting nut, gently pull the trans axle control
cable in the direction of the arrow tighten nut.
TSB Revision
Page 1195 of 2103
AUTOMATIC TRANSAXLE ,
ENGINE (NON-TURBO)> Transaxle Control
SELECTOR LEVER ASSEMBLY. DISASSEMBLY AND REASSEMBLY
(arrow-located places)
Disassembly steps
1.Overdrive switchposition indicatorlight connector case
2.Cover 3. Selector knob
4. Overdrive switch button
5.Overdrive switch6. Pin7.Push button
8.Spring9. Indicator panel upper10.Slider11. Indicator panel
11'N m228.3
12. Position indicator light assembly13.Sleeve14.Bolt15.Lever
16. Detent, spring’ assembly17.B u s h i n g
19.Cotter pin20. Washer.
21.Lock cam 22.Bracket assembly
TSB Revision
Page 1196 of 2103

AUTOMATIC TRANSAXLE
ENGINE Transaxle Control
Terminal
Flat-tip screw driver
TSB Revision
Sleeve
Selector lever
Detent pin
OVERDRIVE SWITCH POSITION
LIGHT CONNECTOR CASE REMOVAL
Use a flat-tip screwdriver or similar tool to pull out the terminal
from the overdrive switch/position indicator light connector
case.
OVERDRIVE SWITCH
SWITCH REMOVAL
(1) Use a flat-tip screwdriver to remove the overdr ive switch
button.
(2) Remove the overdrive switch mounting screw.
(3) Pressing the switch, remove the overdrive switch.
REASSEMBLY SERVICE POINTS
DETENT SPRING ASSEMBLY
Shift the selector lever to the neutral position, and then
install the detent spring assembly so that the roll er is in the
detent plate groove.
SELECTOR KNOB
(1) Put the selector lever in the “N” position, tur n the sleeve
and adjust the dimension between the sleeve and the end of the lever so it reaches 16 mm (1.02 in.)
(2) Install the selector knob.
(3) Check that dimension (A)
the detent plate
detent pin reaches the standard value.
Standard value (A): 1.7-2.4
in.)
(4) If outside the standard value, remove the selec tor knob
and turn the sleeve again to readjust.
Page 1197 of 2103
ENGINE
l
lCheck the bushing wear l
OVERDRIVE SWITCH CONTINUITY
SwitchpositionTerminal.
3 ,
OD is operating (ON)
OD is not operating (OFF)
0 ’
,
,
Revision
,
Page 1198 of 2103

AUTOMATIC TRANSAXLE
E N G I N E ( N O N - T U R B O ) >Automatic
Transaxle KeyInterlock and Shift LockMechanisms
AUTOMATIC TRANSAXLE KEY INTERLOCK AND SHIFT LOCK
MECHANISMS
Caution: SRSBe careful not to subject the SRS-ECU to any shocksduring removal and installation of the key interloc kcable and shift lock cable.
NOTE
567I
8 ’
clipposition position
Key
interlock cable removal steps
1. Plug A
2. Plug
3. Hood release lever
4. Instrument panel under cover
5. Steering column lower cover
6. Center panel7. Cup holder assembly
8. Floor console assembly
9. Console side cover (L.H.)
10. Cover11. Cam and lever
12. Key interlock cable connection
13. Slide lever
14. Snap pin
15. Key interlock cable connection 19. Key interlock cable 11 Nm
8.3
Shift lock cable removal steps
1. Plug A
2. Plug
3. Hood release lever
4. Instrument panel under cover 6. Center panel
7. Cup holder assembly
8. Floor console assembly
9. Console side cover (L.H.)
16. Shift lock cable connection
17. Cotter pin
18. Shift lock cable connection
20. Shift lock cable
TSB Revision
Page 1199 of 2103
AUTOMATIC TRANSAXLE Key Interlock
E N G I N E a n d
SHIFT LOCK CABLE/
I N S T A L L A T I O N
Securethesection between the the
and key interlock cable the
assembly.
Caution
Do not change the of lock
lever assembly.’
L O C K C A B L E L EVER
INSTALLATION . .
(1) Place the
lever in
(2) Fasten the shift lock cable at the end
of the shift lock is-positioned the
KEY INTERLOCK CABLE (SELECTOR LEVER
(1) Install the key interlock cable cam.
(2) Install the spring and washer of
interlock cable
(3)
pushing the cable coupling portion of the
lock cam in the direction A, tighten the nut to fas ten the
key interlock cable.
INSPECTION
Check the cable assemblies for function and for dam age.
Page 1200 of 2103

AUTOMATIC TRANSAXLE
ENGINE (NON-TURBO)> Transaxle Assembly
TRANSAXLE ASSEMBLY
l Transaxle Fluid Draining
l Transaxle Fluid Draining
(Refer to GROUP 00 Maintenance service)
(Refer to GROUP 00 Maintenance service)
l Battery Removal
l Battery Removal
l Under Cover Removal
l Under Cover Removal
(Refer to GROUP 42
Under Cover)
(Refer to GROUP 42 Under Cover)
7454
Post-installation Operationl Under Cover Installation
(Refer to GROUP Under Cover)
l Battery Installation
l Transaxle Fluid Supplying
(Refer to GROUP 00
Maintenance Service)
l Selector Lever Operation Check
9.2
6
5140
69 Nm51 I
42
51
Removal steps
1. Air cleaner cover and air intake
hose assembly2. Air cleaner element
3. Battery tray
4. Battery tray stay 5. Transaxle control cable connection
6. Oil dipstick and guide assembly
7. Starter motor
8. Output speed sensor connector
9. Transaxle range switch connector
10. Solenoid and pressure switch con-
nector11. Input speed sensor connector
12. Transaxle assembly mounting bolts13. roll stopper bracket mounting
14. Transaxle mounting bracket mount; ing nuts
15. Transaxle oil cooler hoses connec- tion
l Supporting engine assembly
