System Description/Door Lock for LHD
Models
OPERATION
Power door lock/unlock operation by door key cylinder
With the key inserted into front door key cylinder, turning it to LOCK will lock all doors.
With the key inserted into front door key cylinder, turning it to UNLOCK will unlock all doors.
Power door lock/unlock operation by multi-remote controller (If equipped)
Pressing multi-remote controller LOCK button will lock all doors.
Pressing multi-remote controller UNLOCK button once will unlock driver door. Then, if an unlock signal is
sent from the remote controller again within 5 seconds, all other doors will be unlocked.
Power door lock/unlock operation by lock/unlock switch
With lock/unlock switch on driver door trim setting to LOCK will lock all doors.
With lock/unlock switch on driver door trim setting to UNLOCK will unlock all doors.
Key reminder system
If the ignition key is in the ignition key cylinder and driver door is open, setting lock/unlock switch, lock
knob, key or multi-remote controller to“LOCK”locks the door once but then immediately unlocks all doors.
(signal from door unlock sensor driver side)
POWER DOOR LOCK
EL-245
Page 1378 of 2267
Schematic
YEL897C
POWER DOOR LOCK
EL-246
Page 1379 of 2267
YEL898C
POWER DOOR LOCK
Schematic (Cont’d)
EL-247
Page 1380 of 2267
Wiring Diagram—D/LOCK—
YEL899C
POWER DOOR LOCK
EL-248
Page 1381 of 2267
YEL900C
POWER DOOR LOCK
Wiring Diagram—D/LOCK—(Cont’d)
EL-249
Page 1382 of 2267
YEL901C
POWER DOOR LOCK
Wiring Diagram—D/LOCK—(Cont’d)
EL-250
Page 1383 of 2267
YEL902C
POWER DOOR LOCK
Wiring Diagram—D/LOCK—(Cont’d)
EL-251
Page 1384 of 2267
YEL903C
POWER DOOR LOCK
Wiring Diagram—D/LOCK—(Cont’d)
EL-252
