Page 1497 of 2267

NISSAN PRIMERA 1999 Electronic Repair Manual Engine Compartment YEL234C Front wiper motor (LHD models) ABS actuator and electric unit (Control unit)Relay boxFront wiper motor (RHD models) Glow relay (CD engine models) Fusible link and fuse box C

Page 1498 of 2267

NISSAN PRIMERA 1999 Electronic Repair Manual Passenger Compartment LHD MODELS YEL235C Time control unit Blower relay Circuit breaker-1Indicator control unit Stop lamp switchNATS IMMU Auto level control unit Headlamp washer timer Ignition relay C

Page 1499 of 2267

NISSAN PRIMERA 1999 Electronic Repair Manual RHD MODELS YEL236C NATS IMMU Auto level control unitHeadlamp washer timer Stop lamp switch A/C LOW relay. A/C MED-LOW relay. A/C MED-HIGH relay. A/C HIGH relayFuse block (J/B) Power window relay Air b

Page 1500 of 2267

NISSAN PRIMERA 1999 Electronic Repair Manual OutlineLHD MODELS RHD MODELS YEL367B Rear door harness RH (5-door Hatchback and Wagon) Front door harness RHRoom lamp harness Back door harness Hatchback and Wagon Rear door harness LH (5-door Hatchba

Page 1501 of 2267

NISSAN PRIMERA 1999 Electronic Repair Manual How to Read Harness Layout Example: G2E1B/6: ASCD ACTUATOR Connector color / Cavity Connector number Grid reference The following Harness Layouts use a map style grid to help locate connectors on the

Page 1502 of 2267

NISSAN PRIMERA 1999 Electronic Repair Manual Engine Control Harness QG ENGINE YEL957C HARNESS LAYOUT EL-370

Page 1503 of 2267

NISSAN PRIMERA 1999 Electronic Repair Manual YEL958C HARNESS LAYOUT Engine Control Harness (Cont’d) EL-371

Page 1504 of 2267

NISSAN PRIMERA 1999 Electronic Repair Manual SR20DE ENGINE YEL959C HARNESS LAYOUT Engine Control Harness (Cont’d) EL-372
