Page 2761 of 3745

NISSAN LATIO 2010 Service Repair Manual GW-44 < SERVICE INFORMATION > FRONT DOOR GLASS AND REGULATOR FRONT DOOR GLASS AND REGULATOR Removal and InstallationINFOID:0000000005396762 DOOR GLASS Removal 1. Remove the front door finisher. Refer

Page 2762 of 3745

NISSAN LATIO 2010 Service Repair Manual FRONT DOOR GLASS AND REGULATORGW-45 < SERVICE INFORMATION > C DE F G H J K L M A B GW N O P 6. While holding the door window, raise it at the rear end to pull the glass out of the sash toward the insi

Page 2763 of 3745

NISSAN LATIO 2010 Service Repair Manual GW-46 < SERVICE INFORMATION > FRONT DOOR GLASS AND REGULATOR 5. Raise the door glass and hold with a suction lifter A. 6. If equipped, disconnect the harness connector from the regulator assembly. 7.

Page 2764 of 3745

NISSAN LATIO 2010 Service Repair Manual FRONT DOOR GLASS AND REGULATORGW-47 < SERVICE INFORMATION > C DE F G H J K L M A B GW N O P • Removal and installation of the door glass. • Removal and installation of the door glass run. Initiali

Page 2765 of 3745

NISSAN LATIO 2010 Service Repair Manual GW-48 < SERVICE INFORMATION > REAR DOOR GLASS AND REGULATOR REAR DOOR GLASS AND REGULATOR Removal and InstallationINFOID:0000000005396765 DOOR GLASS Removal 1. Remove the rear door finisher. Refer to

Page 2766 of 3745

NISSAN LATIO 2010 Service Repair Manual REAR DOOR GLASS AND REGULATORGW-49 < SERVICE INFORMATION > C DE F G H J K L M A B GW N O P 5. Pull out the partition glass in the direction as shown. 6. Raise or lower until lower glass bolts can be s

Page 2767 of 3745

NISSAN LATIO 2010 Service Repair Manual GW-50 < SERVICE INFORMATION > REAR DOOR GLASS AND REGULATOR 6. Raise up the door glass and hold with a suction lifter A. 7. Remove the regulator bolts, and then remove the regulatorassembly from the d

Page 2768 of 3745

NISSAN LATIO 2010 Service Repair Manual REAR WINDOW DEFOGGERGW-51 < SERVICE INFORMATION > C DE F G H J K L M A B GW N O P REAR WINDOW DEFOGGER Component Parts and Har ness Connector LocationINFOID:0000000005396768 System DescriptionINFOID:0
